Arrow LW82 Owner's Manual & Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
729240519
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Storage
Size
8' x 2'
17 Sq. Ft. 100 Cu. Ft.
2,4 m x 0,6 m
1,6 m
* See Inside for Detailed Safety Information.
or
†
Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Area
Width
99 3/4"
2
2,8 m 3
253,4 cm
Depth
Height
Width
30 3/4"
82 1/8"
94 3/4"
78,1 cm
208,6 cm
240,7 cm
www.arrowsheds.com
Model No. LW82
Base
97 1/2" x 28 1/4"
247,7 cm x 71,8 cm
Size
For proper base construction see page 8
Interior Dimensions
(Wall to Wall)
Depth
Height
25 1/2"
80 1/8"
64,8 cm
203,5 cm
01HG
8' x 2'
Nominal Size
Door
Opening
Width
Height
43 1/2"
60"
110,5 cm
152,4 cm

Advertisement

loading
Need help?

Need help?

Do you have a question about the LW82 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow LW82

Summary of Contents for Arrow LW82

  • Page 1 01HG 729240519 Owner’s Manual & Assembly Guide www.arrowsheds.com Model No. LW82 Gloves must be worn at all times to reduce 8’ x 2’ risk of injury! Nominal Size Customer Service: 1-800-851-1085 Base 97 1/2” x 28 1/4” assist@arrowsheds.com 247,7 cm x 71,8 cm...
  • Page 3 03HN CAUTION • Care must be taken when handling various pieces of your building since many contain sharp edges. • Do NOT attempt to assemble your building before double checking that you have all the parts indicated in the parts lists. Any building left partially assembled may be seriously damaged by even light winds.
  • Page 4 HARDWARE LIST... 04HG Hardware Views by Key No. Key Part Part Qty. Description List 65103 Hex Nut (#8-32) 11/32 Hex. #2 Phillips 65900A Black Screw (#10B x 1/2) (13 mm) 65923 Bolt (#8-32 x 3/8) (10 mm) 65004 Screw (#8AB x 5/16) (8 mm) 66045 Door Handle 66646...

  • Page 5: Table Of Contents

    05HG PARTS LIST Part Qty. Part Views Part No. Description 6243 Wall Panel 16 11297 Front Wall Panel 17 11294 Rear Wall Angle 8700 Right Gable 8701 Left Gable 20 10498 Horizontal Door Brace 6278 Vertical Door Brace Door Track Splice 22 11295 23 11296 Door Track 24 10828 Roof Panel...
  • Page 6 06HG PARTS LIST Part Qty. Part Views Part No. Description 30 10829 Roof Beam 9916 Side Wall Channel 6646 Side Wall Angle 8941 Ramp 9379 Front Floor Frame 9377 Rear Floor Frame 8984 Side Floor Frame Corner Panel 6668 7905 Roof Beam Bracket 9204 Roof Beam Brace...
  • Page 7 ASSEMBLY BY KEY NO. 07HG...
  • Page 8 CONSTRUCTING A BASE... 14GQ No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 9 Step 1 09HG 9377 You will need for this page: Rear Floor Frame (QTY: 5) 9377 9377 Bolts thru Top. Overlap Length 11 7/8” 30,2 cm 95 7/8” 243,5 cm Bolts thru Bottom. Finished Length...
  • Page 10 Step 1 10HG 9379 8941 You will need for this page: Front Floor Frame Ramp (QTY: 8) Overlap Length 7 3/8” 18,7 cm 9379 95 7/8” 243,5 cm Finished Length 8941 9379 FRONT Drain holes must face outside the building. FRONT CHECK THAT ALL ASSEMBLED PARTS ARE THE CORRECT LENGTH BEFORE CONTINUING...
  • Page 11 Step 1 11HG 8984 You will need for this page: Assemblies from Step 1: • Front Floor Assembly (1) • Rear Floor Assembly (1) Side Floor Frame (QTY: 8) (QTY: 2) Do NOT fasten your Floor Frames to your Base at this time. You will anchor your building af- ter it is erected.
  • Page 12 Step 2 12HG 9924 11294 You will need for this page: (QTY: 2) Rear Wall Angle Rear Wall Channel 9924 9924 11294 11294 Overlap Length 6 1/8” 15,6 cm 94 5/8” 240,3 cm Finished Length...
  • Page 13 Step 2 13HG 66769 11295 11296 You will need for this page: Door Track Door Slide Track Splice (QTY: 4) 11296 11295 Painted Part The bottom side of the Door Tracks and the Door 11296 Track Splice has only four (4) holes. The top side has many holes.
  • Page 14 Step 3 14HG PANEL LAYOUT 6243 6243 6243 6243 TOP VIEW 6668 6668 Floor Frame Assembly 11297 FRONT 11297...

  • Page 15: Wall Panel

    Step 3 15HG 6668 6243 You will need for this page: Step 1 Floor Frame Wall Panel Corner Panel Assembly (QTY: 9) (QTY: 1) 6243 6668 Floor Frame Assembly Rear...

  • Page 16: Front Wall Panel

    Step 3 16HG 11297 You will need for this page: Front Wall Panel (QTY: 1) (QTY: 4) 11297 11297 FRONT...
  • Page 17 Step 3 17HG 6668 6243 You will need for this page: Wall Panel Corner Panel (QTY: 1) (QTY: 9) 6668 6243 Rear...
  • Page 18 Step 3 18HG 11297 You will need for this page: Front Wall Panel (QTY: 1) (QTY: 4) 11297 11297 FRONT...

  • Page 19: Rear Wall Angle

    Step 3 19HG 6646 Step 2 You will need for this page: Rear Wall Angle Assembly (QTY: 14) Side Wall Angle Wall Angles must face inside the building. Rear 6646 Rear Wall Angle Assembly 6646 FRONT Rear...
  • Page 20 Step 3 20HG Step 2 You will need for this page: Door Track Assembly (QTY: 4) Door Track Assembly Long Leg on Top. FRONT Opening Faces In. Short Leg on Bottom.
  • Page 21 Step 3 21HG 6243 You will need for this page: Wall Panel (QTY: 3) (QTY: 18) Crimped Rib Uncrimped Rib Uncrimped Rib Crimped Rib Crimped Rib Uncrimped Rib 6243 6243 Rear...
  • Page 22 Step 3 22HG 9369 66775 You will need for this page: (QTY: 8) (QTY: 6) Door Jamb Plug 9369 9369 66775 66775...
  • Page 23 Step 3 23HG Step 2 You will need for this page: Rear Wall Channel Assembly (QTY: 12) Rear Wall Channel Assembly Rear Rear...
  • Page 24 Step 3 24HG 9916 You will need for this page: (QTY: 2) (QTY: 8) Side Wall Channel 9916 9916...

  • Page 25: Right Gable

    Step 4 25HG 7905 8700 8701 You will need for this page: Right Gable Left Gable Roof Beam Bracket (QTY: 8) GABLES ARE STACKED TOGETHER DURING SHIPPING AND MAY BE MISTAKEN FOR ONE GABLE! SEPARATE GABLES BEFORE CONTINUING. FRONT 8700 8701 7905 7905...
  • Page 26 Step 4 26HG You will need for this page: Right Gable Assembly Left Gable Assembly (QTY/QTÉ/CANT: 32) Rear FRONT 6 26...
  • Page 27 Step 4 27HG 67293 10829 You will need for this page: (QTY: 12) Weather Stripping Roof Beam Tape BOTH Gable joints before installing Roof Beams. Top View of Gables Weather Stripping Tape 10829 10829 10829 10829 Beam End Views FRONT 6 27...
  • Page 28 Step 4 28HG 9204 You will need for this page: (QTY: 2) (QTY: 2) Roof Beam Brace Attach Brace to Gable then rotate to align with Roof Beam. Tab end attaches to Roof Beam. 9204 9204 Angled end attaches to Gable.
  • Page 29 Step 5 29HG 67293 10828 You will need for this page: Roof Panel Weather Stripping (QTY: 44) 10828 10828 6 29...
  • Page 30 Step 5 30HG 66183L 6868 6014 You will need for this page: Ridge Cap Side Roof Trim Left Roof Trim Cap (QTY: 4) (QTY: 4) 66183R 67468 Right Roof Trim Cap Peak Cap 67468 6868 66183 6014 67468 66183 66183 6014 66183 FRONT...
  • Page 31 Step 6 31HG 10478 6278 66045 You will need for this page: Door Vertical Brace (QTY: 2) (QTY: 3) Handle 10478 66045 6278...
  • Page 32 Step 6 32HG 10498 66382 You will need for this page: Horizontal Brace Door Guide 10498 (QTY: 6) 66382 66382 Repeat these steps for the other door. 10498...

  • Page 33: Door Track

    Step 6 33HG You will need for this page: Right Door Assembly Left Door Assembly (QTY: 8) Gable From inside the building, place the Door Slide bottom of the Door into the Front Floor Frame track at about the half- open position.
  • Page 34 The entire fl oor frame MUST be securely anchored once the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
