- Page 1 Model 858-RH Operating and Assembly Manual Midwest Equipment Mfg. 5225 Serum Plant Road Thorntown, IN 46071 10/10/2018...
-
Page 2: Safety Rules
SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. This symbol means Attention!!!!! It is used to point out safety precautions. ▪... - Page 3 Model 858 Trac-Vac Parts List DRAWBAR KIT PART NO. 10620 11-19-14...
- Page 4 Model 858 Trac-Vac Parts List Part No. Description Qty. 85810 Frame, 854-RH 18030 Turbine Housing, RH 86040 Turbine 18050 8" Inlet 85001 Gearbox 85023 PTO Shaft 85016 Pulley, MA 55 x 3/4" 85009 Bearing, 3/4" Pillow Block 85028 Bearing, 1" Flange 85029 Bearing, 1"...
-
Page 5: General Instructions
GENERAL INSTRUCTIONS Your Model 858 Trac-Vac is designed to mount to the drawbar and center link of your compact tractor. It does not require the use of the lower arms of the 3-point hitch to mount. Each unit requires a tractor specific mount kit that will need to be installed to the drawbar of your tractor. - Page 6 Model 280 Cart Cover Assembly Instructions NOTE: Do not tighten any bolts until the end of construction. Place front on sides with flanges on Place side panels on end with decal Place screen without latch, (front outward and about a foot apart at outside .
- Page 7 Model 348/368L Cart Covers Model 280/348L Cart Cover Model 280/368L Cart Cover Key Part No. Description Part No. Description Side Panel Side Panel 28047 28059 28030 Front Panel 28035 Front Panel Tailgate Tailgate 28236 28238 28232 Deflector 28235 Deflector Front Screen Front Screen 28242 28240...
-
Page 8: Maintenance
MAINTENANCE DANGER: The Trac-Vac 858 was built to be operated according to the rules for safe operation as outlined in this manual. Carelessness or error on the part of the operator can result in serious injury. This unit is capable of amputating fingers or hands and throwing objects. - Page 9 Adjust inboard belt first by moving jack shaft bearing to the rear, then adjust outboard belt by moving gearbox forward. TRAC VAC WARRANTY POLICY Midwest Equipment Mfg. will repair or replace, free of charge, any part, or parts that are defective in material or workmanship or both for a period of one year residential use, and 90 day’s for commercial and rental use.
