How to inspect and install a set screw on your MEC Provincial
222 Road Bike
Note: The following images show the fork without the wheel installed. You do not need to remove
your wheel to inspect for a set screw.
Inspect to see if the set screw is in place:
Set screw is in place (visible in
centre of the red circle).
If your bike looks like this, no further action
needs to be taken. Keep the enclosed set
screw as a spare.
1
The area to inspect is circled in red.
The set screw area is located on the
bottom of the fork tab, and is on the side
of the fork that doesn't have the disc
brake rotor.
Set screw is missing (empty
hole in centre of red circle).
Follow the next steps to install the set
screw.
Advertisement
Related Manuals for Mec Provincial 222
Summary of Contents for Mec Provincial 222
- Page 1 How to inspect and install a set screw on your MEC Provincial 222 Road Bike The area to inspect is circled in red. The set screw area is located on the bottom of the fork tab, and is on the side of the fork that doesn’t have the disc...
- Page 2 How to install the set screw: You will need: Set screw (enclosed with this letter) 2mm hex wrench/Allen key Note: It’s easiest to install the set screw with the front wheel removed. We also recommend that you clean the threads in the threaded hole with a cotton swab before you install the screw. 1.
