- Page 1 TCL多 媒体 SCB C(战略客户业务中心) 基本内容 设计中心-平面设计室 销往地 品牌 MICROMAX 平面设计制作规范表 机型/机芯 物料编码 72-43D190-X84Z1 43D1901 3RT841B1T2B E7-43D190YY-TH0 /批次 说明书 销售型号 物料名称 43HS521AN 制作要求 工艺或使用方法 尺寸 A5（143x210mm） 说明书内容见下页。 80G paper 材质 (80克书写纸) white word on the 颜色 black background 要求 (白底黑字。) 是否折 叠或装...
- Page 2 OPERATION MANUAL 43HS521AN...
- Page 3 IMPORTANT SAFETY INSTRUCTIONS ATTENTION: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
- Page 4 Notes for battery disposal The batteries used with this product contain chemicals that are harmful to the environment. To preserve our environment, dispose of used batteries according to your local laws or regulations. Do not dispose of batteries with normal household waste. For more information, please contact the local authority or your retailer where you purchased the product.
-
Page 5: Table Of Contents
Chapter 1: Introduction Precautions ..............................Product ................................ Power and Plug ............................Power Cord and Signal Cable ........................Use Environment ............................Cleaning ..............................Hanging the TV Set on the Wall ........................Buttons on the TV ............................Sockets ............................... Remote Control Functions .......................... How to Pair Remote Control with the TV...................... -
Page 6: Precautions
Chapter 1 Precautions Use Environment Read all of the instructions before operating the set. Do not place the set on an unstable cart, stand, or table. Keep these instructions well for future use. Product Place the set on a place that allows good ventilation. Do not block or cover the ventilation openings on the Do not use the set near damp, and cold areas. -
Page 7: Buttons On The Tv
Buttons on the TV Note: The location and names of the function buttons and power button on the TV may vary according to TV model. And some buttons may not available for some models. button Scans up/down through the channel list. In the menu system, they act like the up/down direction buttons on the remote and adjust menu controls. -
Page 8: Sockets
Sockets Note: The location and names of the sockets on the TV may vary according to TV model, and some sockets may not available for some models. LAN/RJ45 LAN/RJ45 RJ45 plug for connecting to external modem or network access equipment. OPTICAL OUT socket OPTICAL OUT This output can be used to connect a compatible digital audio receiver. -
Page 9: Remote Control Functions
Remote Control Functions Most of your television's functions are available on the menu that appear on the screen. The remote control supplied with your set can be used to navigate through the menus and to configure all the general settings. Note: The location and names of the buttons on the remote control may vary according to TV model, and not all buttons available on all models. -
Page 10: How To Pair Remote Control With The Tv
Introduction Remote Control Functions Most of your television's functions are available via the menus that appear on the screen. The remote control supplied with your set can be used to navigate through the menus and to configure all the general settings. (On/Off button) Turns the TV on or off. -
Page 11: Switching On
Chapter 2 Switching on Follow the instructions on this page on how to switch on your TV set and the remote control before going on to following pages describing how to use the channel set-up procedure. 1. Insert two batteries in the remote control. Precautions on using batteries: - Only use the battery types specified. -
Page 12: Network Connection
Network Connection To access the internet, you must subscribe high speed broadband internet service from your internet service provider. Your TV can be connected to your home network in two ways: Wired, using the RJ45 (LAN) connector on the back panel. Wireless, using the internal wireless or external wireless USB adapter and your home wireless network. -
Page 13: Chapter 3: Initial Setup
Initial Setup Chapter 3 Google - Initial Setup When you turn on the TV for the first time,there will show Step 3: Select whether or not to connect your TV set to a wizard to guide you to finish the following initial settings: the WLAN network. -
Page 14: Tv Initial Setup
Initial Setup Step 1: 2 3 4 5 TV - Initial Setup Initial setup involves selecting all the settings required Environment Home to be able to search for and store all the analogue Shop Home Please choose your Environment: channels you can receive. Shop Shop with demo Make sure that the television is switched on and follow... -
Page 15: Chapter 4: Home Features
Chapter 4 Home Features Homepage Operation Note: This manual is for common use. Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. And for some models, certain options are not available. You can select all the features from homepage. -
Page 16: Chapter 5: Using Your Tv
Using your TV Chapter 5 Accessing channels Using the numeric buttons: press the corresponding Display & Sound numeric buttons on the remote control to access the Info Watch TV channels. Using the buttons: press the buttons on CH / CH / Picture Off Audio Language the remote control or the corresponding buttons on the... -
Page 17: Using System Settings
Using your TV Using TV Settings The Settings menu allows you to the TV with (2)Primary Preferred Language: your preferences. Press OK and than use ▲/▼ to select Primary Preferred Language. Note: Some of the functions might be unavailable (3)Sencond Preferred Language: in certain sources. -
Page 18: Picture & Display
Using your TV Piture & Display Sound Sound Ajustment Picture Ajustment Adjust sound and speaker-related options. Adjust the picture settings such as Brightness, color and hue. Settings Settings TV Placement Piture & Display Sound Deak Top Display Setting Adjust the picture and screen settings. Adjust the aspect ratio and viewable screen area. -
Page 19: Smart Zone
Using your TV Smart Zone System Language English Fast Cast Sleep Timer World clock Night mode Enjoy Music Environment Home Enjoy Music:Select this option to enter into Audio Only Settings System mode. Shop Demo E-show Setup your TV options Fast Cast:An app that quickly delivers mobile content to Power TV,allowing users to quickly deliver multimedia content such as photos,videos,music and more to TV terminals. -
Page 20: Attention And Frequently Asked Questions
Chapter 6 Multimedia Attention and Frequently Connect a USB device to a USB socket, the screen will show Asked Questions USB file name and then press OK to enter .If no USB device connected, the USB interface will be not displayed. Attention: Some non-standard mobile storage device may not be recognized. -
Page 21: Troubleshooting
Troubleshooting Ignition Most problems you encounter with your TV can be Black spots or horizontal streaks appear, or the picture corrected by consulting the following troubleshooting list. flutters or drifts. This is usually caused by interference from car ignition system, neon lamps, electric drills, or No picture, no sound other electrical appliance.
