Summary of Contents for Boss Audio Systems MGV550B
-
Page 2: Information To The User
Thank you for purchasing this Bluetooth Marine Digital Media AM/FM Receiver Please read through these instructions carefully so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference. INFORMATION TO THE USER The Bluetooth®... -
Page 3: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. -
Page 4: Before You Start
• Refer any repairs to a qualified BOSS AUDIO SYSTEMS Service Center... - Page 5 • The MGV550B should be wired directly to a vehicles battery • When wiring directly to the vehicles battery, be sure to disconnect the batteries negative terminal wire before starting any wiring procedures, if extending the main power primary wire, it is...
-
Page 6: Troubleshooting Guide
Refer to the user manual of the The Bluetooth function of the device for how to enable the device is not enabled Bluetooth function MGV550B BT memory Follow how to reconnect a Cannot pair Bluetooth is full device in section E... -
Page 7: Specifications
SPECIFICATIONS FM TUNER FREQUENCY RANGE INTEGRATED AMPLIFIER • 87.5~107.9MHz • PEAK Power Rating: 60W / channel • Europe 87.5~108MHz • Channels: 4 • Frequency Response: 20-20kHz • Asia 87.5~108MHz • Australia 87.5~108MHz • Usable Sensitivity: 12dB (S/N=30dB) • Bands: 3 AM TUNER FREQUENCY RANGE CHASSIS •... -
Page 8: Suggested Mounting Methods
SUGGESTED MOUNTING METHODS CAUTION!! Using other mounting methods may void this warranty Make the mounting hole size as follows １ 3.55〞 90mm Slip the unit through the hole cutout ２ ３ Firmly tighten remaining four screws on the front panel. TOOLS NEEDED: - Measuring Tape / Ruler - Wrench and/or Pliers... -
Page 9: Wire Diagram
WIRE DIAGRAM CAUTION!! Do not ground or short the speaker leads... -
Page 10: Getting Started
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of BOSS AUDIO SYSTEMS Inc. - Page 11 Button Control Fuctions GETTING STARTED ROTARY KNOB MODE MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL MANUAL...
- Page 12 AUDIO and SYSTEM SETUP SETTINGS...
-
Page 13: Bass Level
AUDIO EQ Jazz EQ Beat EQ User EQ Pop EQ Classical EQ Rock EQ Flat BASS Level BASS +07 BASS 00 BASS -07 MID Level MID +07 MID 00 MID -07 Treble Level TRE +07 TRE 00 TRE -07 Balance Level BAL R +07 BAL L -R BAL -07... -
Page 14: Radio Operation
Press BLUETOOTH OPERATION PAIRING & DISCOVERING A NEW BLUETOOTH CONNECTION Note: The mobile device must be within 33ft (10m) of the MGV550B for Bluetooth to function properly. ANDROID users: a. Go into the Settings Menu of your ANDROID device b. Enter the Bluetooth Menu and press SCAN c. -
Page 15: Usb Operation
If your device was previously paired with the , but it wasn’t the last paired device: Ensure no other devices are currently paired If the device is out of range from the , it will disconnect automatically USB OPERATION 1) Press the MODE button to select BT AUDIO 2) Press to start PLAY, press again to PAUSE 3) To skip songs or advance tracks press...
