- Page 1 Mobile Imaging System Installation Procedure Part Number: 00-879039-03 April 1997 OEC Medical Systems, Inc. 384 Wright Brothers Drive Salt Lake City, UT. 84116 Used and Refurbished C-Arms are Available from www.SharpMedical.com - Call us at 800-969-9800 An Independent C-Arm Service Provider. This PDF provided for research / historical purposes only.
- Page 2 Compact / Series 7600 Installation Procedure This manual contains descriptions, instructions and procedures that apply to the Compact / Series 7600 Mobile Digital Imaging System only. Refer to the Installation Report/Checklist P/N 00-879038-03 when installing a 7600 system. Used and Refurbished C-Arms are Available from www.SharpMedical.com - Call us at 800-969-9800 An Independent C-Arm Service Provider.
- Page 3 Compact / Series 7600 Installation Procedure Revision History Dash Date Change Description Rev 1 December 1995 Initial Engineering Release Rev A December 1995 Manufacturing Release Rev B July 1996 Added power supply tolerances, kV tracking specifications, and resolution specifications Rev C April 1997 Add Series 7600 installation procedures Rev D...
- Page 4 Compact / Series 7600 Installation Procedure Used and Refurbished C-Arms are Available from www.SharpMedical.com - Call us at 800-969-9800 An Independent C-Arm Service Provider. This PDF provided for research / historical purposes only.
-
Page 5: Table Of Contents
Compact / Series 7600 Installation Procedure TABLE OF CONTENTS Introduction ........................1 Responsibility ..........................1 Safety Procedures........................1 Explosion Hazard ............................1 Electrical Safety............................2 Accident Reporting............................ 3 Unauthorized Modifications ........................3 System Specifications ....................4 Technical Specifications..........................4 System Classification ......................... 4 Connector Output Power ...................... - Page 6 Compact / Series 7600 Installation Procedure Thermal Printer / Multiformat Camera................20 Fluoroscopic Image Tests ......................21 Radiographic Beam Alignment Test ..................21 Setup ............................... 21 Beam Alignment Verification ........................21 Complete Paper Work.......................22 Used and Refurbished C-Arms are Available from www.SharpMedical.com - Call us at 800-969-9800 An Independent C-Arm Service Provider.
-
Page 7: Introduction
Electrotechnical Commission safety standard IEC-601. Do not connect any external device to the system that does not meet the requirements of IEC-601. Only devices provided by or approved by OEC Medical Systems, Inc. should be connected to the system. Explosion Hazard Never operate the system in the presence of flammable anesthetics or other flammable or explosive liquids, vapors, or gases. -
Page 8: Electrical Safety
Compact / Series 7600 Installation Procedure If flammable substances are present before you apply system power, do not plug in or turn on the system. If you detect flammable substances after the system has been turned on, do not touch any of the controls, switches, knobs or cables. Evacuate all personnel immediately, then ventilate the room to clear the air of the flammable vapor or gas. -
Page 9: Accident Reporting
The malfunction does not lead the manufacturer to undertake a remedial action involving any other systems. For OEC Medical Systems, Inc. to meet these reporting requirements, all users of these systems, operators, and service technicians, must provide the QA Manager of OEC Medical Systems, Inc. with the following information regarding all reportable events as soon as possible: Identify the model and the serial number. -
Page 10: System Specifications
Compact / Series 7600 Installation Procedure System Specifications Technical Specifications The policy of OEC Medical Systems, Inc. is one of continual product development and improvement. For this reason, OEC Medical Systems, Inc. reserves the right to change the operating characteristics and specifications of newer products at any time, without prior notice, and without incurring any obligation relating to previously manufactured items. -
Page 11: Input Power
Input Power NOTE: The system operating voltage is changeable. If the operating voltage requires changing, the change may only be accomplished by an OEC Medical Systems, Inc. field service technician, or by qualified technical service personnel. Line Frequency: 60/50 Hz... -
Page 12: X-Ray Source Assembly
Compact / Series 7600 Installation Procedure X-ray Source Assembly Type Fixed anode type Focal Spot Dual, 0.6 mm and 1.5 mm Total Filtration >3 mm minimum aluminum equivalent Anode Heat Storage Capacity 76,000 HU Leakage Technique Factors 110 kVp and 3.0 mA Voltage Rating 110 kVp maximum Fluoroscopy... -
Page 13: Radiography
Compact / Series 7600 Installation Procedure Radiography 1.5mm Focal Spot High voltage range: 36 kVp to 110 kVp Tube current 20 mA fixed. Timer Duration of radiography can be manually set from 0.1sec to 4.0 sec with an internal electronic timer. -
Page 14: Dimensions
Compact / Series 7600 Installation Procedure Stability Positive stability on grades up to 10 degrees when in transport position and on grades up to 8 degrees in any position of normal use. Altitude 8,000 ft. (2438 meters) maximum Humidity Operating: 20 to 80%, non-condensing Storage and transport: 10%-90%, condensing Shock and Vibration 1G at 5-200 Hz for 2 hours Dimensions... -
Page 15: X-Ray Generator Information
Compact / Series 7600 Installation Procedure X-ray Generator Information The X-ray Generator in the Compact / Series 7600 complies with IEC 601-2- 7/1987 and CSA 22.2 #601.2.7. The following information provided in accordance with these standards. Reference: 601-2-7 Clause 6.8.2 Maximum mA @ Nominal kVp Standard Fluoro 3 mA @ 110 kVp... -
Page 16: Unpacking And Inspection
If any part of the shipment shows damage or parts are missing, immediately notify the carrier and the nearest OEC Medical Systems, Inc. regional service office. Retain the shipping container and packing material for the carrier's inspection. -
Page 17: Installation
Compact / Series 7600 Installation Procedure Installation As you perform the steps in this procedure check them off on the Installation Report/Checklist P/N 00-879038-02. Additional information needed for operating the Compact / Series 7600 found in the Operator Guide’s. Site Requirements There are three major considerations for installing a system. -
Page 18: Cover Removal
Compact / Series 7600 Installation Procedure Cover Removal C-Arm Rear Cover Unplug the system power cord from the AC power receptacle. Remove the two screws located on the lower front section of the rear cover and the screw located on each side of the cover. Move the cover toward the floor. -
Page 19: Line Voltage Compatibility Check
Turn the system on by pressing the green START button on the control panel (Compact / Series) or workstation (Series). The system will display the OEC test pattern on the monitors when the system has initialized. Verify that the elapsed time indicator operates on the generator. -
Page 20: System Power Supply Voltages
Compact / Series 7600 Installation Procedure System Power Supply Voltages The power supplies reside in a perforated metal enclosure on the left side of the generator cabinet. There are two separate power supplies (Compact) and one (Series) in the enclosure. Locate the output voltage wire bundle coming from the top power supply (NG1). -
Page 21: System Operational Verification
Compact / Series 7600 Installation Procedure System Operational Verification Generator min s PRINT Press the C-Up and C-Down buttons and verify that the C-arm lifts smoothly from the top to the bottom limits. Press the Auto Fluoro button and verify that the LED illuminates. Press the x-ray button and verify that the kV automatically servos by monitoring the kV display and that an image appears on the monitor. - Page 22 Compact / Series 7600 Installation Procedure Press the Manual Fluoro button and then the kV button and verify that the LED illuminates. Press the kV-up/down button and verify that the kV can adjust from 40kV to 110kV. Press the Film button and verify that the LED illuminates. Press the Film Timer-up/down button and verify that you can select a time from 0.1 sec.
- Page 23 Compact / Series 7600 Installation Procedure 13. Place some lead aprons on the image intensifier to attenuate the beam. Press the Thorax Surgery button and verify that the LED illuminates. 14. Press the Hand Surgery button and verify that the LED illuminates. Take an x-ray and verify that the field size automatically decreases because the iris collimator closes partially.
-
Page 24: Workstation
Compact / Series 7600 Installation Procedure Workstation " ’ ALT CTRL > SPACE SPACE TEXT Print Press the Auto Windowing button 51/30 to turn on/off the auto windowing function. If you turn off the auto windowing you can activate the manual window function by pressing the Shift button 53 at the same time as the auto windowing button. - Page 25 Compact / Series 7600 Installation Procedure Press the Zoom button 62 to digitally magnify the image four times. Press the Edge Enhancement button 63 to sharpen edge definition. Once you apply sharpen it remains. Sharpen will not toggle. Press the Image Negate button 66 to reverse the display of light and dark values in an image.
-
Page 26: Thermal Printer / Multiformat Camera
Compact / Series 7600 Installation Procedure 11. Press the Exchange Image button 65 to toggle the images between monitors. 12. Press the Shift 53and Text 57 buttons at the same time to enter patient data. TEXT 13. Press the Backspace 59, the Space 60 and Return 61 to manipulate the patient data. -
Page 27: Fluoroscopic Image Tests
Compact / Series 7600 Installation Procedure Fluoroscopic Image Tests Select AUTO FLUORO mode. . Ve rify that the kVp tracks up and down during X-rays as material thickness increase and decrease per the ranges below: FILTERS kVp RANGE 1 Copper Filter 59-65 2 Copper Filters 70-76... -
Page 28: Complete Paper Work
Distribute the copies of the FDA form 2579 to the appropriate individuals as outlined on page 1. Return the Installation Report/Checklist to OEC immediately. Used and Refurbished C-Arms are Available from www.SharpMedical.com - Call us at 800-969-9800 An Independent C-Arm Service Provider. This PDF provided for research / historical purposes only.
