Gas Restaurant Ranges
Operating Instructions
Before you begin, please read these instructions carefully to
use this product correctly, to make the product perform ideally, and
to avoid hazards.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-RO4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Migali C-RO4

  • Page 1 Gas Restaurant Ranges Operating Instructions Before you begin, please read these instructions carefully to use this product correctly, to make the product perform ideally, and to avoid hazards.
  • Page 2 Dear customers and users： Thank you for purchasing our products. In order to be able to better use this product, please read these instructions carefully before any operation, and follow the guide, to avoid any unnecessary trouble during using. Please keep this instruction manual in a safe place for convenient reference and operation.

  • Page 3: Table Of Contents

    Gas Restaurant Ranges The Installation, Operation and Maintenance Guide Contents Safety Protection ……………………………………………………3 2. Brief Introduction……………………………………………………3 3. Manufacturer's Authority and Responsibility……………………3 4. Parameter Specifications……………………………………………4 5. Transport and Storage………………………………………………22 6. Installation and Debugging…………………………………………23 7. Safety Notices and Precautions……………………………………25 8. Operating Instructions…………………………………………… 26 9.

  • Page 4: Safety Protection

    1、Safety Protection Please make sure that the operator is an authorized and licensed technician before you allow him/her to install and operate the products. Be sure to strictly follow this instruction guide during installation and using. The manufacturer is not responsible for any dangers or accidents caused by improper operation or maintenance.

  • Page 5: Parameter Specifications

    manufacturer's explicit authorization. Manufacturers refused to undertake responsibility to third parties as the following reasons: Not follow this instruction guidance and warning in in using and testing; Not in accordance with the requirements of technical parameters using this product; Incorrectly or irrationally using the product by untrained personnel; Not obey the local law using this product;...
  • Page 6 <Table 1> Griddle Overall Packing Oven Number working Model dimensions(IN) size(IN) dimensions(IN) area(IN) L x W x H L x W x H L x W x H oven L x W C-RO4 none 20*26*14 24*31*57 24*20 C-RO-24G - 5 -...
  • Page 7 Model manifold B.T.U./h pressure Oven plates （in.W.C.） SHAPE SHAPE NG45 NG42 NG45 NG44 Natural Gas 124,000 25,000 27,000 21000 24,000 C-RO4 LP54 LP52 LP54 LP53 Propane 116,000 23,000 27,000 21000 24,000 Natural Gas NG45 NG42 NG45 NG44 72,000 25,000 27,000...
  • Page 8 4.2、36 inch series： - 7 -...
  • Page 9 - 8 -...
  • Page 10 - 9 -...
  • Page 11 L x W x H L x W x H L x W x H oven L x W C-RO6 none C-RO4-12GR 12*20 C-RO4-12GL 36*31*57 *26*14 C-RO2-24GR 24*20 C-RO2-24GL C-RO-36G 36*20 ② Information of Gas Supply and Burner The minimum supplied gas pressure regulator is factory set at 5”Natural...
  • Page 12 Natural NG45 NG42 NG45 NG39 148,000 25,000 27,000 21000 27,000 C-RO4-12GR C-RO4-12GL LP54 LP52 LP54 LP52 Propane 140,000 23,000 27,000 21000 27,000 Natural NG45 NG42 NG45 NG39 125,000 25,000 27,000 21000 27,000 C-RO2-24GR C-RO2-24GL Propane LP54 LP52 LP54 LP52 121,000...
  • Page 13 - 12 -...
  • Page 14 - 13 -...
  • Page 15 - 14 -...
  • Page 16 L x W x H oven L x W C-RO8 none C-RO6-12GR 12*20 C-RO6-12GL 20*26*14 C-RO4-24GR 48*31*57 24*20 C-RO4-24GL C-RO2-36GR 36*20 C-RO2-36GL  Information of Gas Supply and Burner The minimum supplied gas pressure regulator is factory set at 5”Natural Gas W.C, and 10”L.P.
  • Page 17 NG45 NG42 NG45 NG44 Natural 196,000 C-RO4-24GR 25,000 27,000 21000 24,000 C-RO4-24GL Propane LP54 LP52 LP54 LP53 188,000 23,000 27,000 21000 24,000 Natural NG45 NG42 NG45 NG44 173,000 25,000 27,000 21000 24,000 C-RO2-36GR C-RO2-36GL Propane LP54 LP52 LP54 LP53 169,000...
  • Page 18 - 17 -...
  • Page 19 - 18 -...
  • Page 20 - 19 -...
  • Page 21 - 20 -...
  • Page 22 C-RO8-12GR 12*20 C-RO8-12GL C-RO6-24GR 24*20 C-RO6-24GL 60*31*57 *26*14 C-RO4-36GR 36*20 C-RO4-36GL C-RO2-48GR 48*20 C-RO2-48GL ② Information of Gas Supply and Burner The minimum supplied gas pressure regulator is factory set at 5”Natural Gas W.C, and 10”L.P. Gas W.C. The external thread of product’s intake-tube is 3/4 inches.

  • Page 23: Transport And Storage

    21000 27,000 C-RO6-24GR C-RO6-24GL Propane LP54 LP52 LP54 LP52 240,000 23,000 27,000 21000 27,000 NG45 NG42 NG45 NG39 Natural 229,000 C-RO4-36GR 25,000 27,000 21000 27,000 C-RO4-36GL LP54 LP52 LP54 LP52 Propane 221,000 23,000 27,000 21000 27,000 Natural NG45 NG42 NG45...

  • Page 24: Installation And Debugging

    6. Installation and Debugging Any erroneous installation, adjustment, refit, overhaul or maintenance may cause property damage or personal injury. The work shall be performed by authorized and licensed technicians, otherwise the manufacturer has the right not to provide warranty service; Only be installed in accordance with the local code.
  • Page 25 same level with other series of the same stove; Please lift the equipment rather than drag if you need to move it; Please refer to P16“11. Schematic Diagram for Installation of Rear Panel” for the installation methods of rear panel. Supplied gas pressure regulator is factory set at 5”Natural Gas W.C, and 10”L.P.

  • Page 26: Safety Notices And Precautions

    joint screw arbor, to prevent gas escape! 6.2 Debugging It’s very important to debug the new stove. Through the comprehensive system test of equipment, we can ensure function and safety performance of products. Discovering any potential problems before use (such as equipment’s placement, ventilation, operation, etc), can avoid costly losses.

  • Page 27: Operating Instructions

    used for other purposes; The equipment does not contain any user-serviceable parts. Dealers or technicians will repair it. Do not take apart any spare parts without authorization; Never change any other parts without authorization to this equipment, otherwise, may cause hazards, and the manufacturer has the right not to provide warranty service;...
  • Page 28 Figure 2 Figure 3 Figure 4 Figure 5 8.3 Lighting of normally open fire of stove 1. Align the OFF indicative line of thermostat valve knob to the arrow (Figure 5) to close the valve. 2. Open the underside face plate of oven (figure 6), thoroughly press the button at the front end of safety valve, and ignite the pilot fire by lighter with another hand simultaneously (figure 7 and figure 8).
  • Page 29 Figure 6 Figure 7 Figure 8 Figure 9 Figure 10 8.4 Ignition of main fire of oven After the normally fire was ignited, the main fire valve of safety valve was opened, and press the thermostat valve knob to rotate to the position LOW counterclockwise (figure 9). At this moment, the oven burner is ignited.
  • Page 30 8.6 Stove Operation Before using the stove for the first time, please use a mild detergent to wipe it clean. Do not use corrosive or abrasives detergent. Turn the burners on about 15-20 minutes before broiling for preheating, according to the cooking requirement to adjust the flame size. Notice: When first preheating, the furnace will smoke above.

  • Page 31: Cleaning And Maintenance

    angle. Then, tighten the fastening screw bolt of damper to guarantee the appliance does not get loose. At last, reinstall the underside face plate of oven. ④Caution: Each burner damper has been adjusted before delivery (once air input), Normal use without adjustment but only switching gas. Adjust only by authorized and licensed technicians.
  • Page 32 Recommended cleaning methods <Table9> Items Methods Times Wipe it with a soft cloth and mild Body daily detergent; Turn off valves when not in use; Control panel Wipe panel and control valve knob with daily mild detergent. Pull out catch tray from front body until the equipment cools down.

  • Page 33: Troubleshooting

    10. Troubleshooting <Table 10> Possible causes Problem solving Problems 1.Insufficient 1.Contact the local pressure in pipe gas supply dept. Not lighting 2.Nozzle occlusion 2.Dredge nozzle 1.Insufficient 1.Contact the local pressure in pipe gas supply dept. 2.The main fire nozzle 2.Dredge nozzle occlusion Ignite the pilot 3.Gas control valves...

  • Page 34: Schematic Diagram For Installation Of Rear Panel

    Note 1、Pressure maintaining valve connects with air intake, must be installed by authorized and licensed technicians, to ensure interface tightness. 2、The pressure regulator(s) have connected, the maximum load of natural gas cannot exceed 6”, and of LP cannot exceed 12”. 3、Adjustment range of the pressure regulator(s) is 3”-6”for natural gas, and 5”-12”for L.P..
  • Page 35 ( Insert the assembled rear top (Fix the assembled rear panel plate into the corresponding with the stove body by position of stove body) self-tapping screw) Migali Industries, Inc. Trusted Since 1955 516 Lansdowne Ave Camden, NJ 08104 Service Call: 800.852.5292 Service Email: warranty@mgiali.com...
