Summary of Contents for ancnoble WSF Series
- Page 1 REV: A1.02 Self-Refill/Drain Auto Waterer User Manual © 2013 ANC Technology www.anctech.com...
-
Page 2: Specifications
ANC Technology 1. Introduction: This self-refill/drain auto waterer will self drain and refill water according to set up interval, to make sure the water for your pets is clean and flesh. Solar-powered, easy to operate, good for backyard dog, cat, chicken and other pets. 2. -
Page 3: Installation Step
ANC Technology 4. Installation step： 4.1、Component introduction: 1. Solar panel 7. Reinforcing plate 2. Water feeder control panel 8. Screw holes 3. Steel Plunge 9. Water inlet 4. Matel cap 10. Expansion bolts 5. Float 11. Water Drain Outlet 6. Water container 4.2 How to install 1.Choose fence or posts, drills 2 holes on fence or posts, try to make them as parallel as possible, make the auto waterer even right and left after installed, the... - Page 4 ANC Technology Fig 2 2. Screw the two M10 expansion bolts to the holes, set the threaded part out from the hole, hung the waterer first, then put up the reinforcement plate , finally add spring washers and gaskets, use the nut to tighten. Fig 3. Fig 3...
- Page 5 ANC Technology Note: Please make the waterer front level is a little higher than back level for easier drain, and please also make sure that tilt would not more than 5 degrees. Otherwise will cause the seal plunge not seal well. 3.
- Page 6 ANC Technology Fig 5 5. Connect the solar panel, put whole water dispenser under sun for some time, a few hours or one day, depend on sun. 6. Close valve, then connet water pipe in and out. 7. After one day or so charge under sun, open the water valve to let water to fill. Adjusting float if need.
-
Page 7: How To Operate
ANC Technology Fig 6 5. How to operate： 5.1 Check if the installation is OK, then drain water once: Open the metal cap, user can see the control panel, push and hold the “←”key about 10 seconds, wait until all the 4 lights on the panel are light up, release the key, then only lights for “8 hour”... - Page 8 ANC Technology 5.2 Setup drain/clean water period: Open the metal cap can see the control panel. There are 4 choices of drain interval time: 2 hours, 4 hours, 8 hours and 24 hours. Light will flash under each choosed one. Push “←” to move light and choose. Factory default is 24 hours.
- Page 9 ANC Technology ANC Technology Limited Warranty card Dear Customer： Thank you very much for choosing ANC products. 1. This product has FCC verification. 2. Warranty period is one year. Beginning on day of receipt. 3. Please keep your receipt and this warrantee card. 4.
