Thank you for your purchasing the motorcvcle, with four stoke and pedal style. Hope
you enjoy driving it all the tine.
The motorcycle is the most fashionable pedal style and top grade and using for city
nowadays. Because it's engine is produced by advanced technical and the parts and
components are selected to assemble, with large horsepower, low consuming, low noise,
electric ignition, electric starting, frame body with protecting, quick accelerating reaction,
actively driving, and superexcellent performance..
The manual contains the necessary instructions and guidance with respect to the
operation and maintenance of the motorcycle, keep it at an optima performance. Please you
understand if the specification is changed, the parts of drawing or contents in book are
different from the fact.
Please you read carefully the book before driving for your safety and making your
comfortable.
The capacity of motorcycle can proper adjusted by experienced worker according to
different the area, climate and conditions until the best condit
performance.
Please you note environmentalism.
Mortch International Ltd
1
ion, and don't effect on the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prince and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mortch Prince

Summary of Contents for Mortch Prince

  • Page 1 Mortch International Ltd Thank you for your purchasing the motorcvcle, with four stoke and pedal style. Hope you enjoy driving it all the tine. The motorcycle is the most fashionable pedal style and top grade and using for city nowadays. Because it’s engine is produced by advanced technical and the parts and...

  • Page 2: Table Of Contents

    Mortch International Ltd Contents 1.regulations of safe driving…………………1 Way of parking…………………………..…21 Way of driving…………………………….2 5.inspecting before driving……………………22 Loading……………………………………3 Inspecting and supplying gasoline………….23 2.locations of parts…………………………..4 Inspect braking……………………………..24 3.handling of parts…………………………..5 Inspect braking light………………………..25 Meters…………………………………….6 Inspect turn signal………………………….25 Indicators…………………………………6 Inspect tire………………………………….26 Main switch………………………………7...

  • Page 3: Way Of Driving

    Mortch International Ltd 1.SAFE DRIVING Clothes: Safe driving main point is natural and relaxing mood and wearing comfortable dress, Pay attention to driving with obeying ruler of traffic, don’t worry and relax the mood. CAUTION: · the drivers don’t wear loose or longed clothes, avoid to happen damage.

  • Page 4: Loading

    Mortch International Ltd · keep your only natural posture to actively driving the motorcycle. · the position effect on the rider’s · please pay attention to driving on the no-smooth safe,please seat at the center of double road. seat, if driver seat at the end of double...
  • Page 5 Mortch International Ltd ·the handle bar can feel the change of weight between the loading and no-loading. So please driving caution. When the loading overtaking, the handle bar shake easily, please avoid overtaking driving. NOTE: ·Don’t place the clothe under the seat(outer luggage),if else, make the fuel system choked and the engine ill.

  • Page 6: Locations Of Parts

    Mortch International Ltd 2.LOCATIONS OF PARTS:...
  • Page 7 Mortch International Ltd...
  • Page 8 Mortch International Ltd 3.INSTRUCTIONS FOR FHE MOTORCYCLE ■ ■ ■ ■ Speedometer and indicator (1)Mileage recorder It display the total distance covered by the vehicle(km) (2)speed indicator The standard of speed:km/h (3)Pilot of headlight Pilot of headlight is switched and indicate the (5)fuel meter pilot light.

  • Page 9: Main Switch

    Mortch International Ltd ■Main switch ·Electrical source is cut off and the engine stopped. ·The key can be taken down. ·Electrical source is on and started. ·The key can not taken down when driving. ·The steering handle pipe is locked and avoid theft.
  • Page 10 Mortch International Ltd ■Starting button: ■Switch comp headlight ■Headlight OFF: When use the electric starting, please draw the ·Headight,sidelights,speedometer rod comp front brake stop, or step the pedal comp light are shut off. rear brake, until the electrical source is touched ·...

  • Page 11: Switch Comp Turn Signal

    Mortch International Ltd ■HEAD LIGHT, CHANGE SWITCH OVERTAKE HEAD LIGHT, CHANGE SWITCH OVERTAKE HEAD LIGHT, CHANGE SWITCH OVERTAKE HEAD LIGHT, CHANGE SWITCH OVERTAKE SIGNAL SWITCH SIGNAL SWITCH SIGNAL SWITCH SIGNAL SWITCH ■HORN BUTTON: when the pilot is switched, using the HI...
  • Page 12 Mortch International Ltd NOTE: ·Please return the turn signal after using because it can’t relax, if else effect or other people’s safe. ■...
  • Page 13 Mortch International Ltd ■LUGGAGE BOX: ■KEY OF HEMET Luggage box lies under the seat. Way of opening seat is the same as above. Way of using NOTE: (1) Open lock comp seat and put up the seat. ·The max weight of loading: not exceed 10kg.

  • Page 14: Front Luggage Box

    Mortch International Ltd ■FRONT LUGGAGE BOX Way of opening Insert the key and turn it right, the front luggage can push up. Way of closing: Insert the key and turn it right, close the cover of luggage box. And then turn left and take down.

  • Page 15: Electric Starting

    Mortch International Ltd ■Way of starting for engine: (5) When driving in winter, turn the key of bank to “OFF”, kick starting about 5 times and (1) Check the gasoline, fuel and battery starting. make into gasoline, then touché with the...
  • Page 16 Mortch International Ltd NOTE: After starting the engine the hand leave the button and don’t touch with it when driving; catch hold of the front brake bar or step the rear brake pedal, the NOTE: braking light is switched, but pushing time is not...
  • Page 17 Mortch International Ltd · Ride the motorcycle from left side and seat well, 4.WAY OF NATURAL DRIVING the left foot touch with room and avoid to rave. 1 Spring the man stand firstly ·Push ahead and the main stand will auto spring.
  • Page 18 Mortch International Ltd 2 Loose rod of rear brake Turns the grip of throttle slowly and the motorcycle moves slowly. NOTE: NOTE: ·Don’t add freely gasoline to the turning · Don’t turn the grip of throttle quickly and bar after loosing the rod of rear braking,...

  • Page 19: Correctly Driving

    Mortch International Ltd 4 Correctly driving Adjusting of speed is controlled by the grip of throttle. The speed will become faster, Before driving the motorcycle, please open turn Return inner so please accelerate slowly. signal and confirm the rear safe.
  • Page 20 Mortch International Ltd ■ ■ ■ ■ The first period of new motorcycle ■ ■ ■ ■ Using the front&rear braking running will effect on the usage of stopping when parking ·Parking the motorcycle after returning the grip engine. ·please keep the speed less 60km/h in the first of throttle to origin position.
  • Page 21 Mortch International Ltd ■Don’t stop and swerve peremptorily ■Notice driving the wet day. ·Swerving and stopping peremptorily is one of ·please decelerate to drive because of longed the clause of accidents and very danger. distance and the difference of road between the sung and wet days.

  • Page 22: Way Of Parking

    Mortch International Ltd ■Way of parking: 2 The vehicle complete stop 1 Near the parking place: Return the turn signal to origin position snd switch to “OFF” ·Open the turn signal ahead of time and notice the rear and side of vehicle and stop it slowly.

  • Page 23: Inspecting Before Driving

    Mortch International Ltd When parking 5.Inspection before driving ■ ■ ■ ■ Inspection before driving Stand the left side of motorcycle in the smooth land and support main stand of motorcycle ·Support the main stand in the little traffic and Please have a habit of checking vehicle before smooth land, if else happen to accident easily.
  • Page 24 Mortch International Ltd 1 CHECK AND SUPPLY GASOLINE ·Supply the oil when the needle reach the red zone, at this time the rest gasoline is about1.5L. ·Supply the gasoline of 90#in time. ■APPOINTED ESPECIAL OIL Four stoke especial oil:SAE10w-30(SIGMA) NOTICE: 1.Don’t use the counterfeit oil, if else happen...
  • Page 25 Mortch International Ltd CHECK BRAKING <CHECKING BRAKING OIL> 《WINDAGE OF BRAKING ROD》 1.Place the handle bar correctly, check the The braking rod must have proper windage. And braking oil in right fuel tank, and keep it the it’s active is work naturally.
  • Page 26 Mortch International Ltd 3 Inspection of braking light ·Turn the main switch to “ON”. ·Turn the main switch to : “ON”. · Handle the switch of turn signal and confirm the ·Brake the front&rear braking and confirm the front rear, left and right turn signal, turn signal light is switched.
  • Page 27 Mortch International Ltd ·Check and clean out metal and crush pieces in 6 Inspection of wheel the tire trough ·Check the pressure of tire ·Please change into new tire, if the crush or the depth of trough reach the limit.
  • Page 28 Mortch International Ltd · · · · Please maintain the vehicle, assure to comfortable driving. (please reference page31) · · · · please check termly the vehicle when don’t use it long time. · · · · The first inspection:...
  • Page 29 Mortch International Ltd ■ ■ ■ ■ CHECK THE SPLINE COLLAR OF ■CHANGE OIL REAR TIRE AND FRONT&REAR Replace the oil firstly 300km,after every 1000km. HANGER SET check the oil capacity every 500km and supply ·When check the spline, support the vehicle by the oil in time until the limit.
  • Page 30 Mortch International Ltd <term of changing> <way of changing> Replace into the 10#or GY gear oil firstly 300km 1.Support the vehicle in the smooth land. and after every half a year or 3000km. 2.Get down the screw of oil. 3.If change oil the warm of engine, the rest oil will pour out gear box.
  • Page 31 Mortch International Ltd ■ ■ ■ ■ CHECK SPARK PLUG The untidily of spark plug electrode and exceed windage effect on it’s work. <way of cleaning> The best way is using cleaner of spark plug to clean. If have not cleaner, please use the needle brush.
  • Page 32 Mortch International Ltd TERMLY MAINTAIN PROJECT AND SCHEDULE: Assure to driving safely, maintain the performance,longed the usage and reduce the pollute,please check and maintain it termly. I:Checking,cleaning,lubricating,adjusting,or replacing A:adjustment C:cleaning R:replacing T:lock Check ITEMS DRIVING DISIANCE(km) before 300 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000...
  • Page 33 Mortch International Ltd ■CHECK THE ELECTROLYIE OF BATTERY BATTERY HEAD The vehicle adopt no-supplying water or Firstly get down the three screws and battery supplying electrolyte battery. cover when cleaning the battery head. ·Get down and clean the battery when the Don’t...

  • Page 34: Replace The Fuse

    Mortch International Ltd ■Replace the fuse · Change the electric goods(Light,speedometer) Shut off the main switch and check whether the fuse is scaled or not according to the specification good parts appointed. Replace the fuse according to the power ·If use the disqualification parts, the fuse is scaled appointed.
  • Page 35 Mortch International Ltd ■Way of cleaning the air cleaner Dust is the one of the clause of reducing the horsepower. <way of getting down> 1.Get down the five locked screws in the left rear cover and rear cover, and then get down the seven locked screws.
  • Page 36 Mortch International Ltd performance of the engine. The carburetor is (b)Adjust the idle speed adjusted the best condition in the manufacture 1.Warm the engine many minutes and start it. and don’t change the condition. Now you shall 2.Twist the adjusting nut of oil, and slowly drop it adjust the two projects as followings:adjusting of about3 circle.
  • Page 37 Mortch International Ltd 7.THE SPECIFICATION SCHEDULE: ≤2.9 Over size:length×width×high 2070×75×1410 The min consume L/100KM ≤7(0km/h) Wheel base: 1450 Braking distance ≥10 Dead mass Climb performance (°) Capacity of fuel tank Engine model YY1P57QMJ Single eylinder,forced Oil capacity of crankcase Style air,four stoke.
  • Page 38 Mortch International Ltd Start Elecrric/kick start Front tire 110/90-12 The specifi- cation of tire Ignition system Rear tire 130/70-12 Pressing Spark plug A7RTC Ront tire of tire: Lubricant system Force lubricant Rear tire Clutch Dry-auto acentric Electric system Change speed system...
  • Page 39 Mortch International Ltd 8.ELECTRIC PRINCIPAL DRAWING...
