Rechargeable Multifunction LED Light
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
• Adult use only. This product is not a toy, keep away from children.
• Do not stare directly at the light emitted by this product.
• The built-in rechargeable battery is not replaceable. Do not open, short circuit, or destroy the battery as injury may occur.
• Do not dispose of product in regular trash, municipal waste stream or by fire as the built-in rechargeable
battery may leak or explode.
• This product is resistant to rain and splashing water, but it is not submersible. Do not drop into or immerse in water.
General
• This product is powered by an internal built-in rechargeable battery, however it can be operated from the external battery
pack using four (4) AA size batteries (not included) when the internal built-in battery is exhausted.
• Remove batteries from the external battery pack which is not to be used for an extended period of time.
• Do not mix old and new batteries. Do not mix alkaline, standard (Carbon - Zinc), or rechargeable (Nickel - Cadmium)
batteries.
• Remove used batteries promptly.
• Always purchase the correct size and grade of battery most suitable for the intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure batteries are installed correctly with regard to polarity (+ and -).
• The LED is a lifetime light source. It will never need to be replaced.
• The operating time for this product depends on whether it is run continuously or intermittently. Intermittent use extends the
operating time of a set of batteries.
• To clean the product, use only a damp cloth. Avoid strong cleaner, excessive water and abrasive brush.
Parts list
1.
External battery pack (batteries not included)
2.
Detachable 12V DC power cord
3.
USB cable
Built-in battery indicator level and charging receptacles
The built-in battery indicator light and the charging input receptacles
are located on the left side under the rubber flap.
When the device is switched on and operating from the built-in battery
it automatically detects the built-in battery level as follow:
•
If the indicator light is flashing red the battery is about 40% level or
less, and requires charging.
•
If the indicator light is off the battery level is about 40% level or above.
Charging methods
The built-in battery indicator light will turn red when is in charging mode,
and green when is fully charged from either:
• A computer through the USB cable. It takes 5 to 6 hours
to fully charge the battery. (See Fig. 1)
• A vehicle 12V DC receptacle through the detachable 12V DC power cord.
It takes 2 to 3 hours to fully charge the battery. (See Fig. 2)
(170PO) RECHARGEABLE MULTIFUNCTION LED LIGHT ENGLISH 4.875" X 7.25" 05/16/2012
INTEX
®
OWNER'S MANUAL
WARNING
OPERATING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Page 1
(170PO) RECHARGEABLE MULTIFUNCTION LED LIGHT ENGLISH 4.875" X 7.25" 05/16/2012
SAVE THESE INSTRUCTIONS
Page 2
1 Watts
Model CL1111
1
170
PO
170-*PO-R0-1305
170
PO
3
2
Fig. 1
Fig. 2
Advertisement
Table of Contents
Summary of Contents for Intex CL1111
- Page 1 (170PO) RECHARGEABLE MULTIFUNCTION LED LIGHT ENGLISH 4.875” X 7.25” 05/16/2012 INTEX ® OWNER'S MANUAL Rechargeable Multifunction LED Light 1 Watts Model CL1111 READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT WARNING • Adult use only. This product is not a toy, keep away from children. • Do not stare directly at the light emitted by this product. • The built-in rechargeable battery is not replaceable. Do not open, short circuit, or destroy the battery as injury may occur. • Do not dispose of product in regular trash, municipal waste stream or by fire as the built-in rechargeable battery may leak or explode.
- Page 2 (170PO) RECHARGEABLE MULTIFUNCTION LED LIGHT ENGLISH 4.875” X 7.25” 05/16/2012 • The external battery pack. It takes 5 to 6 hours to fully charge the battery. 1. Pull out the left rubber protector to access the battery compartment cover and then press and open the cover (see Fig 3 & 4). 2. Insert four (4) AA size batteries following the orientation shown on the battery compartment (see Fig 5) 3. Close the cover and replace the rubber protector back. Fig. 3 Fig. 4 4. With the switch off, plug in the external battery pack cord into the device input receptacle (see Fig 6) and the device will start charging. 5. To use the device while charging the built-in battery, simply turn on the switch, the LED will light up and the built-in battery is charging at the same time. NOTE: with the external battery pack attached, the system cannot bypass the charging mode and light up the LED only. Fig. 6 Attaching the external battery pack to the main device Fig. 5 1.
-
Page 3: Limited Warranty
>35 *Built-in battery >70 *Built-in + external pack batteries Unit: hours *Based on a fully charged internal battery, and with 4 AA fresh alkaline batteries. SAVE THESE INSTRUCTIONS Page 5 (170PO) RECHARGEABLE MULTIFUNCTION LED LIGHT ENGLISH 4.875” X 7.25” 05/16/2012 Limited Warranty Your RECHARGEBALE MULTIFUNCTION LED LIGHT has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the RECHARGEBALE MULTIFUNCTION LED LIGHT. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable. This Limited Warranty is valid for a period of one (1) year from the date of the initial retail purchase. Keep your original sales receipt with this manual, as proof of purchase will be required and must accompany warranty claims or the Limited Warranty is invalid. If a manufacturing defect is found within this one (1) year period, please contact the appropriate Intex Service Center listed in the separate “Authorized Service Centers” sheet. The Service Center will determine the validity of the claim. If the Service Center directs you to return the product, please carefully package the product and send with shipping and insurance prepaid to the Service Center. Upon receipt of the returned product, the Intex Service Center will inspect the item and determine the validity of the claim. If the provisions of this warranty cover the item, the item will be repaired or replaced at no charge. Any and all disputes regarding the provisions of this Limited Warranty shall be brought before an informal dispute settlement board and unless and until the provisions of these paragraphs are carried forth, no civil action may be instituted. The methods and procedures of this settlement board shall be subject to the rules and regulations set forth by the Federal Trade Commission (F.T.C.). IMPLIED WARRANTIES...
