Pitching angle adjustment
3
5
•
Use the tilt adjusting knob to adjust your TV to the desired angle, the pitching angle can be adjusted
between -20°~20°, as shown in fig 5.1.
wall
Tilt adjusting knob
Maintenance
Once you have mounted the bracket and the flat screen, check that they are sufficiently secure and safe to
use. You should check whether screws are fixed well each two months. If you have any doubts regarding the
installation, please consult our retailer or service department for detail.
7
wall
fig. 5.1
INSTALLATION INSTRUCTIONS
Pitching angle:
-20° ~ +20°
180°
Swivel:
30kg
(66lbs)
MAX
LCD Wall Mount
M
Max Load Capacity: 30kg(66lbs)
Advertisement
Summary of Contents for HQ TVS-HQ-FSB06B
-
Page 1: Installation Instructions
Pitching angle adjustment • Use the tilt adjusting knob to adjust your TV to the desired angle, the pitching angle can be adjusted between -20°~20°, as shown in fig 5.1. INSTALLATION INSTRUCTIONS wall wall Tilt adjusting knob fig. 5.1 Maintenance Once you have mounted the bracket and the flat screen, check that they are sufficiently secure and safe to use. - Page 2 NOTE: Read entire instruction sheet before you start installation and assembly. Component Checklist IMPORTANT: Ensure you have received all parts against the component checklist prior to installing. If any parts are missing or faulty, telephone the special franchiser for a replacement. WARNING •...
- Page 3 WOOD STUD WALL MOUNTING: SOLID BRICK AND CONCRETE BLOCK MOUNTING: WARNING WARNING • Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components. • When installing wall mounts on cinder block, verify that you have a minimum of 1-3/8”...
- Page 4 Installing the Display • Find the appropriate VESA, attach the adapter plate to the back of the screen using the appropriate combination of screws, washers, as shown in fig.4.1 and fig.4.2. • Begin with the proper screw, hand thread through washer and adapter plate into screen as shown below. •...
