- Page 1 OEW-ST60 WIFI CAR DVR User Manual 2 Year Warranty Made In China...
-
Page 2: Table Of Contents
Light Status........................6 Memory Card......................6 Device Voice Prompt....................6 (C)Technical Specifications..................7 (D)Product Contents....................7 (E)Device Instructions....................8 (F)Installation.......................8 (G)Operation & LED Status Instructions............9 (H)OE Witness Smart Phone App Installation..........10 (I)OE Witness Smart Phone App Operation...........11 (J)FAQ & Answers....................14 OE Witness Warranty Terms and Conditions..........15... -
Page 3: Introduction
This instruction manual contains basic information on how to install and operate your OE Witness dash cam. Before using your OE Witness dash cam, we recommend that you read and understand this manual to ensure you get the maximum from your purchase and use it correctly. -
Page 4: Important Safety Information
Disclaimer The OE Witness WIFI hidden style digital video recorder (DVR) is designed for the recording of video and taking of photos when driving. OE Witness takes no responsibility for the loss, damage or corruption of data due to incorrect operations. We strongly advise this device be used with a memory card of Class 10 or above. - Page 5 This car digital video recording device is for the sole use of driving assistance and it will NOT replace the actual manual operation of the vehicle. OE Witness will NOT be held liable for any accident or dispute caused. The video or photo data taken by the device is for use of recording only.
-
Page 6: B Customer Guide
Memory Card The user is advised to format the memory card used in the device regularly. Format can be performed by Cellphone via the OE Witness dedicated App or alternatively by computer. This will ensure the memory card is kept in good working order and clear any memory chips which can affect its long term performance capability. -
Page 7: C Technical Specifications
Technical Specifications NAME Parameter 600MHz Chipset Frequency 512MB DDR Memory 1080p@30fps,720p@30~60fps Video Resolution Lens Angle F2.0 Lens Aperture H.264 Video Compress Mode 8/16/64/128G (Standard Version is 16GB) Memory Capacity -20℃~70℃ Working Temperature -30℃~75℃ Storage Temperature 2.4GHz IEEE802.11b/g/n WIFI Protocol Input Voltage less than 300mA Working Current 10.5V~24V... -
Page 8: E Device Instructions
Device Instructions Lens On/Off and Indication Light Memory Card Socket Reset USB Interface Installation Take off the original plastic Install the Car DVR to the part from the rear mirror rear mirror Installation Position Take it out Wiring diagram for reference Fuse Box Diagram Black Cable(GND) Yellow Cable(B+, Power... -
Page 9: G Operation & Led Status Instructions
Operation & LED Status Instructions Button & Indication Light Definition Name Operation Definition After it ´ s on, Short Press Lock/Unlock （With SD Card) After it ´ s on, Short Press Resume to Factory Setting Button （Without SD Card) (Including SSID) After it ´... -
Page 10: Hoe Witness Smart Phone App Installation
OE Witness Smart Phone App Installation Search “ OE Witness” on App Store(For IOS) or on Google Play (For Android) The Car DVR original factory setting is as below: WIFI ID: OEWitness-XXXXXX XXXXXX :As Device Code WIFI Password: 1234567890... -
Page 11: Ioe Witness Smart Phone App Operation
OE Witness Smart Phone App Operation 2、Find the WIFI ID: 1、Open Wi-Fi and 3、Open the APP on OEWitness-XXXXXX find the right ID the cellphone and click type the Password : on “Preview “ 1234567890 4、Connection OK, then you check the actual... - Page 12 Working Status Transmission Speed Time Display On/Off Voice Take Picture recording On/Off Video recording 5、Photo or Video preview instruction File Selection & Preview Local video or photo Long press the file then management & browse you can select and click to download the file you need.
- Page 13 On/Off Voice mode Record time selection On/Off Parking Monitor Optional for 1/2/3mins Memory Card Format memory card SSID Setting Information or Reset 7、Instruction for setting...
-
Page 14: Jfaq & Answers
A: Memory card issue. Solution is to format the memory card on a comput- er and press reset on the device. Insert memory card and check for record- ing. FOR ANY ASSISTANCE REGARDING YOUR OE WITNESS PRODUCT PLEASE CONTACT US VIA OUR DEDICATED CUSTOMER SUPPORT PORTAL AT OEWITNESS.COM OR EMAIL US ON SUPPORT@OEWIT-... -
Page 15: Oe Witness Warranty Terms And Conditions
Should the OE Witness dash cam fail to operate satisfactorily within the warranty period, OE Witness at its sol discretion will repair or replace the product. In cases of the product being discontinued or out of stock, OE Witness reserves the right to supply an equivalent model that may be refurbished, reconditioned or pre-owned.
