Summary of Contents for SereneLife PSLCLM60
- Page 1 USER’S MANUAL LAWN MOWER PSLCLM60...
-
Page 3: Intended Use
Safety Button Battery Pack Switch Lever Safety Key Handle Knob Power Cord for Charger Cable Clip Charger Battery Cover Battery Temperature Indicator Height Adjustment Lever Battery Power Indicator Upper Push Bar Switch Button for Indicator Grass Collection Indicator Mulching Insert Grass Collection Bag Quick Fold Lever INTENDED USE... - Page 4 • Never allow children or people unfamiliar with these instructions to use the lawnmower. Local regulations may restrict the age of the operator. • Never mow while people, especially children or pets, are nearby. • The operator or user is responsible for accidents or hazards occurring to other people or their property. •...
- Page 5 • Protect the battery charger from rain and moisture. The penetration of water in a battery charger increases the risk of electric shock. • Recharge only with the charger supplied by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
- Page 6 2. Securing cable by using cable clips Fig. 3 Secure the cable from the motor to the switch assembly by using four cable clips-two is fixed on upper push bar, the other one Is fixed on lower push bar. See Figure 3 3.
-
Page 7: Operation
Using the height of cut between 25mm to 35mm will further shorten the battery duration. OPERATION 1. Tips for the use of this battery-powered mower Under normal conditions, the battery should run for approximately 30 minutes per single charge the operation time and the area that can be mow by this battery-powered mower is dependent on various factors, These are: Fig. - Page 8 2. Charging and caring for the battery Important: Before charging the battery, read all instructions and warning markings in this manual and on your mower, Do not operate your mower until you have read and understand all instructions and the bat- tery has been fully charged.
- Page 9 Important: Always connect the charger to the battery first, and then plug it into the wall outlet. When unplugging, reverse the process: unplug the charger from the wall outlet first and then disconnect it from the battery. Charging the battery inside and outside the mower Figure 9-10 1.
- Page 10 4. Starting and Stopping Attention! Rotary cutter blade, The blade continues to rotate for a few seconds after the ma- chine is switched off. Allow the motor/blade to stop rotating before switching “on” again. Do not rapidly switch off and on. Starting Figure 11 Before start make sure the battery pack was put into the mower and put the safety key into its socket.
- Page 11 Fig. 13 Figure 13 Instructions for mowing without the grass collection bag We recommend: • The grass should not be too high nor too wet! • Mow slow while mowing. • Do not cut grass more than 20mm (see Fig. 16) Mowing tips: If grass residue is left in the discharge opening, pull mower backwards about 1-2m so that the grass resi- due can drop out downwards.
- Page 12 • One green light goes on, low battery capacity • Two green light goes on, mid battery capacity • Three green light goes on, full battery capacity • Red light which show the battery temperature lights on, battery temperature was too high, please wait until the red light off , then start charging process again.
- Page 13 2. Removing and Attaching the Blade You must remove the blade to sharpen it, or to change to a spare blade. Always check the blade for sharpness, damage, and tightness before and after each use. Replace the blade promptly if it has been bent or damaged. Only use spare blade from manufacturer. Fig.
-
Page 14: Troubleshooting
Balancing the Blade Attention! When sharpening a used blade, be especially careful to keep it balanced. If in doubt, replace the blade with a new one. An out-of-balance blade cause your machine to vibrate excessively. Excessive vibration may cause damage to the Mower, especially to its motor. - Page 15 Problem Possible Cause Corrective Action Safety key removed from battery Put safety key into battery power power socket socket safety key has been put into the Take out safety key and put it into socket,but the connection is not the socket again, to ensure the tight and secure plugging tight and secure Battery discharged...
- Page 16 Problem Possible Cause Corrective Action The blade may be loose Remove the safety key from the socket,, and remove battery, turn the mower over on the right side, and check that the blade is tightly attached or not, if not, tighten the blade.
- Page 17 Problem Possible Cause Corrective Action The mesh holes on the collection Clean the collection bag bag are clogged Collection bag is collecting grass The collection bag is wet. Allow the collection bag to dry poorly thoroughly before using it again. LAWN MOWER FEATURES AND SPECIFICATIONS Features: •...
