GAS WALL MOUNTED ROOM HEATER
Model
DV30
DV45
WARNING:
If the information in these instructions are not followed
exactly, a fire or explosion may
result causing property damage, personal injury
or death.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
- Shut off the gas supply at the gas source.
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone
in your building.
- I
mmediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a qualified
installer, Service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
The coating selected to provide longer life to the heat exchanger
may smoke slightly upon initial firing.
Please provide adequate ventilation if this occurs.
The appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home, where not prohibited by local
codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a
certified kit is used.
Operation of this stove without the properly installed, furnished vent system and vent cap could result in Carbon Monoxide (CO) poisoning and
WARNING:
possible death. For your safety, this stove and the vent system should be inspected at least annually by a qualified service technician.
This unit is for residential use only and is not approved for installation in greenhouses, or environments involving dusty, wet, corrosive, or explosive
conditions. Such conditions will invalidate the warranty and may create unsafe conditions.
Installation, maintenance, service, trouble shooting and repairs must be performed by a qualified service agency.
Mr./Mrs. Homeowner, DO NOT attempt any of these procedures yourself as this could expose you to property damage, personal injury, or loss of life and
will invalidate all warranties.
INSTALLATION AND
OPERATING INSTRUCTIONS
Code
DG04900
DG04905
Gas
Gas "E"
Liquefied propane gas (LPG)
Gas "E"
Liquefied propane gas (LPG)
DV30
DV45
DG04905-15-08-2019A
Advertisement
Table of Contents
Related Manuals for Drolet DV30
Summary of Contents for Drolet DV30
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS GAS WALL MOUNTED ROOM HEATER Model Code DV30 DG04900 Gas "E" Liquefied propane gas (LPG) DV45 DG04905 Gas "E" Liquefied propane gas (LPG) WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or death.
-
Page 3: Table Of Contents
OPERATION ..........................17 TO TURN OFF GAS TO APPLIANCE ..................17 CLEANING AND MAINTENANCE ................... 18 GAS CONVERSION INSTRUCTION ..................20 ADJUSTMENTS ........................21 CHECKING THE SUPPLY PRESSURE ................... 22 TROUBLESHOOTING ......................24 WARRANTY ..........................25 PARTS LIST ..........................26 Drolet-DG04905... - Page 4 Drolet-DG04905...
- Page 5 Drolet-DG04905...
-
Page 6: Introduction
Read these instructions thoroughly before installing, servicing, or using the appliance. If you do not understand any part of these instructions consult local authorities, other qualified installers, service technician, the gas supplier or the manufacturer. Drolet-DG04905... -
Page 7: Product Identification
Code are to be followed in the absence of local code requirement. Model Input Type MAX wall MIN wall Nom./Red. Width Depth Height Connection thickness thickness DV30 3,49/1,42 25,27 8,85 33,77 1/2” Gas "E" 35,43 (LPG) 5,11/2,04 32,36 8,85 33,77 1/2”... -
Page 8: Product Features
PRODUCT FEATURES Room heater DV30 Gas type Gas A Gas E (LNG) (LPG) Max heating value 9300 9300 Min heating value 4740 4740 Minimum gas pressure before valve W.C. Maximum gas pressure before valve W.C. 8.48 21.2 Gas pressure after valve for max W.C. -
Page 9: Functional Wiring Diagram
CONDENSER IGNITION ELECTRODE FUSE MANUAL SWITCH PHASE NEUTRAL TIMER FAN THERMODISC TANGENTIAL FAN BULB OF SWITCH CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. Drolet-DG04905... -
Page 10: Product Features
· High Temperature Silicone (outside) · Pipe wrench The installation location shall provide the following; A) adequate combustion and ventilation air, and B) adequate accessibility clearances for servicing. MINIMUM CLEARANCES FROM COMBUSTIBLES 5,90” (150mm) MINIMUM 5,90” (150mm) MINIMUM 5,90” (150mm) MINIMUM Drolet-DG04905... -
Page 11: Vent Terminal Clearances
In accordance with the current CSA-B149.1 Natural Gas and Propane Installation Code In accordance with the current ANSI Z223.1 / NFPA 54 National Fuel Gas Code Drolet-DG04905... -
Page 12: Installation Warning
- DON’T overlap draperies, towels or anything else that could cause a malfunction and prevent a good air circulation in the environment. - DON’T block-off the air inlet / outlet of the appliance with linen or carpets. Drolet-DG04905... -
Page 13: Installation Procedure
5,74” (146mm) horizontal bracket. 25,27” (642mm) 32,36” (822mm) 24,80” (630mm) 24,80” (630mm) - Mark and drill the hole "d" and secure the 19,13” (486mm) 19,13” (486mm) template. Drill the hole as shown "a" "b" "c" "d" in the above figure. Drolet-DG04905... -
Page 14: Installation Procedure
11. Bend the 4 alignment tabs (8.1) of the plate (8) and secure it to the external wall with screws (9) 12. Fix the terminal (10) to the plate (8) with screws (11) 18,89” 480m m Ø 5,1 1” Ø 130m m Ø 3,14” Ø 80m m 6,85” 174m m 6,85” 174m m 0,39” 1,96” 10mm 50mm Drolet-DG04905... - Page 15 Fit it against the edge of the frame, slide the front of the jacket onto the front the frame and push it fully. Hold it in place and secure it to the heater with the screw (2). Restore the tray (3). Drolet-DG04905...
-
Page 16: Gas Connection
• Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. Drolet-DG04905... -
Page 17: Operation
Set the thermostat to it’s lowest setting. "Turn off all electric power to the appliance if service is to beperformed" Open cabinet door. Push in gas control knob slightly and turn clockwise to "OFF". Do not force. Close cabinet door. Drolet-DG04905... -
Page 18: Cleaning And Maintenance
The correct flame pattern should be viewed by looking through the view port in front of the unit cover. UNDERSIDE VIEW VIEW A = minimum flames 3) Pilot 1) Termocouple B = maximum flames 4) Gas outlet 2) Ignition electrode Drolet-DG04905... - Page 19 After inspecting burner, place back into heat exchanger. Be sure door gasket is not damaged and will effect a proper seal or pilot outage will occur. Tighten screws holding burner door to heat exchanger. Connect gas supply back to the pilot. Reassemble the casing. Drolet-DG04905...
-
Page 20: Gas Conversion Instruction
MAIN GAS BURNER INJECTOR REPLACEMENT (LNG) Model (LPG) Unscrew the collar (4, 3/8” F) from the MAIN DV30 BURNER Injector mount fitting; 1,65 1,05 Ø main burner Unscrew the injector mount fitting from the... -
Page 21: Adjustments
- small side facing the regulator and bigger side facing the seal cap => outlet pressure for Gas "A"(LNG) - bigger side facing the regulator and small side facing the seal cap => outlet pressure for Gas "E"(LPG) Figure 4: screw in the sealcap. Drolet-DG04905... -
Page 22: Checking The Supply Pressure
COUNTERCLOCKWISE to increase it. Once the settings have been made, seal both the pressure and minimum flow rate regulators with a drop of paint, then disconnect the pressure gauge from the pressure port and turn in the screw. Drolet-DG04905... - Page 23 Switch to MAX Motor faulty Replace The hot air flow is reduced Tangential fan failure Replace Intake/outlet grille obstructed Verify / Release The fan does not change speed. Switch faulty Check / replace The burner does not change its power setting. Drolet-DG04905...
-
Page 24: Troubleshooting
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. • If you cannot reach your gas supplier, call the fire department. WARNING Turn off heater and let cool before servicing.Verify proper operation after servicing. Drolet-DG04905... -
Page 25: Warranty
1 year *Pictures required Shall your unit or a component be defective, contact immediately your dealer or DROLET customer service. Prior to your call make sure you have the following information necessary to your warranty claim treatment: Your name, address and telephone number. -
Page 26: Parts List
PARTS LIST Drolet-DG04905... - Page 27 Description DV30 DV45 31135 RAL9002 humidifying tray 80020025 00 31136 RAL9002 DX + SX side panels 80020020 00 31137 RAL9002 front panel 80010670 00 80010671 00 31138 RAL9002 door 80002051 00 31139 RAL9002 front panel + door 80010672 00 80010673 00...
- Page 29 NOTE: Distribued by: Due to ongoing Stove Builder International inc. product upgrading, aesthetic 250, rue de Copenhague, and dimensional features, St-Augustin-de-Desmaures technical details, fittings and (Québec) Canada accessories could undergo G3A 2H3 changes and are not binding. 418-908-8002...
