Coopers 10569 Instructions For Use

Dual Sensor Light
Please read and retain these instructions for future reference
Power Details: 4 x AA Batteries (not included)

BATTERY INSTALLATION

1. Remove the battery cover (located on the opposite side of the LED lights) from back using a small
Phillips head screwdriver.
2. Insert 4xAA batteries (not included) as indicated inside the battery compartment and replace the
battery compartment and screw.

INSTALLATION INSTRUCTIONS

1. Determine the exact location where you want to install the light fixture.
*Two different installation options are provided, it is recommended to use the standard installation
wherever possible

STANDARD INSTALLATION

1. Prepare area where you what to mount the light unit, clearing any loose debris, and ensuring that
you have adequate space to mount the light before drilling any holes. There needs to be a small
space left above the unit so that it can be hooked over the screws.
2. Mark where you want the two screws to be mounted, they should be 57mm apart and level.
3. Drill pilot holes using a 1.5mm drill bit to a depth of 19mm.
4. If you hit a wall stud, or are fixing to a wooden surface, use only the supplied screws to install the
light fixture.
5. If the wall is hollow or you are drilling into masonry using the pilot holes as guide, drill again using
a 6.5mm drill bit and insert a wall anchor into each hole. Tap each wall anchor lightly with a
hammer, until they are flush with the wall surface.
6. Thread a screw into each hole (or wall anchor if used) leaving 3.5mm of the screw unthreaded, to
secure the light fixture.
7. Match the holes on the base of the light fixture (narrow end of holes facing upwards) with the
screw heads and slide downward to secure the light fixture.
10569
DUAL SENSOR LIGHT
Eg: x 57mm
Instructions for Use
v002: 30/1/18
x
