- Page 1 WIDO V1 PRO ELECTRIC FOLDING ALL TERRAIN BIKE USER GUIDE MODEL: EBIKE1 V1.0 (2019) WARNING: FOR YOUR OWN SAFETY AND THAT OF YOUR EQUIPMENT, MAKE SURE TO READ THIS MANUAL AND TAKE THE PRECAUTIONS DETAILED. FAILURE TO FOLLOW WARNING NOTICES AND...
-
Page 3: Table Of Contents
WIDO V1 PRO - USER GUIDE CONTENTS CONTENTS | 3 SAFETY INFORMATION | 4 GETTING TO KNOW THE BIKE | 6 ASSEMBLY / UNFOLDING YOUR BIKE | 8 FOLDING YOUR BIKE | 10 BIKE SPECIFICATION | 11 BATTERY & CHARGING | 11... -
Page 4: Safety Information
• Don’t lend your bicycle to anyone who is unfamiliar with it. If you choose to loan your Wido bike to anyone, make sure they have also read and fully understand this owner’s manual. •... - Page 5 If In doubt, please contact the Wido support team. If you have any further questions about the operation of this Wido e-bike, please consult your local e-bike dealer or contact the Wido support team who will be happy to help.
-
Page 6: Getting To Know The Bike
GETTING TO KNOW THE BIKE... - Page 7 WIDO V1 PRO - USER GUIDE KEY COMPONENTS Saddle Seatpost Seatpost quick release Disc brake Tire Spoke Motor Cassette Rear derailleur Chain Handlebar lock mechanism Pedal Crankset Charging hole Key for battery lock Display/control panel Handlebar Brake lever Handlebar stem...
-
Page 8: Assembly/Unfolding Your Bike
UNFOLDING THE HANDLEBAR Straighten the handlebar stem (19) until it is perpendicular to the ground and lock the handlebar locking mechanism (11) in place with a few twists. The Wido V1 Pro handlebar is a fixed height handlebar. IMPORTANT: Make sure the handlebar stem fits tightly into the handlebar locking mechanism, and is securely fastened. - Page 9 WIDO V1 PRO - USER GUIDE UNFOLDING THE BIKE If the bike is already folded, follow these steps to set it up for use. Ensure that the battery pack is secure, locked and will not slide out of the battery compartment (for more information see section ‘Battery &...
-
Page 10: Folding Your Bike
FOLDING YOUR BIKE A great feature of this product is that it can be conveniently folded for easy transportation, fitting into cars and onto public transport for example. Folding your bike is relatively easy but if in doubt, we recommend you take your bike and & manual to a local bike shop for further instructions. -
Page 11: Bike Specification
WIDO V1 PRO - USER GUIDE BIKE SPECIFICATION Motor: Rear wheel 250W brushless motor Battery: Samsung 36V 14Ah Max speed: 15mph/24kmh Battery range: Up to 60 miles Bike weight with battery: 25kg Bike dimensions: H107 x W62 x L161cm Bike dimensions when folded: H70 x W45 x L90cm Wheels: 20”... - Page 12 IMPORTANT: Do not charge the battery with any chargers other than the one supplied with your Wido bike. Failure to do so may result in battery damage. Follow all instructions provided with the charger supplied with your bike. Failure to do so could result in damage to your battery or could create a fire hazard that could cause you serious injury.
- Page 13 WIDO V1 PRO - USER GUIDE REMOVING THE BATTERY FROM THE BIKE: Simply remove the battery from the frame as explained earlier in this section and plug the charger into the battery. CHARGING TIMES: With standard charger (2.0 A) : between 4 to 6 hours* * Depends on current battery usage level, climate conditions, earlier charging cycles.
-
Page 14: Bike Display Panel
BIKE DISPLAY PANEL The bike display panel should appear as shown: The power button is used to turn the motor on/off. To switch on, press once and to turn off, hold down the power button. MODE Pressing ‘MODE’ will increase or reduce the motor power and how much your pedalling is assisted. - Page 15 WIDO V1 PRO - USER GUIDE SADDLE TILT POSITION To tilt the saddle to the right position, move the saddle more forward/rearward or adjust the nose of the saddle to point slightly upward/downward - loosen the nut/screw located under the saddle, at the top of the seatpost (2). Once loose, move the saddle to your ideal position.
-
Page 16: Ride Checklist
RIDE CHECKLIST Check that the seatpost is tightly fastened. Check that bolt of saddle is tight. Check that the handlebar is tightly fastened. Check that handlebar locking mechanism is tightly fastened. Check that the bike folding/lock mechanism for the frame and its clips are tightly fastened. Check that all other bolts and fasteners are tight, such as for kickstand and motor. -
Page 17: Product Replacement
WIDO V1 PRO - USER GUIDE 3 MONTH CHECKLIST: Check the wheels and tyres, check that everything on the bike is tight and in good condition. Check the wear on the brake pads, adjust the tension if necessary and check the effectiveness of the brakes. -
Page 18: General Tips
GENERAL TIPS It is recommended to take your bicycle for a full tune-up and maintenance check by a bicycle mechanic on a regular basis. While your bike is rain and splash-proof, their electrical components should NEVER be submerged in water. To prevent corrosion, dry the bicycle and its components after every wet ride. - Page 19 WIDO V1 PRO - USER GUIDE Always charge the battery after any use. Always charge the battery indoors. Keep the battery away from water wherever possible. Do not disassemble or modify the battery Do not expose the battery to fire or extreme temperatures.
-
Page 20: Troubleshooting
TROUBLESHOOTING A. Top speed too slow: Fully recharge battery Check weight doesn’t exceed limit stated Check terrain - is it too bumpy? B. Power on but motor not working: Reinstall battery & check it is inserted correctly. Replace fuse Please contact customer services C. -
Page 21: Contact
WIDO V1 PRO - USER GUIDE H. Motor not working effectively: Check the power has been switched on Check that the battery is properly inserted Check the battery is fully charged Check that any cables and connections haven’t become twisted/trapped. -
Page 22: Declaration Of Conformity
Wido Ltd. Units 5A-5B Bestwood Business Park Nottingham NG6 8TQ TECHNICAL DATA Description: Wido V1 Pro E-Bike Model: EBIKE1 DOCUMENTATION We declare that this product conforms to the following product legislation in accordance with the following directives: EMc directive 2014/30/EU... - Page 23 WIDO V1 PRO - USER GUIDE...
- Page 24 Wido Ltd. NG6 8TQ wido.com...
