Step 6
Cable Management
Loop cable from monitor under fore-
arm. Pull handle down and tuck
cables betweem the plastic cable
management.
Ergonomic mounting solutions for monitors and keyboards.
Model 9112 Single or Double
Use the cable clip to keep cables organized
LCD Pole Arm
and in tact around the pole.
Installation Instructions
P502576
Rev B
