Right Hand Arm Assembly with Toilet Roll Holder
Fig. 1
1. Toilet roll holder comes fitted to the right hand side, however can be swapped to the left hand
side if required.
Button Removal
Button
Fig. 2
2. Unclip button with small flat bladed screwdriver. Remove button and springs. Remove two (2)
phillips head screws.
Screw
Spring
Press here
to remove button
CARE ARMREST
TOILET ROLL INSTALLATION INSTRUCTIONS
PLEASE READ CAREFULLY BEFORE INSTALLATION
Screw
Page 1 of 2
