Chrome electric heated towel rails
measurements and installation instructions
SNUG COMPLETE - SERIES
Snug Complete - 500
90mm
500mm
CL
CL
70mm
Snug Complete - 500
200mm spacing
440mm
* Height: 1000mm
from centres
* Width: 500mm Centre to Centre
*Element 100 watt bottom bracket
*Bottom Rung / Hard Wire Attachment
32mm
440mm
19mm
70mm
Snug Complete - 700
700mm
90mm
CL
CL
70mm
Snug Complete - 700
200mm spacing
440mm
* Height: 1000mm
from centres
* Width: 700mm Centre to Centre
*Element 150 watt bottom Bracket.
*Bottom Rung / Hard wire Attachment
440mm
32mm
19mm
70mm
THE SNUG RANGE OF TOWEL RAILS IS MANUFACTURED EXCLUSIVELY FOR ROGERSELLER BY HYDROTHERM AUSTRALIA PTY. LTD.
HYDROTHERM AUSTRALIA PTY. LTD . 96 COMMERCIAL DRIVE THOMASTOWN, VIC. 3074 Ph.(03) 9464 4622 F.(03) 9464 4722 www.hydrotherm.com.au
CERTIFICATE OF SUITABLILITY NO. 89383V. AUSTRALIAN IP 55 ELECTRICAL RATING.HYDROTHERM TOWEL RAILS HAVE A REGISTERED DESIGN.
Advertisement
Related Manuals for ROGERSELLER Snug Complete Series
Summary of Contents for ROGERSELLER Snug Complete Series
- Page 1 19mm 70mm THE SNUG RANGE OF TOWEL RAILS IS MANUFACTURED EXCLUSIVELY FOR ROGERSELLER BY HYDROTHERM AUSTRALIA PTY. LTD. HYDROTHERM AUSTRALIA PTY. LTD . 96 COMMERCIAL DRIVE THOMASTOWN, VIC. 3074 Ph.(03) 9464 4622 F.(03) 9464 4722 www.hydrotherm.com.au CERTIFICATE OF SUITABLILITY NO. 89383V. AUSTRALIAN IP 55 ELECTRICAL RATING.HYDROTHERM TOWEL RAILS HAVE A REGISTERED DESIGN.
- Page 2 INSTALLING BRACKETS Slide the WALL BRACKET into the BRACKET ARM and hold up to the wall in position. With a pencil, outline the WALL BRACKET in the desired position and remove from the wall. Using a pencil and the WALL BRACKET , mark the centre screw hole and cross it for accuracy.
- Page 3 HARD WIRING Hydrotherm recommends that all hard-wired heated towel rails be connected to a light switch or digital timer. Connecting hard-wired heated towel rails to a light switch or a timer will prolong the life of the electric element and reduce energy consumption. CHANGING ELEMENTS To change an element from one side to the other, or to replace an old element is a very simple process.
