MICRO-MARK MicroLux 86892 Instructions Manual

Wood turner's lathe
Hide thumbs

Advertisement

Table of Contents

#86892
8" x 12"
Wood Turner's athe
lease read and understand all instructions before using this tool.
Note: These instructions will show you how to assemble this machine,
work its controls and maintain it for long life.
t is not intended as an educational course on how to make parts using a lathe.
Made in China for
340 Snyder Avenue
Berkeley Heights, NJ 07922
For technical assistance, email Tech@micromark.com
©Micro-Mark
MM041217

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MicroLux 86892 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MICRO-MARK MicroLux 86892

Summary of Contents for MICRO-MARK MicroLux 86892

  • Page 1 Made in China for 340 Snyder Avenue Berkeley Heights, NJ 07922 For technical assistance, email Tech@micromark.com ©Micro-Mark MM041217...
  • Page 2 INTRODUCTION Your 8” x 12” Variable Speed Wood Lathe is a dependable tool designed to assist you in turning many types of projects. It is easy to assemble and to operate and is an ideal lathe for those just getting started in wood turning and experienced users alike.
  • Page 3 GENERAL SAFETY INFORMATION WARNING: To avoid mistakes that could cause When turning a workpiece, always rough the wood to round form serious injury, do not plug the lathe in until at a slow speed. If the lathe runs so fast that it vibrates, there is the following steps have been read and understood.

  • Page 4: Bolt

    Faceplate Spindle Headstock Power cord Speed control knob Circuit breaker reset button Switch Tool rest banjo 10 Base lock lever 11 Tool rest lock lever (long) 12 Tool rest 13 Tailstock 14 Tailstock spindle 15 Hand wheel 16 Tailstock spindle lock lever (short) 17 Tailstock cup center 18 Tailstock lock lever 19 Flat wrench...

  • Page 5: Tailstock

    SPRING-LOADED LOCK LEVERS INSTALLING THE DRIVE SPUR AND LIVE CENTER Assemble the Spring-Loaded lock levers for the tailstock spindle 1. Insert the shaft of the spur (1) into the hollow center of the and the tool rest. The shoulder screw (1) passes through the spring headstock spindle.

  • Page 6: Switch

    SPEED CONTROL ADJUSTMENTS The speed control knob (3) sets the speed of the lathe to suit the The variable speed control contains the electrical connections to the motor and has three external controls: ON/OFF switch, speed weight of the workpiece or the type of tool being used. After the lathe control knob, and the circuit breaker reset button.

  • Page 7: Faceplate

    TAILSTOCK OPERATION TOOL REST OPERATION 1. Move the tailstock (5) by loosening the lock lever (1) and pushing 1. Loosen the lock lever (4) to move the tool rest (1) banjo to the the tailstock to the desired position on the bed. Lock by tightening right or left and back or wherever required.

  • Page 8: Table Of Contents

    Part No. Description Part No. Description Part No. Description Headstock Bolt Retaining plate Speed dial switch Plate Bolt Speed dial label Bolt Headstock spindle nut Sleeve Hand wheel Plate cover Eccentric rod Tailstock Bolt Tool rest Spindle lock screw Spec label Bolt Bolt Bolt...

  • Page 9: Motor

    Micro-Mark makes no other warranty of any kind whatever, expressed or implied, and all implied warranties of merchantability and fitness for a particular purpose which exceed the above mentioned obligation are hereby disclaimed by Micro-Mark and excluded from this warranty.
