Summary of Contents for EC Line EC-E320D
- Page 1 User Manual EC-E320D EM Card Reader...
-
Page 2: Chapter I: Overview
Chapter I: Overview 1 Introduction： The EC-E302D is an advanced EM Card Reader, it reads the EM card identification number and transmits to any connected device. It has a slim and attractive design and is built for convenience and portability. With its USB interface, it’s plug and play, and runs without any additional power source. -
Page 3: Chapter Ii: Technical Specifications
Chapter II: Technical Specifications Electrical Characteristics: Operating Voltage Range 5 VDC (USB Powered) Standby Current 70 mA Max. Operation Current 90 mA Supported Transponders EM Cards Read Card Distance 5 - 8 cm Operation Frequency 125 kHz Communication Speed 106 Kbit/s Environmental Characteristics: Operating Environment Indoor Use... -
Page 4: Product Illustrations
Chapter III: Product Illustrations The Card Reader Interface Interface Mini USB 4 / 6 April-2018... -
Page 5: Chapter Iv: Installation Instruction
Chapter IV: Installation Instruction Connect USB Cable with Card Reader and Computer Mini USB port connect to the card reader and the USB port connect to the computer. Card Reader Successful Connection Hearing ‘drip’ sound and the red LED lights to indicate there is power to the reader. - Page 6 Manufacturer: EC LINE Thank you very much for using EC Line product For service, please contact service@ecline.com.hk www.eclinepos.com 6 / 6 April-2018...
