Table of Contents
1)
Introduction ........................................................................................................................ 1
Supported Hardware .............................................................................................................. 1
Firmware Requirements .......................................................................................................... 1
2)
Fuse Kit Installation ............................................................................................................. 2
3)
Installing the TT100 on the Trailer ...................................................................................... 3
TT100 Transmitter Installation ................................................................................................ 3
Refrigeration Unit Connection ................................................................................................ 4
1) Introduction
The Tethered Trailer Tracks (TT100) mobile communication terminals system is an option that
allows dispatch to monitor trailer connects and disconnects. Connects and disconnects are
detected by the IVG or MCP (except MCP50) and passed on to the host with the date, time,
and location. The Trailer Tracks system can also monitor the refrigeration unit of a trailer. This
feature works as an early warning system should the trailer temperature fall outside specific
user-defined values.
Supported Hardware
•
Omnitracs Intelligent Vehicle Gateway (IVG)
•
Omnitracs Mobile Computing Platforms (MCP200, MCP110, MCP100)
Note: The MCP50 is not supported.
Firmware Requirements
To fully support Trailer Tracks, you must meet the following requirements for the system
you are using:
• IVG - Firmware version DA0215R or higher
• MCP200, MCP110, MCP100 - All firmware versions support Trailer Tracks
MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Tethered Trailer Tracks (TT100)
Quick Installation Guide
80-52641-1 Rev. J
1
Advertisement
Table of Contents
Summary of Contents for Omnitracs TT100
- Page 1 Refrigeration Unit Connection ....................4 1) Introduction The Tethered Trailer Tracks (TT100) mobile communication terminals system is an option that allows dispatch to monitor trailer connects and disconnects. Connects and disconnects are detected by the IVG or MCP (except MCP50) and passed on to the host with the date, time, and location.
- Page 2 2) Fuse Kit Installation To install the fuse kit, follow these steps: 1. Locate the blue AUX wire in the 7-way trailer receptacle. With ignition turned on, determine if +12 /+24 VDC is present on this wire. • If +12/24 volts is present, proceed to step •...
- Page 3 3) Installing the TT100 on the Trailer TT100 Transmitter Installation Use these installation instructions for the TT100 transmitter (with refrigeration cable) and TT100 dry van monitoring (without refrigeration cable). 1. Mount the Trailer Tracks transmitter on the front of the trailer near the trailer’s 7-pin “pigtail”...
- Page 4 Carrier Advance/Carrier 45-J7856-6 DataTrak software Other Apex installed (3-pin Packard connector) Thermo King 45-J7857-6 i-Box with minimum Omnitracs (pre 2010 i-Box) (6-pin circular Deutsch) 5308 software installed Communication Protocol Thermo King 45-JB082-6 (6-pin i-Box with minimum Omnitracs (2010 or newer radio...
- Page 5 Dallas, TX 75201 U.S.A. © 1998-2017 Omnitracs, LLC. All rights reserved. Omnitracs is a trademark of Omnitracs, LLC. All other trademarks are the property of their respective owners. Omnitracs endeavors to ensure that the information in this document is correct and fairly stated, but Omnitracs is not liable for any errors or omissions.
