7710 WiFi Backup Camera
I
MPORTANT: The Rampage WiFi Backup Camera is intended
only for temporary low speed use such as; hooking up trailers
or backing up/parking situa ons. It is not intended for high
speed travel and may not stay a ached to the vehicle. Please
remove before traveling at high speeds.
Operating Instructions
RAMPAGE
P
R
O
D
U
C
T
S
Advertisement
Summary of Contents for Rampage 7710
- Page 1 7710 WiFi Backup Camera MPORTANT: The Rampage WiFi Backup Camera is intended only for temporary low speed use such as; hooking up trailers or backing up/parking situa ons. It is not intended for high speed travel and may not stay a ached to the vehicle. Please remove before traveling at high speeds.
-
Page 2: Operation
Operation Overview: Use the High Strength magnets on the camera’s mount to a ach to vehicles, trailers, or anywhere there is a magne c surface available. Connect your viewing device to the camera using the built in WiFi hotspot in the camera (see “app connec on” for details). Adjust the view of the camera using the connected device as a viewer, then back up as required with an extra eyes wherever you need it. - Page 3 Charging With power switch in off posi on, connect the camera to a computer or power supply with the included USB cable. While charging, the red light next to the switch will illuminate and then shut off when it is fully charged. The camera can be operated while charging, this will be indicated by the blue light flashing and the red light staying solid.
- Page 4 connected before using the app. Connect to the cameras WiFi hotspot before opening the app (instruc ons below). For Android WiFi will connect automa cally when the app is opened. To connect to the WiFi on an iOS device: Open “Se ngs”, find the “WiFi” tab and open it, watch for a WIFI device named “...
- Page 5 camera and will con nue to record un l it is pressed again to stop. Recording is indicated by the icon being a red square instead of a circle. Videos are stored in the app’s file folder and can be played back from the app or transferred to the “Camera roll”...
- Page 6 File Access The files icon allows access to the files recorded on the device via the camera app, and allows the user to transfer the files as required for use in emails or elsewhere. Auto shut down If the ba ery voltage drops below a set point the camera will automa cally shut down.
- Page 7 App does not connect to camera: *Be sure the WiFi is connected before opening the app on iOS devices. *On Android, be sure the password is set correctly in the app and that the camera shows as connected in the Android devices WiFi connec ons screen.
- Page 8 Screen Rota on/ Image adjustment *Use the viewing devices screen lock func on with the rota on bu on in the app to hold a specific view as needed. This can help to maximize the view on the device. *Use the full screen zoom bu on to zoom on smaller screen devices. On the iOS app you can scroll around the zoomed image with your finger to see all of the available view even though it does not show all at once.
- Page 9 charged but it should be recharged at least once every few months to ensure no damage comes to the ba ery. There is a low voltage shutoff func on on the camera that automa cally shuts it down, but the switch should not be le on once the camera shuts itself off, and the camera should be recharged as soon as possible to keep from damaging the ba ery.
- Page 10 Specs: Standard: IEEE802.11b, IEEE802.11g, IEEE802.11n (1t1R Modes) Frequency Range: 2.402-2.4835 GHz Transmit Power: IEEE802.11g 12±1.5dBmChannel: 1~11, 1~13, 1~14 Modula on Mode： 802.11b DSSS (CCK, DQPSK, DBPSK) 802.11g/n OFDM (BPSK, QPSK, 16QAM) Wireless Rate 802.11 2, 1 Mbps 802.11b 11, 5.5 Mbps 802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n 150 Mbps (MAX) Opera on Mode: Ad-Hocand Infrastructure...
- Page 11 LED lamp: High power LED Image Frame Rate: 30fps (VGA) S/N Ra o: > 48DB Transmission Distance: 30 -50 meters (100’-170’) direct line of sight Working Frequency: 2.4GHz Product net weight: 126g Power: DC 5.0V (Charging via USB cable on standard USB port) Charging me: 3 hours Working me: 3-4 hours Standby me: 800 hours...
- Page 12 90 days from date of purchase. Such obligations under this warranty shall be limited to the repair or replacement, at Rampage products discretion, of any assembly or parts which, upon examination by Rampage products, Inc. proves to be defective.
