- Page 1 PLASMA CUTTING MACHINE HOMER Plasmacut 39 OPERATING MANUAL ALFA IN a.s © www.alfain.eu Homer Plasmacut 39 manual EN 03...
-
Page 2: Table Of Contents
2/17 CONTENT INTRODUCTION ..................3 SAFETY INSTRUCTIONS AND WARNINGS ........... 4 CONDITIONS OF USE ................7 TECHNICAL DATA ................... 8 MAIN PARTS OF THE MACHINE ............9 ACCESSORIES ..................10 GETTING STARTED ................11 CUTTING ....................13 MAINTENANCE ..................15 10. -
Page 3: Introduction
Machine HOMER Plasmacut 39 is designed for cutting metal on the basis of modern technology cutting material through a thin beam plasma gas. -
Page 4: Safety Instructions And Warnings
4/17 2. SAFETY INSTRUCTIONS AND WARNINGS 1. OPERATION AND MAINTENANCE OF PLASMA ARC EQUIPMENT CAN BE DANGEROUS AND HAZARDOUS TO YOURHEALTH. 2. Plasma arc cutting produces intense electric and magnetic emissions that may interfere with the proper function of cardiac pacemakers, hearing aids, or other electronic health equipment. - Page 5 5/17 processes. You must be very careful when cutting or welding any metals which may contain one or more of the following: Antimony Chromium Mercury Nickel Cobalt Arsenic Barium Copper Selenium Silver Beryllium Lead Cadmium Manganese Vanadium Always read the Material Safety Data Sheets (MSDS) that should be supplied with the material you are using.
- Page 6 6/17 contact, is the open-circuit voltage between the clamps. In our generator this voltage is 260V. The maximum open-circuit voltage of the plasma machines is established by national and international standards (EN 60974-1) depending on the type of current to be used, on its waveform and on the hazards arising from the work place.
-
Page 7: Conditions Of Use
7/17 RISK OVERVIEW 1. Risk of electric shock 2. Ultraviolet light and light radiation 3. Risk of inhaling gas fumes and dust particles 4. Burns 5. Noise NOTE 1. It is forbidden to operate a machine with damaged insulation of the cutting torch or supply cable. -
Page 8: Technical Data
8/17 c. Draft and any ventilation of neighbouring machine d. Excessive overloading - crossing technical parameters e. Rough handling ELECTROMAGNETIC COMPATIBILITY The welding device is in terms of interference designed primarily for industrial areas. It meets the requirements of EN 60974-10 class A and it isn’t designed for using in residential areas, where the electrical energy is supplied by public low-voltage power supply network. -
Page 9: Main Parts Of The Machine
9/17 Weight (including torch) 5. MAIN PARTS OF THE MACHINE FRONT AND REAR PANELS Fig. 1 – Main parts of the machine Pos. Description LED indicator – when illuminated, the machine is ON LED indicator. If the LED illuminates the thermo-switch is disconnected. -
Page 10: Accessories
10/17 6. ACCESSORIES CONTENT OF DELIVERY 1. Torch Plasma SCB50 Homer 4 m 2. Earthing cable 3. Operating manual ON REQUEST Pos. Code Description SCB50-40-M16X1.5 Torch Plasma SCB50 Homer 4 m (substitute) P166 Circle Cutting Attachment SCB50 4801 Adapter hoses for filter AT 1000... -
Page 11: Getting Started
Note – the bold items are equipped on the torch Recommended starting kit for the Torch SCB 50: Pos. Code Description 6096 Starting Kit for SCB50 Homer 4 m Content of starting kit 6096 P1521-Hf Electrode Hafnium SCB50 Electrode Hafnium Extended P1518-Hf... - Page 12 8. No additional oiling if the pressure air is permitted. That could damage the plasma machine and the cutting torch. OPTIONAL AIR FILTERS FOR HOMER PLASMACUT 39 To achieve high quality cutting and to avoid serious disturbances to the torch it is highly advised to include the air filter.
-
Page 13: Cutting
13/17 8. CUTTING 1. Move the torch to the material and press the torch trigger. The arc will ignite. 2. Start with cutting. After end of cutting release the torch trigger, the arc turns off and for 30 seconds the air will flow to cool down the torch. 3. - Page 14 7. In case of low air pressure or disconnected air input never press the torch trigger. It can cause the torch damage. 8. HOMER Plasmacut 39 is adapted for use with torch SCB 50. This combination comply with EN 60974-7 Article 10.1.4. Using any other type and design of a torch must be approved by ALFA IN a.s.
-
Page 15: Maintenance
If the cable bundle of the torch is worn out it must be replaced immediately - danger of electrical shock. 2. Disconnect the HOMER from the mains supply voltage before disassembling. 3. Special maintenance is not necessary for the control unit parts in the plasma cut machine. -
Page 16: Statement Of Warranty
16/17 skills enabling that person to safely carry out a risk assessment and repairs to the electrical equipment in question. 8. The person carrying out the servicing needs and repairs must know what to look at, what to look for and what to do. STATEMENT OF WARRANTY 1. -
Page 17: Disposal
17/17 DISPOSAL Only for EU countries. Do not dispose of electric tools together with household waste material. In accordance with European Council Directive 2002/96/EC on electrical electronic equipment waste implementation in accordance with national law, electric tools that have reached the end of their service life must be collected separately and returned to an environmentally compatible recycling facility.
