proSmart PS Plug User Manual

Wi-fi programmable controller
Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PS Plug and is the answer not in the manual?

Questions and answers

Summary of Contents for proSmart PS Plug

  • Page 2 PS Plug allows the fast connected devices — their work and џ automatization of every electrical current status. device, regardless of its manufacturer or model. The technology set in PS Plug allows џ it to connect with any wireless...
  • Page 3 Why choose PS Plug Provides comfort and mobility џ Optimizes the control of the connected appliances џ Complete integrated control system џ Easy to use and user friendly software interface џ Mobile application running on all mobile OS џ PS Plug...

  • Page 4: Technical Specifications

    Technical specifications...
  • Page 5 Switching socket from 5% till 90% without condense Air humidity during transportation Charging block 90V - 250V AC 50-60Hz Working frequency Wi-Fi (b/g/n) 2,4GHz Size 110x62x73mm (LxWxH) Working temperature 0°— + 45°C -20°— + 60°C Storage temperature Working humidity 90% without condense —...

  • Page 6: Safety Instructions

    Safety instructions Please, read before using the device for the first time The outlined safety procedures below are to be followed while using the current product. Please, do follow all warnings in the device’s user manual. General safety instructions You are the only one responsible for the device’s usage, as well as for any caused damages in consequence of that.
  • Page 7 national and regional legislations are followed. The device is to be installed in electric switchboards or in the device/s it will manage and is created to control household devices and equipment. Any unauthorized reconstruction and/or product modification is strictly forbidden following the European safety and approval directives (CE). Services, settings and repairs could be accomplished only by an authorised service provider.
  • Page 8 Attention! Damaged power supply cables are a life treat as could lead to an electric shock. Do not use the device if there is a damaged cable, power supply cord or network plug. In case of a fault, turn to a qualified technician! Do not leave children with the device without supervision! Do not let children play with the device.
  • Page 9 Electric safety This device could be used only when powered by the specific supply unit. Every other way could be dangerous and terminates the validity of any issued device’s certificate. Use the correct external power supply. The device should be powered only by the specific power supply as indicated on the nominal electric power supply’s nameplate.
  • Page 10 In case you are in a flammable materials’ environment, the device must be turned off and the user is to follow all instructions and warning labels. The sparks in such places could cause fires or explosions, leading to injuries and even death. We highly recommend to not use the device in fueling areas, workshops or gas stations.
  • Page 11 with high air humidity. If the device ever gets wet, do not attempt to dry it off in a furnace or a dryer for the risk of damage is high! Do not use the device after a sudden temperature change. If you are transferring the device between environments with big temperature and humidity level differences, it is possible for the steam to condense on the surface and inside of the device.
  • Page 12 the use of certain hazardous substances in electrical and electronic equipment (RoHS) and its recasts. Burns and fire prevention Do not use the device if the premises’ temperature goes above 40°C. Keep the highly flammable materials away from the device. Make sure free air access around the device is available.
  • Page 13 PS Plug connects very easily to a chosen Wi-Fi router. This is accomplished via the proSmart application for your smartphone, smartwatch, PC or tablet. You can add a new device in three quick and easy steps. Upon installation of the...
  • Page 14 PS Plug is created to work on the following environmental conditions: - For premises’ work; - For altitude up to 2000m; - For ambient temperature from 0°С till +45°С; - For average maximum air humidity for temperature of up to 31°С - 80%, linear decreasing to 30% average humidity for 45°С...
  • Page 15 1 pc user manual for installation Unpack the device and take the two main elements out of the box (Scheme 1). Connect your PS Plug to any electrical appliance by placing the device in a Schuko socket. Scheme 1 Attention! Do not modify or influence the built in protection of the electric...
  • Page 17 1.2 Installation PS Plug is a device meant to be plugged in a Schuko socket. (Scheme 2). Scheme 2 1.3 A few requirements must always be considered and followed during installation: - The device’s installation and connection must be accomplished according to the national legislation for electrical installations.
  • Page 18 the power supply (the controller itself, as well as the chain it controls through the relayed exit). - Disengagement tool must be provided for the electric installation during the device’s installation and the needed safety is to be ensured for the service provided. - All connections to the relay’s outputs in the device must be conducted with conductors with an insulation resistance not lower than that of the insulated conductors of РVС...
  • Page 19 PS Plug will be operating in. Open the proSmart mobile app on your smartphone or tablet. If you still do not have the mobile app installed, you can download it from Google Play store, Apple store or Windows Phone Store.
  • Page 20 Log in to your profile with your email and password. If this is your first proSmart device and you have not registered yet, you can do that in proSmart’s webpage: https://prosmartsystem.com/en Press the ‘Add’ button for adding a new device, located in the upper hand side of the screen.
  • Page 21 Watch the green light on the device. When the light goes off and then starts blinking every 3 seconds, PS Plug is ready to work. Look at the mobile device’s screen. The app is now ready to control PS Plug If you have used ProSmart Config mode, please proceed to Step 3.
  • Page 22 PC or mobile device. 2.2.1 Initiate a wireless network search from your smartphone or laptop and connect to the PS Plug’s AP (the wireless network). Every device creates a network with its own name, starting with BSwitch_xxx and a combination of letters and numbers.
  • Page 23 Scheme 2.2.2 After connecting, your browser will automatically open a new page giving you the chance to choose the wireless network, to which you want to connect the device (Scheme 5). If your browser does not open automatically, please open it manually for the automatic opening of the browser is a manual setting and thus it could be turned off.
  • Page 24 2.2.4 Choose the desired Wi-Fi network, type in your password and click on the ‘Connect’ button - Scheme 6 2.2.5. In up to 20 seconds PS Plug will switch to a working mode and the light indicator will be on all the time, blinking shortly every second.
  • Page 25 2.3 Working mode – When PS Plug is in Working mode, the green light blinks every 3 seconds. If you hold the button for 5 seconds, PS Plug will go to settings in ProSmartConfig mode. Step 3: User profile creation: 3.1 Once connected to the Internet,...
  • Page 26 3.2 If you choose to use a browser, open https://prosmartsystem.com/en in your PC desktop or mobile device and press the ‘Log in’ button in the upper right corner (Scheme 7). Scheme 3.3 If you access the website or the app for the first time, you need to register or log in with your Facebook or Google + accounts by just clicking the particular button.
  • Page 27 3.4 New user registration. Fill in the registration form and click the ‘Register ’ button. You are now registered and may enter the app. (Scheme 9). Scheme 9...
  • Page 28 4.1 Home Screen —After the successful login with username and password, you should already be seeing the home screen in your profile and can add the device you have received. Enter the serial number of your PS Plug device that you previously connected to the wireless network (Scheme 10).
  • Page 29 Scheme 11 In order to set a name for your device, as well as a time zone and location, press button in the upper right corner and fill in the fields (Scheme 12). From that window you can also delete the device from your profile via clicking the deletion button in the bottom right corner.
  • Page 30 Scheme 12 4.3 You can now set and control your device. In the upper left corner you can find three buttons: Main screen, Schedule and Graphics (Scheme 13). Main screen Schedule Graphics Scheme 13...
  • Page 31 5.2 Timer - When selecting Timer, the appliance switches on and remains switched on according to the user's set time. After the set time has elapsed, the PS Plug returns automatically to the previous mode of operation (Scheme 14) Scheme 14...
  • Page 32 5.3 Sharing devices From the Shared devices menu via a button , placed in the upper right corner of the proSmart application‘s screen, every device’s owner can share them with other registered users via an email. Step 6: PS Plug...

  • Page 33: Warranty

    Warranty The warranty of the device is 24 months from the date of purchase. The serial number of the PS Plug device is unique and you need to present it in the event of a problem during the warranty period.
  • Page 34 Manufacturer: Pro Smart Inc 78 Maestro Kanev Str. 1618 Sofia, Bulgaria prosmartsystem.com/en...
