FSLIMPRO05 - 10 - 15 - 20 - 25
1. GENERALITES
La barrière FSLIMPRO a été spécialement étudiée et réalisée pour permettre une installation facile et
rapide. L'électronique incorporée dans les profils et l'absence de signaux de synchronisation par câble
facilitent l'installation et réduisent au minimum la pose des câbles de liaison (uniquement l'alimentation et les
contacts d'alarme).
La disponibilité de profils de différentes tailles (1 à 2,5 m) permet d'adapter la protection selon les besoins
spécifiques. La fixation des profils par vis et joints toriques ainsi que la forme particulière des bouchons
garantissent l'étanchéité de la fixation et permettent de l'utiliser en extérieur.
Grâce à la forme du profil en aluminium et à la simplicité du système de fixation des sondes, il est possible
de les placer à l'intérieur de la barrière de sécurité FSLIMPRO, à la hauteur désirée, permettant de
l'optimiser selon vos propres exigences.
2. CARACTERISTIQUES PRINCIPALES
• Profil en aluminium
• Bouchon supérieur en caoutchouc et bouchon inférieur en ABS comportant un trou au fond, protégé par
une éponge permettant le passage de l'air, évitant la formation de buée à l'intérieur des colonnes ainsi
que la pénétration d'insectes pouvant endommager les photocellules
• Capot en polycarbonate
• Fixation murale par vis et joints toriques compris dans la fourniture
• Fourni avec 4 paires de sondes émetteur + récepteur
• Possibilité d'utiliser jusqu'à 8 paires de sondes
• Coulissement des sondes émetteur + récepteur dans la glissière interne prévue à cet effet et fixation par
vis
• Fourni avec protection antiarrachage et antiouverture pour chaque colonne
• Fourni avec un passe-fil pour un câble de diamètre extérieur 6mm.
• Amplificateur de photocellule incorporé ayant les caractéristiques techniques suivantes:
Système multiplexé et synchronisé
Pouvant gérer jusqu'à 8 rayons, sélectionnables 2 par 2.
1 sortie à relais en commutation N.O./N.F
• Facilité d'installation et d'alignement des sondes grâce à quatre niveaux d'intensité des rayons
infrarouges.
• Activation des rayons utilisés au moyen du commutateur DIP "BEAMS/RAGGI" à quatre contacts.
• LED de signalisation de l'état des rayons:
allumée = rayon interrompu ou désactivé
éteinte = rayon aligné et non interrompu
• Modes de fonctionnement sélectionnable au moyen du commutateur DIP "FUNCTION" (1 et 2 ), comme
l'indique le tableau suivant:
Dip 1
Dip 2
OFF
OFF
ON
OFF
OFF
ON
ON
ON
3. CARACTERISTIQUES TECHNIQUES
Alimentation
Puissance absorbée
Courant absorbé
Longueur d'onde I.R.
Portée
Sorties à relais (contact sec inverseur)
Temps de déclenchement du relais
Temps de réarmement
Température de fonctionnement
Un rayon interrompu pendant au moins 0,1seconde
Au moins deux rayons adjacents interrompus pendant 200msec,
ou deux rayons non adjacents pendant 500msec
Au moins deux rayons adjacents interrompus pendant 200msec
ou un rayon pendant 1seconde
Un rayon interrompu pendant au moins 1 seconde
12Vcc
Max. 1.5 W
Max 50mA (4 paires de rayons activés)
950 nm
10 mètres en intérieur / 6 mètres en extérieur
N.O. / N.F.
Minimum 100ms maximum 1seconde
0,5 seconde
-20 °C ÷ +55 °C
FRANÇAIS
Activation alarme
ISFSLIMPRO_10_12_fra.doc
