- Page 1 Franklin Autoswing Installation Manual...
- Page 2 UNIPRO. The Control unit is anyone in your area familiar with the Franklin Autoswing. resulting from failure to observe Good Technical completely supports the EELINK protocol. Its main Practice when constructing closing structures (door, Real Carriage Door &...
-
Page 3: Table Of Contents
Table of Contents • Keep the photocell optical components and responsible for any damage resulting from failure luminous signal indication devices clean. Check to observe the installation standards and the that the photocells are not obscured by branches or instructions contained in the present manual. System Overview ..............6 shrubs. -
Page 4: System Overview
System Overview Specifications • Surge protection and a dedicated circuit are encouraged Franklin Autoswing Installation Manual A. Control Unit Housing The below drawing is an example of typical B. Left Motor component placement and wiring. C. Right Motor Typical System Overview ... -
Page 5: Igea Motor Installation
Moun�ng the Control Housing 1. Install the limit‐switch refernce cams as shown in g. 3. Install the full cam on top of 1. Locate the control housing containing the LIBRA‐UL‐R panel. the metal sha�, then install the ring cam on Franklin Autoswing Installation Manual FULL CAM RING CAM top of the full cam. Do not fully �ghten the 2. For moun�ng, the rear of the housing must be predrilled. Refer xing screws. to g. 5 for the loca�ons of the holes to be drilled. Installa�on of Motor (Con�nued) 2. When the door is fully open, rotate the Igea Motor Installation 3. At this �me, plan where you would like to run the wiring into corresponding cam (g. 4), un�l you hear a solid header and/ 12. Repeat these steps for the other leaf, if installed 2. -
Page 6: Mounting The Control Unit
Installation Manual Franklin Autoswing Installation Manual ra�on Mode Franklin Autoswing Installation Manual Manual Opera�on Mode Manual Opera�on Mode Mounting c�on, manual opera�on mode can be carried out Manual Operation Mode cannot be used manually to release the motor. To 2. At this time, plan where you would like to run the onalized key. ... -
Page 7: Wiring Simplified
Warning! Jumper Wiring Simplified wire from 70 + 72 must be removed Motor 2 is the door that will open last and close once photo eyes first. For dual motor installations this will be your second motor. Motor 2 output terminals are 14 and are wired into the Motor 1 is the door that will open first and close 15, and the limit input is terminal 43... -
Page 8: Autoset Programming For Quick Setup
• Press [OK] Autoset is complete you can move on to Step 2. The Franklin Autoswing comes “out of the box” 6. After selecting your preset, the screen will • Change value to 5 to ignore photo sensors on... -
Page 9: Programming Features
• Press [OK] Auxiliary the wrong motor wired into 10, 11, and 42, and Range Value Function Description will need to switch the motor wiring (the 2nd for IC1 and IC2 Adjust the value as needed Outputs door is 14, 15, and 43). OPEN Open only. - Page 10 and SAFE 3, both are provided with optional Termi- Name Descrip- Default Notes Range Value Function Description Range Value Function Description supervision circuit FAULT 2 and FAULT 3 tion for “Aux 3” PHOT OP TEST Same as Safety Com- above. Re- All 3 safety inputs are normally closed (N.C.) Door open Output activate...
-
Page 11: Installing Wired Wall Button
Installing Wired Wall • Screw in two flat head wood screws (2) and Range Value Function Description Range Value Function Description tighten firmly by hand. BAR OP TEST Same as SHADOW Safety loop in- above. Re- put. If the con- Button 5. -
Page 12: Additional Remotes
Programming (polarity proof connection) • “PARAM” will appear on the display • Tighten both screws (2) and (3) Press the [–] button one time Additional Remotes • Using pliers, break out the cable pass through • The display will show “LOGIC” (1) or (2) in the button frame (3) 4. -
Page 13: Optional Accessories
Optional Accessories Homelink Programming Wireless Outdoor Keypad With an outdoor keypad you enjoy secure exterior access to your doors without a remote. Operates up to 10 doors. Wireless Wall Button This upgraded wall button is wireless, so no wiring is necessary for installation. Operates up to 4 doors. ECOSOL Solar Power Get your garage door off the grid with Ecosol solar conversion. -
Page 14: Wireless Wall Button
Wireless Wall Button Outdoor Wireless • WITHOUT RELEASING P1, when the LED lights up, press & hold P2 for 10 secs. Keypad • Release both buttons. LED will flash 6 times indicating memory deletion. Note: Please see manufacturer instructions for assembly Programming to the Thalia Board 4. - Page 15 Wi-Fi Hub • Press [OK] 5. Remove the jumper off both legs and reinsert the appropriate location on onto one leg the control board • Red LED light will be fixed and green LED will Programming blink 6. Insert batteries and start over with instructions 7.
-
Page 16: Wi-Fi Hub
Full Programming Confirm pairing by click “Proceed” (Fig. I) Menu for the Thalia • Confirm successful pairing by clicking “Ok” (Fig. J) Control Board Navigating the Controls Note: Any incorrect FI_00xxxxxxxxxx (Fig. D) Wi-Fi network data Press [OK] twice to get into the programming menu entry makes it necessary to reset the WI-FI HUB, “HALT”... - Page 17 Main Selec- Description Range Main Selec- Description Range Main Selec- Description Range Main Selec- Description Range tion fault tion fault tion fault tion fault PARAM> OPEN Motor 2 open- 0-10 PARAM> OP. Percentage of 1-99 LOGIC> STEP- Determines LOGIC> IBL TCA Ignores the DELAY ing delay in...
-
Page 18: Additional Safety Devices
Additional Safety Main Selec- Description Range Main Selec- Description Range Main Selec- Description Range tion fault tion fault tion fault Devices LOGIC> SAFE 1 * Configuration 1 & 5 LOGIC> RADIO Quick remote LOGIC> TRAFFIC Ignores the of safety input PROG programming. -
Page 19: Battery Backup
as a template. The disk should be 8” in diameter, with a 1‐7/8” diameter hole cut out of the center. 2. Set the disk on your assembled lever arm as show below. You will not need the motor or base plate. With your door leaf in the fully open posi�on (approx 105 degrees), move the disk along the wall and door coupling along the door un�l you achieve the dimensions at right. For best results, the straight leg of Battery Backup Arched Door 4. Split the two neutral (white or grey) wires For best results, the the lever arm should be as close as possible to the running from the transformer to the controller arched jamb (1/2” min) . straight leg of the board (top two wires on JP30) lever arm should be 3. ... -
Page 20: Error01 Troubleshooting Guide
Error01 Troubleshoot- Manufacturer’s Step by Step Guide for Error01 1. Check fuses ing Guide 2. Check power on 50-51 3. If there is power there, TEMPORARILY move all photo beam power leads to 50-51 If you experience an issue during the Autoset and 4. - Page 21 15. Put your meter on 50-52 to measure ac voltage. About Us Order Today 16. When auto set counts down 3…2…1… right after Real Carriage Door & Sliding Hardware is To order please call us at 800.694.5977. Our 1, power should turn on and off at 50-52 testing committed to excellence in creating high quality experienced designers are ready to help you find the photo beams and if they pass the test...
- Page 22 Please visit our website and download our most up to date manual. Call us directly at 1(800)694-5977 for additional assistance.
