Skiguard Sport Install Instructions

Installation Instructions Skiguard Sport Models:
Included inside Skiguard Sport Model:
•
Plastic bag containing two sets of quick-
release tie-downs and mounting
hardware
•
Pair of cargo organizers
•
Set of keys (tied to the strap in the rear)

Step 1: Cross bar installation

If not already done, install your cross bars. Make sure to follow all guidelines as set forth by the
manufacturer. Pro-tip: Adjustments to the mounting location of the cross bars may be required, so do
not fully tighten the cross bars until the end. If you have been supplied with T-bolts (see Step 5), cut 2x
15inch strips of the rubber sealing and install in the center of the cross bars. These strips may be longer
or shorter, just make sure they do not interfere with the T-bolts.

Step 2: Unwrapping the Skiguard

Pull the Skiguard out of the cardboard box and lay it down on top of the carboard box. Now remove the
plastic wrapping. Be careful not to scratch the surface if using a knife to cut off plastic. Pro-tip: make
sure all tape is removed from the Skiguard – it will not be easy to get off after a few weeks in the sun!

Step 3: Lift the Skiguard into the car

Gently lift the Skiguard onto the cross bars. The open cut-outs with the four slots should be directly over
the cross bars. Pro-tip: with one person in the front and one in the back of the Skiguard, lift the box over
your heads and walk to the side of the car. One of the two will lean in and lay the front or back down on
a cross bar. Align the open cut-out with the cross bar. Once the front or back is resting on a cross bar,
push the box inward so it is resting safely on the roof, and allow the second person to follow with the
other end of the box. Now gently slide the box inward until it is nearly centered on the roof. Be aware of
the antenna and make sure to lift the box over it to avoid causing any damage.

Step 4: Positioning

With the rear hatch open, move the Skiguard as far back as possible without hitting the hatch. We
recommend leaving about 2cm or ¾ inch clearance. To ensure that the Skiguard is properly centered,
use a tape measure to adjust its positioning side-to-side. Pro-tip: If you don't have a tape measure
readily available, use the antenna in the rear and the rear-view mirror in the windshield to gauge if the
Skiguard is centered.
Install Instructions Sport 180401 ENG R1
You will need:
•
1 strong friend
•
Knife or something with a sharp point
•
Tape measure (not required, but
recommended)
