- Page 1 M o n o c u l a r D i g i t a l D a y / N i g h t V i s i o n W i t h 8 X Z O O M O p e r a t or In s tru cti ons 1-NV3-B / 1-NV3-C CERTIFIED...
-
Page 2: Table Of Contents
Contents Overview..................1 Operating Hints................1 Components ................. 2 Operating Instructions ..............3 Battery Installation ..............3 Power On .................. 3 Power Off .................. 4 Icons Description ................4 Scenery Observation ..............4 Brightness Adjustment ..............5 Brightness Adjustment ............. 5 Adjustment for Illumination............ -
Page 3: Overview
• The viewing distance in a low light environment is 200 meters (650 ft) The PhaZZer NV3 can be used during the day or at night. If the light is too strong during the day, it will get a better visual effect when the objective lens shelter is on. -
Page 4: Components
transducer. If there is any light source, such as streetlamps or moon- light, the infrared illuminator does not need to be turned on. You can adjust the focal length of the objective lens and the screen brightness to achieve a clear image. Components 1 2 3 4 5 6 7... -
Page 5: Operating Instructions
15 - DOWN Check Operating Instructions Battery Installation The PhaZZer NV3 Day/ Night Vision Monocular comes equipped with a 16340mAh lithium-ion battery. To unscrew the battery cover, turn counterclockwise. Insert the battery with negative electrodes bottomed, and then tighten the battery cover clockwise. -
Page 6: Power On
Long press the” Power/OK” Switch (button#13) for 3 sec- onds while looking through the Eyecup (Image #10) The monocular is on when the screen displays the lightened PhaZZer Screen and icons are shown. (Please refer to Picture 1). The monocular is now in still photo/view mode. Power Off In any mode, long press the “Power/OK”... -
Page 7: Brightness Adjustment
• Adjust the objective focus wheel (image #1) to get the sharpest image The Automatic fine-tuning control, that is operated by the viewer, will adjust according to the average brightness of the central focal point. Digital zoom is implemented by pressing the “+” (Up but- ton #12) and “-“... -
Page 8: Screen Brightness And Infrared Illuminator Adjustment
Press the “+” (Up button #12) or the “–“ (Down button #15) to adjust the infrared illuminator ranged from 0 to 9 (9-lightest, 0-turn off). Once appropriate brightness is achieved, the auxiliary light adjustment mode will auto- matically shut off after 3 seconds. Screen Brightness and Infrared Illuminator Adjustment Picture 2... -
Page 9: Photo Shooting
Don’t block the auxiliary light when it is turned on. Photo Shooting The PhaZZer NV3 Day/Night Vision Monocular enters the photo/view mode automatically after powering the device on. (Picture 1). You can observe the scenery or take still photos. -
Page 10: Time/Menu Setting
#14) to use the playback function. In the playback mode, press the “+” (Up button #12) and the “-“ (Down button #15) to choose the photos and videos for playback. When you have located the photos or video to playback, press the “Power/OK “... -
Page 11: Menu Descriptions
(button #13) to enter, and press “Power/OK” (button #13) when setting is done. Short press “M” (Mode button #14) to exit the menu setting mode. Menu Descriptions Menu Optional Tips Options Choices White Auto/Sunlight/ Select due to different Balance Cloudy/ weather conditions. -
Page 12: Pcs Connection
PCs Connection PCs Connection The PhaZZer DV3 Day/Night Vision Monocular is equipped with a USB 2.0 interface. Connect the viewer to the computer by inserting the USB cable into the com- puter port. The battery is charging when the monocular connects with your PC. -
Page 13: Auto Power Off/Power Management
Please charge the battery for at least 10 hours before first time use. External Power The PhaZZer DV3 Day/Night Vision Monocular is equipped with external power. It can be charged through the USB interface, or by a standard mobile charging source. -
Page 14: Basic Parameters
The battery will also charge when the monocular connects to an external power source. Basic Parameters Menu Optional Choices Tips Options Optical Magnification Performance Dimension of Objectives φ35mm 7°x5.25° Ocular Adjustable ±0.5 Range Observing Distance 2m~∞ (Low Light Environment) Digital Sensor Performance Illumination... -
Page 15: Configuration Standard
Configuration Standard Basic Parameters Power Operating Voltage 3.7V DC Replaceable Rechargeable lithium-ion Battery battery, 16340mAh Charging Source 5.0V/700mA Adapter Other Measure- 178x72x78mm ment(L*W*H) Weight 300g Package Content Items Amount Objective Lens Shelter External Power Adapter USB Cable NV1-535 Monocular Pouch Shoulder Strip Hand Grip Strip 16340mAh lithium-ion Battery... -
Page 16: Operating Environment And Others
Operating Environment and others Keep the PhaZZer DV3 Day/Night Vision Monocular in it’s soft pouch when not in use. Operating temperature range is -5~40°C. Relative humidity is 80%. In order to avoid the wetness and mildew, please store the device in a clean and dry environment and avoid high pressure, mechanical damage, humidity and solar radiation. - Page 17 CERTIFIED Arthur Evelyn Bldg Suite 5, Main St. Charlestown, Nevis. www.PhaZZer.com (402) 881-1117 • Sales@Phazzer.com...
