CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017
CAEDMON ECO DESIGN SMOKE CONTROL
WOODBURNING STOVE
INSTALLATION AND USER INSTRUCTIONS
Read these instructions carefully before installation and use.
These instructions should be retained by the user for future reference.
The Caedmon Eco Design stove has a nominal heat output of 7kW (wood), and a weight of
92 kg. The flue gas mass flow is 6.1g/s for wood logs. The mean flue gas temperature
directly downstream of the flue spigot at nominal heat output is 322 degrees C (wood).
Stove efficiency 76%. The Caedmon Eco Design has been tested as a closed appliance and
is capable of intermittent operation.
WARNING
The stove must be installed to comply with Health and Safety at Work Act 1974 to British
Standard BS 8303 and to all local Building Regulations, including those referring to
National and European standards. These need to be complied with when installing the
appliance.
Ensure that the flue pipe diameter is not less than the 150mm diameter outlet on the
appliance.
There must not be an extractor fan fitted in the same room as the Caedmon Eco Design.
If there is a possibility of disturbing asbestos during the installation it is necessary to take
the appropriate steps to protect the installer.
Fire cement is caustic and protective gloves should be worn.
The chimney must be swept and examined for soundness and suitability before the stove is
installed. Remedial action should be taken if required, seeking expert advice if necessary.
Where the chimney is believed to have previously served an open fire installation, it is
possible that the higher flue gas temperature from a closed appliance may loosen deposits
that were previously firmly adhered, with the consequent risk of flue blockage. It is
therefore recommended that the chimney be swept a second time within a month of regular
use after installation.
CO Alarms:-Building regulations require that whenever a new or replacement fixed solid
fuel or wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be
fitted in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer's
instructions. Provision of an alarm must not be considered a substitute for either installing
the appliance correctly or ensuring regular servicing and maintenance of the appliance and
chimney system.
1
Advertisement
Related Manuals for Town & Country Fires Caedmon ECO Smoke Control
Summary of Contents for Town & Country Fires Caedmon ECO Smoke Control
- Page 1 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 CAEDMON ECO DESIGN SMOKE CONTROL WOODBURNING STOVE INSTALLATION AND USER INSTRUCTIONS Read these instructions carefully before installation and use. These instructions should be retained by the user for future reference. The Caedmon Eco Design stove has a nominal heat output of 7kW (wood), and a weight of 92 kg.
- Page 2 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 The Clean Air Act 1993 and Smoke Control Areas Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area.
-
Page 3: Unpack The Stove
CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 UNPACK THE STOVE Carefully cut the straps and lift the box up over the top of the stove. Remove the packing from round the outside of the stove, leaving the plastic cover on if building work is still in progress, it is important to protect the paint finish from any damage, water, dust or fire cement. - Page 4 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 required. The Caedmon Eco Design requires a Class 1 chimney of its own, a shared chimney will not be suitable. The chimney must be sound, free from leaks and swept before installation. If the chimney requires lining, a lining must be used which is suitable for wood and solid fuel, with a minimum of 150mm internal diameter.
-
Page 5: Lighting The Stove
CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 Connect the receiver box to the cable near the stove, insert 4 x AA batteries. Place the 9v battery into the handset. To open the air vent press the smallest button on the handset at the same time as the button next to the arrow pointing upwards. - Page 6 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 with the stove – place the black cover over the handle when opening and closing the door, then remove and leave near the stove. The appliance will give more heat output with increased air supply, so the controls can be adjusted to increase or decrease the burning rate of the fuel, as desired.
- Page 7 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 Fuel overloading The maximum amount of fuel specified in this manual should not be exceeded, overloading can cause excess smoke. Operation with door left open Operation with the door open can cause excess smoke. The appliance must not be operated with the appliance door left open except as directed in the instructions.
- Page 8 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 originally used in the factory, can be obtained from you supplier. Warning – do not use an aerosol spray near the stove when the stove is alight. This appliance should be regularly maintained by a competent service engineer. There must be no unauthorised modification of the appliance Any replacement parts must be recommended by the Manufacturer and can be purchased from the approved dealer the stove was originally purchased from.
-
Page 9: Warning Note
CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 WARNING NOTE Properly installed, operated and maintained this stove will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fueling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, then the following immediate action should be taken:- (a) Open doors and windows to ventilate the room and then leave the premises. - Page 10 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 Product Fiche Commission Delegated Regulation (EU) 2015/1187 Energy Labelling of Local Space Heaters Town & Country Fires Supplier`s Name or Trademark: Caedmon Eco Design SC Suppliers Model Identifier: Energy Efficiency Class of Model: Nominal Heat Output to Room (kW): Nominal Heat Output to Water (kW): 76.0...
- Page 11 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 The Town and Country Fires Guarantee Town and Country Fires Ltd guarantee the quality of workmanship of their multi fuel stoves for twelve months from the date of purchase. Stoves must be installed to current Building Regulations National and European Standards and per our Installation / User instructions supplied with the stove.
- Page 12 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 TO REPLACE THE BRICKS & BAFFLES Firstly remove the fuel guard then the first right hand side brick. Next remove the first baffle then the first left hand brick. Slightly push the second baffle up over, then using the riddling tool gently prise one of the side slip bricks out (see picture below) The second side brick can now easily be removed.
- Page 13 CAEDMON ECO DEISGN SMOKE CONTROL ISSUE No. 02 10/10/2017 Congratulations on your purchase of a Town and Country Fires Multi Fuel Stove. Please complete the following to validate your guarantee from one to ten years and either complete via our website or return in the pre paid envelope to;...
