ECO-71010, ECO-71010-STPK, ECO-71010-DLX
Read All Safety and Operating Instructions thoroughly before use
Wood-Fired Pizza Oven
2
68.5
7
33.9 in
cm
i
86 cm
n
BAKE|SMOKE|ROAST & GRILL
& Smoker w/ Cover
88.6 in
225 cm
68 in
173 cm
30.3 in
77 cm
Warning! Please Read!
Assembly &
Operation Manual
71010-MAN01
Advertisement
Summary of Contents for ecoque ECO-71010
- Page 1 Warning! Please Read! ECO-71010, ECO-71010-STPK, ECO-71010-DLX Read All Safety and Operating Instructions thoroughly before use Wood-Fired Pizza Oven & Smoker w/ Cover Assembly & Operation Manual 88.6 in 225 cm 68 in 173 cm 30.3 in 77 cm 68.5 33.9 in 86 cm BAKE|SMOKE|ROAST &...
- Page 2 • Adding fuel or volatiles such as lighter fluid to combusting charcoal or flames can result in explosion. Do not add volatiles after igniting thas appliance • Do not use liquid or gas fire starters. Always refer to ecoque.com for a list of fire starters recommended for this appliance.
- Page 3 ECO-71010 • Use appropriate personal protective equipment such as oven mitts, gloves, and aprons when operating this appliance. • Only use wood, charcoal, or plant based fuels specifically designed for outdoor cooking. • Use care when transporting this appliance. Strap it to the side of the trailer or vehicle •...
- Page 4 The cooking chamber of the pizza oven is completely Thoroughly before use. sealed off from smoke. If you want to add a great smoke flavor to your pizza, try placing an EcoQue Chip Strip Note: The dial thermometers are calibrated to show alongside your pizza. Available at ecoque.com...
- Page 5 ECO-71010 page|5 Assembly of the Side Handles Assemble the oven handles: Unbox/Uncrate the Oven Compartment. Remove all the contents. Attach the Lifting Handles as shown in this picture using 4-(A) Flat Head Screws Name Size Flat Head Screw-1/2” Long M6*15 8 PCS IMPORTANT!! Additional Tip for Attaching the Handles!! Before you roll your new oven off the pallet, you need to attach the assembly handles.
- Page 6 ECO-71010 Once the pallet is close to the place where your oven will go, it's time to unpack it. Remove the carton and empty the contents of the oven chambers to lighten up the unit to move it into place.
- Page 7 ECO-71010 OVEN Chimney Assembly- Name Size Chimney Flat Head Screws ½” Long M6*15 3PCS Chimney adjustment rod is at the base of chimney. Attach Chimney Cap with 3 provided screws (A) as shown. The Chimney will be locked on top of the Oven by dropping it in the oven top hole(knob at a few degrees to the right of center, until the cross rod at the base drops in the slot holes) and then rotating it clockwise to lock it, so the adjustment knob points forward.
- Page 8 ECO-71010 Place Parts in the oven and smoker compartment: (as shown in the diagram) Note: All the parts below are packed in the pizza oven chamber for transportation. Assemble the ovens according to the instructions below: 1x slide out rack in the pizza oven.
- Page 9 ECO-71010 Starting the Fire Step 3: Add Additional Fuel This Wood-Fired Pizza Oven & Smoker is designed to burn Add Additional fuel as necessary to maintain the cleanly and efficiently. Its unique firebox design allows for temperatures you want in the ovens. You can use any easy setup and operation.
-
Page 10: Cooking Pizza
Use the pizza oven instead of the smoker when- For videos, recipes, and information please ever you want to plank, roast, or bake without visit us at: www.youtube.com/user/ecoque smoke. Note: Cooking times will vary depending on Avoid cooking foods that will drip fat or grease the type of food and the weight of the food. - Page 11 ECO-71010 Place the bricks, pizza stone in the Oven as Shown after initial burn off is completed. (See Page 12) DO THIS AFTER THE BREAK-IN BURN (See Pg. 14 & 15) THE FIREBOX The Firebox is fastened to Glide Rails and that allows it to easily slide in and out of the combustion chamber.
- Page 12 ECO-71010 NOTE!! THIS STEP HAS ALREADY BEEN COMPLETED ON YOUR UNIT. SO, MOVE TO THE NEXT STEP. Also note that the vent pipe now has a cap on the end to close it when not in use. Name Size...
- Page 13 ECO-71010 Additional Notes and Tips for Installing the Pizza Stone in the Top of the Oven: When installing the Top Pizza Stone, here's some additional tips we've come up with to make it a little easier. 1) WAIT to install the top pizza stone until after you've cleaned the oven chamber with some citrus cleaner and a rag.
- Page 14 • Control the smoke with the Chimney Also Visit the EcoQue You Tube Channel where Illustration to the right you will find a collection of Videos on the Wood • Place a water pan in the smoker oven Oven Assembly, Making Pizza, Smoking &...
-
Page 15: Maintenance
ECO-71010 Maintenance Cleaning the Combustion Chamber When it comes time to empty the ash tray, follow Note: Allow this appliance to completely these simple steps ONCE THE FIRE IS OUT!!... cool before performing maintenance. Step 1: Pull out the Fire Box... -
Page 16: Warranty Information
• EcoQue hereby warrants this product against defects in materials and workmanship for a period of One (1) Year from the date of original retail purchase. This warranty is good only to the original purchaser. - Page 17 California Proposition 65 Warning: This product may contain components that were cleaned with chemical(s), known to the state of California to cause Cancer, and birth defects or other reproductive harm. These should burn off during the break in burn process- prior to cooking. However, certain fuels, like cooking wood and Natural Lump Charcoal will be used in this oven.
- Page 18 For Videos, Recipes, and More Information: Please visit us at ecoque.com and on our You Tube Channel at: http://www.youtube.com/user/EcoQue CONTACT US AT: sales@directglobalsales.com -or- customerservice@ecoque.com PH: 253-487-5924 Copyright 2019 Direct Global Sales, Inc. DBA EcoQue...
