OXD-844-5010-5030K_Instructions.qxd
Diagrammatic information
Adjustable
feet
Overload
protection
screws
Fig 1. Underside view of the scales
Fig 2. Display unit mounting options and views
OXFORD PRECISION
© The Kennedy Group Ltd. 08/04
05/08/2008
14:19
Page 1
Load
cell
Battery
compartment/
cover
Victoria Works, Leicester, England
OXFORD
PRECISION
Electronic Bench Scales
• Battery or mains powered
(batteries provided)
• Suitable for warehouse or light
industrial applications
• Wall or desk mounted display
• Dual reading – metric or imperial
• Capacities:
Model: BS-60E
60kg/132.28lb
Model: BS-120E 120kg/264.56lb
• RS232 Interface
OXD-844-5010K/OXD-844-5030K
INSTRUCTION MANUAL
Advertisement
Table of Contents
Related Manuals for Oxford PRECISION BS-60E
Summary of Contents for Oxford PRECISION BS-60E
- Page 1 • Suitable for warehouse or light industrial applications • Wall or desk mounted display • Dual reading – metric or imperial • Capacities: Model: BS-60E 60kg/132.28lb Model: BS-120E 120kg/264.56lb • RS232 Interface Fig 2. Display unit mounting options and views...
- Page 2 (x) _______ The input signal is too small. 1. Specifications (xi) Lo Low voltage. Model Capacity Graduation BS-60E 60kg/132.28lb 0.02kg/0.05lb 4. Advanced Operating Instructions BS-120E 120kg/264.56lb 0.05kg/0.1lb Protocols When scale’s “P” is pressed or the carriage return (0d hex) is received, PS-103 scale will 2.
