Design Hardware F1000V LBR Installation Instructions

STEP 3:INSTALL FIRE RATED BOLT
1.Insert bolt and use the provided screws to secure bolt.
2.3/16" x 1/2" flat head machine screws and 3/16" x 5/8" flat head,
self-tapping machine screws for metal door use.
3.5/32" x 3/4" flat head wood screws for wood door use.
STEP 4:INSTALL STRIKE HOLE PLUG
1.Insert hole plug into the 1" hole in strike door leaf.
2.Self adjusting tabs on the hole plug will lock in place to secure
the plug.
STEP 5:REVIEW INSTALLATION
1.Close both doors and verify fire rated bolt and strike hole are lined up.
2.Be sure the door gap directly in front of the fire rated bolt
any other similar type of device.
REMARKS:
1.Refer to F1000V devices Installation Instructions for
2.Before installing head cover,insert head cover plug into bottom side of head cover first.
HEAD COVER PLUG
(Packed with LBR device)
is not covered with a door edge guard or
further details.
HEAD COVER
HEAD COVER PLUG
INSTALLED
FIRE RATED BOLT
F1000V LBR

INSTALLATION INSTRUCTIONS

IDENTIFICATION OF PARTS
A
HEAD COVER PLUG
STRIKE HOLE PLUG
(FOR STRIKE DOOR)
3/16" x 1/2"
FLAT HEAD FLAT HEAD,SELF TAPPING
MACHINE SCREWS
TOOLS REQUIRED
B
PLASTIC CAP
BOLT
3/16" x 5/8" 5/32" x 3/4"
FLAT HEAD
MACHINE SCREWS WOOD SCREWS
METAL
3/16"-24 5/32"
2017.04
