USER GUIDE
SENSOR TAP
Pillar Sensor Taps & Bib Sensor Tap
PENGUIN
PELICAN
HERON
PLOVER
FLAMINGO
Advertisement
Table of Contents
Summary of Contents for ARK Penguin Series
- Page 1 HERON PENGUIN 71005 71006 71005B 71006B 71005E 71006E USER GUIDE PELICAN PLOVER 71007 71007B 71001 71007E FLAMINGO ABOUT CAT NO. Both No Suffix AC & DC Only DC (Batteries) Only AC (Electricity) 61004 61004B 61004E SENSOR TAP An ISO 9001 : 2008 Certified Company Pillar Sensor Taps &...
- Page 2 ABOUT SENSOR TAPS SPECIFICATIONS Ark Sensor Taps are automatic faucets through which water flows only SPECIFICATIONS PILLAR TAP SENSORS BIB TAP SENSORS when hands activate the fixture. These taps have built in infrared sensors Power Consumption 2-5 Watts 2-5 Watts which sense the presense of an object i.e.
- Page 3 INSTALLATION DIAGRAM INSTALLATION PROCEDURE Please refer to the diagram: Pillar Tap Sensors: (Fig. 1) Install the Pillar Tap on the Wash Basin and tighten the Check Nut. Fix the connector on PVC pipe loose end. Fix the other end of this Connector to the Control Box. Bib Tap Sensors: (Fig.
- Page 4 IMPORTANT INFORMATION & GUIDELINES TROUBLESHOOTING Duracell Alkaline 'AA' size batteries should be used for DC PROBLEM REASON ACTION Models. Sensor connected but Plug /Batteries not Check the Plug /Batteries not working properly inserted. and insert them properly. The Control Box should be fixed vertically as shown in Old Batteries Replace the Batteries.
