U39 FURY
USER MANUAL
This product supports GPS positioning and is recommended for outdoor flight!
This wifi camera pinpoint is 5G, please confirm whether the phone is supported.
▲This product is suitable for users over 14 years old.
▲Stay away from the rotating propeller
▲Read the<important statement and safety guidelines >carefully.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Udirc U39 Fury
Summary of Contents for Udirc U39 Fury
- Page 1 U39 FURY USER MANUAL This product supports GPS positioning and is recommended for outdoor flight! This wifi camera pinpoint is 5G, please confirm whether the phone is supported. ▲This product is suitable for users over 14 years old. ▲Stay away from the rotating propeller...
- Page 2 Drone Front Propeller A Propeller B Camera Front folding arm Front folding arm Switch Battery indicator Battery Rear folding arm Rear folding arm Propeller B Rear Propeller A Tripod Tripod Front Front LED (Red) Front LED (Red) TF Card slot visual system Rear LED (Green) Rear...
-
Page 3: Battery Charging
Unfolding Instruction ① Folding State ② Rear folding arms unfold ③ Front folding arms unfold ④ Open the tripod Battery charging Battery power is low in the original factory, It must be fully charged before use. ▲Only use the original charging line; Adapters with output current of 5V≥2A must be selected. Connect the batteries of the aircraft to the charging line of the original plant, and then connect to other USB charging sockets. -
Page 4: Transmitter Charging
Installation of TF Card * TF card is not included Insert the TF card into the slot on the belly of the fuselage, and pay attention to the metal contact surface orientation of the TF card. Transmitter The original transmitter is low in power, so it should be used after saturation. Phone Holder Video Gimbal Rotary Button... - Page 5 The installation methods of mobile phone holder Installation Disassemble Pull up the clip on ② Straightening the antenna ① the mobile phone Press to unlock the lock ① Put the phone ② clip on the back of the quasi- remote controller and push it to the end.
-
Page 6: Flight Operations
Flight Operations Mobile phone connect with Drone Download and install APP: UDIGPS This software is suitable for mobile phones in the IOS and Android system. For detailed operation, please check the system “HELP” of APP. Transmitter connect with Drone Frequency Pairing ②... -
Page 7: Compass Calibration
Compass calibration Rotate the aircraft horizontally until the remote control says "di... "Level correction to complete. When the front navigation light turns to long light and the rear navigation light flashes, enter vertical correction.rotate the vehicle vertically until the remote control says "di... - Page 8 Unlocking/locking the motor Push the left and right stick inward to the 45 degree angle simultaneously. ① On standby drone, motor rotation, drone unlocked. ② When the drone is not take off, the motor stops rotating and the drone is locked. The drone can only take off when the motor is unlocked.
- Page 9 Take off After unlocking the motor, the left control lever slowly pushes up and the aircraft slowly rises. Landing During the flight, the left control lever slowly pull down , and the drone slowly lands until landing. Return During the flight, press the "return " button, and the transmitter will sound "di", and the drone will automatically return to the take-off point.
- Page 10 Following Function While flying, press down the key, the transmitter sounds “di”, drone enters the function of following.Now it can be controlled by the user. The function is standard by the mobile phone APP signal, so it’s a must to make the drone and APP connected normally, turn on the mobile location service at the same time, otherwise this function is invalid Note: follow the maximum range distance, within 1000m of the take-off point.
-
Page 11: Gimbal Adjustment
Speed mode switch Press "H/L" and make "Di. Di. Di" three times to enter high speed mode "H"; Press it down again ，it will make the sound"di" again ,this indicates to the low speed mode”L. Press down the key again, it makes the sound of ‘di’ for twice, it comes to the middle speed mode “M”. -
Page 12: Low Battery Alarm
Video Press the "video" button to enter the recording state, and the transmitter will prompt "didi" to repeat this action to stop recording and save video. Notes for Filming ① Photos taken will be saved to mobile picture library and aircraft TF card; Video can be saved in TF card first, which can be downloaded to mobile picture library for viewing. - Page 13 Out of Range Alarm When the drone flying out of the max remote control distance, the transmitter will beep “didi...didi...didi...” to alarm the user to fly back the drone within range immediately. Stuck Protection When the propeller is stuck and does not rotate, the drone will start the automatic protection function to stop the motor working.
- Page 14 Method of propeller installation and disassemble Disassemble：Unscrew the screw on both sides of propeller clamp and pull out propeller assembly. Installation：Place the propeller assembly on the motor shaft, fix it on the motor, and lock screws on both sides of the propeller clamp. Note：There are marked "A"...
- Page 15 TF Card：Support Class 10 Micro Image mode：RGB Mode TF card，Supreme support 64G. ≥10 level Micro TF Card. Frame Rate：25 Operation Temperature：0°C-40°C File System Support：FAT 32 Tips: the above data are the test data of UDIRC toy lab, for reference only.
- Page 16 Real time image transmission：720 P@20 fps Operation System：This software is suitable for mobile phones in the IOS 9.0 or later and Android 4.4 or later system, Tips: the above data are the test data of UDIRC toy lab, for reference only.
-
Page 17: Troubleshooting
Troubleshooting Problem Problem cause Solution Low battery. Charge the controller battery. The controller The batteries are incorrectly. Install the batteries following the polarity indicators. Indicator light is off. The batteries are incorrectly Clean the dirt between the battery and the positioned. -
Page 18: Fcc Note
FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
