Masterplug ILRCDNG Manual

safety in-line RCD
OUTDOOR
POWER

FEATURES

• Maximum load 3120 watts 240V AC
• 30 milli-amp trip speed
• 40 milli-seconds (typical) double pole contact break
PRODUCT IMAGES
ILRCDNG
PRODUCT INFORMATION
Part Number
Product Dimensions

TECHNICAL SPECIFICATIONS

IP Rating
Maximum Current
Maximum Load
No. of Poles
Rated Trip Current
Trip Speed
RCD Type
Standards
Benefit

SAFETY WARNING

PLEASE READ CAREFULLY AND USE IN ACCORDANCE WITH OUR SAFETY INSTRUCTIONS BELOW
Unplug from the mains before inspection of the appliance
Keep children away from sockets and electrical appliances
Seek expert advice or contact the UK Masterplug helpline on 03300 249 279 if you have difficulty setting
your Masterplug in-line RCD or if the RCD repeatedly trips
Store and use between -5° c and + 40° c
Use your in-line RCD as a substitute for taking normal precautions when using mains electrical power
Use in conditions where the atmosphere is loaded with flammable vapour
Use if the case becomes damaged
Use above an altitude of 2,000 metres above sea level
Masterplug Help Line
03300 249 279
designed with outdoor activities in mind, this range
provides safe power solutions for garden and light DIY use
ILRCDNG
Height 50mm x Width 58mm x Depth 175mm
IP65
13 Amps
3120 Watts
2
30mA
40mS (Typical)
Non-Latching
Manufactured to BS7071:1992
Added protection from the risk of electric shock
Luceco PLC
Stafford Park 1 Telford TF3 3BD ENGLAND
• Added protection against fatal electric shocks
• Manufactured to BS 7071 1992
LINE DIAGRAMS
58
www.masterplug.com
IP65
RATED
50
41.3
