BA400-Series Enclosures
Storage Devices
Installation Procedures
Order Number: EK–BA44A–IN. K01
Revision Information:
Digital Equipment Corporation
Maynard, Massachusetts
This manual supersedes
EK–BA44A–IN. J01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DEC BA400 Series

Summary of Contents for DEC BA400 Series

  • Page 1 BA400-Series Enclosures Storage Devices Installation Procedures Order Number: EK–BA44A–IN. K01 Revision Information: This manual supersedes EK–BA44A–IN. J01 Digital Equipment Corporation Maynard, Massachusetts...
  • Page 2 The following are trademarks of Digital Equipment Corporation: CompacTape, CX, DDCMP, DEC, DECconnect, DECdirect, DECnet, DECscan, DECserver, DECUS, DECwindows, DELNI, DEMPR, DESQA, DESTA, DSRVB, DSSI, IVAX, KDA, KLESI, KRQ50, MicroVAX, MSCP, Q–bus, Q22–bus, RA, RQDX, RV20, SA, SDI, ThinWire, TMSCP, TQK, TS05, TU, VAX, VAX 4000, VAXcluster, VAX DOCUMENT, VAXELN, VAXlab, VAXserver, VMS, VT, and the DIGITAL logo.

  • Page 3: Table Of Contents

    Contents Preface ........... . . 1 EF- and RZ-Series Integrated Storage Elements General .
  • Page 4 2 TLZ-Series Tape Drives General ..........2–1 TLZ07 Tape Drive .
  • Page 5 A Related Documentation Index Figures 1–1 EF-Series ISE (Front and Rear View) ....1–2 1–2 3.5-inch RZ-Series ISE (Rear View) ....1–3 1–3 Front Panel Assembly .
  • Page 6 Tables 1–1 DVTST Error Messages ......1–33 5–1 Power-on Self-test Events ......5–8...

  • Page 7: Preface

    Preface This manual describes add-on installation procedures for the various storage devices available for BA400-series system enclosures. Structure of This Manual Chapter 1 describes the installation of EF- and RZ-series integrated storage elements. Chapter 2 describes the installation of TLZ-series tape drives. Chapter 3 describes the installation of RRD-series CD-ROM drives.

  • Page 9: Ef- And Rz-Series Integrated Storage Elements

    EF- and RZ-Series Integrated Storage Elements 1.1 General Figure 1–1 shows the EF-series integrated storage elements (ISE). Figure 1–2 shows the RZ-series ISEs in the 3.5-inch configuration. Note that the logic module is located on the right side for the RZ-series. The two configurations vary as follows: •...

  • Page 10: Ef-Series Ise (Front And Rear View)

    Figure 1–1 EF-Series ISE (Front and Rear View) Bracket Slides Bracket Slides Front View Rear View MLO-009301 1–2 EF- and RZ-Series Integrated Storage Elements...

  • Page 11: Inch Rz-Series Ise (Rear View)

    Figure 1–2 3.5-inch RZ-Series ISE (Rear View) RZ-Series From back of drive: the screw hole is offset to the right for SCSI. 50-Pin Signal Cable 4-Pin Power Cable MLO-011782 EF- and RZ-Series Integrated Storage Elements 1–3...

  • Page 12: Front Panel Assembly

    Figure 1–3 shows the front panel assembly that comes with the ISEs. Figure 1–3 Front Panel Assembly Phillips Screw MLO-007236 The term "Integrated Storage Element" (ISE) is used for any Digital Storage Systems Interconnect (DSSI) or Small Computer System Interface (SCSI) storage device.
  • Page 13 Note Within a system enclosure it is possible to have up to seven disk storage devices, provided there is no tape drive in the enclosure. There can be three 3.5-inch dual storage devices and one 5.25-inch or one 3.5-inch single storage device. For more detailed information about configuring EF- and RZ-series ISEs in a BA400-series enclosure, refer to the appropriate enclosure maintenance manual listed in Appendix A.

  • Page 14: Ef- And Rz-Series Ise Installation Preparation

    1.2 EF- and RZ-Series ISE Installation Preparation EF- and RZ-series ISEs require that bus node ID jumpers be set on the drive before the ISE can be installed in a BA400-series enclosure. When installing an EF- or RZ-series ISE, refer to the reference booklet or data sheet that is shipped with the ISE to set the proper bus node ID (DSSI/SCSI ID) jumpers.

  • Page 15: Installation Procedure

    1.3 Installation Procedure To install an EF- or RZ-series ISE in a BA400-series enclosure, perform the following procedures. 1.3.1 ISE Installation in an Empty Slot CAUTION Static electricity can damage integrated circuits. Use the anti-static wrist strap and antistatic pad found in the static-protective field service kit (29-26246-00) when you work with the internal parts of a computer system.

  • Page 16: Power Switch Location

    Figure 1–4 Power Switch Location Power Switch MLO-006627 1–8 EF- and RZ-Series Integrated Storage Elements...

  • Page 17: Ba440 Enclosure

    3. Always install ISEs working from right to left (Figure 1–5). Figure 1–5 BA440 Enclosure Slot 3 Slot 2 Slot 1 Slot 0 MLO-006528 NOTE The first (slot 0) mass storage cavity in the mass storage area is wider than the rest to accommodate a larger device, such as a tape drive. A small filler panel (70-27414-01) is used to fill the gap when an EF- or RZ-series ISE is installed in this first cavity.

  • Page 18: Blank Front Panel Assembly

    4. Loosen the captive Phillips screw that secures the blank ISE front panel assembly (Figure 1–6), and remove the panel. Figure 1–6 Blank Front Panel Assembly Phillips Screw MLO-007236 1–10 EF- and RZ-Series Integrated Storage Elements...

  • Page 19: Removing The Plastic Skid Plate From The Ef-Series Ise

    5. For 5.25-inch EF-series ISEs, remove the plastic skid plate from the right side (remove the four screws) of the device (Figure 1–7). Discard the skid plate. Figure 1–7 Removing the Plastic Skid Plate from the EF-Series ISE Skid Plate Screws Screws MLO-009302...

  • Page 20: Installing The Ise In The Storage Cavity

    Figure 1–8 Installing the ISE in the Storage Cavity Captive Screws Phillips Screw Guide Tabs Finger Cutouts Front Panel MLO-007244A 7. Refer to Figure 1–8A and install the ISE. Using the tabs in front of upper and lower finger cutouts, firmly push the ISE brackets until the interface card at the rear of the storage device plugs into its backplane connector.
  • Page 21 8. Tighten the two captive screws at the top and bottom of the bracket. CAUTION It is normal for there to be a small gap between the ISE mounting bracket tabs and the enclosure frame. Tighten the captive screws only until they are securely fastened (9 inch-pounds).

  • Page 22: Upgrading The Ise Storage Devices

    1.4 Upgrading the ISE Storage Devices The system’s storage capacity can be increased by: • Replacing an ISE with one that has a larger storage capacity • Installing a second storage device on a 3.5-inch ISE The following sections describe how to upgrade the ISE storage devices. 1.4.1 Removing ISEs To upgrade a system, it may be necessary to remove an ISE.

  • Page 23: Keylock Positions

    Figure 1–9 Keylock Positions Key Lock Top Key Position MLO-004034 Power Switch MLO-004035 Bottom Key Position MLO-012859 EF- and RZ-Series Integrated Storage Elements 1–15...
  • Page 24 3. Loosen the captive Phillips screw that secures the ISE front panel and remove the panel (Figure 1–10/Step 1). 4. Loosen the upper and lower captive screws that hold the ISE in place (Figure 1–10/Step 2). 5. Using the upper and lower finger cutouts on the ISE brackets, carefully pull the ISE out of its backplane connector and slide the drive out of the enclosure.

  • Page 25: Removing The Ise To Be Upgraded Or Replaced

    Figure 1–10 Removing the ISE to Be Upgraded or Replaced Captive Screws (loosen) Phillips Screw Guide Tabs Finger Cutouts (pull) Front Panel MLO-007247A EF- and RZ-Series Integrated Storage Elements 1–17...

  • Page 26: Installing A Second Storage Device In A 3.5-Inch Ise

    1.4.2 Installing a Second Storage Device in a 3.5-inch ISE The upgrade kit for the 3.5-inch ISE contains the following: • Storage device • Mounting hardware—four Phillips screws • BA400-Series Enclosures Storage Devices Installation Procedures • Drive reference booklet or data sheet The following sections describe how to install a second storage device in a 3.5-inch ISE.

  • Page 27: Removing The Top Outside Bracket From The Ise

    Figure 1–11 Removing the Top Outside Bracket from the ISE From back of drive: the screw hole is Top Bracket offset to the right for SCSI. Flange Interface Card Assembly 50-Pin Signal Cable 4-Pin Power Cable MLO-011783 4. Gently turn the storage device upside down so that it rests on the top inside bracket.

  • Page 28: Installing The New Storage Device

    1.4.2.2 Installing the New Storage Device Note Before installing an RZ-series ISE, ensure that the bus node ID jumpers are properly set and that the TERM ENABLE jumper is removed. Some of the ISEs have two sets of jumpers for setting the bus node ID.

  • Page 29: Installing The Phillips Screws That Secure The Storage Device To The Inside Brackets

    Figure 1–12 Installing the Phillips Screws That Secure the Storage Device to the Inside Brackets Phillips Screws Bottom of ISE Bottom Inside Bracket Controller Modules MLO-007246 Installation Notes When you install the new drive, be sure to complete the following: 1.

  • Page 30: Installing Upgraded Ises In The Mass Storage Cavity

    1.4.3 Installing Upgraded ISEs in the Mass Storage Cavity To install a 5.25-inch ISE upgrade or an upgraded 3.5-inch ISE, complete the following procedure: 1. For the EF-series ISEs, with the side that had the skid plate attached to it facing to the right, slide the ISE along the guide rails into the mass storage cavity (Figure 1–13A).

  • Page 31: Bus Node Id Configuration Guidelines

    Figure 1–13 Installing the ISE Upgrade in the Storage Cavity Captive Screws Phillips Screw Guide Tabs Finger Cutouts Front Panel MLO-007244A 1.4.4 Bus Node ID Configuration Guidelines The EF- and RZ-series ISEs require setting jumpers on the storage device for the bus node ID.

  • Page 32: Power-On Self-Test (Post)

    • For each DSSI bus or SCSI bus, do not duplicate bus node numbers for storage elements. You can have only one storage element on bus 0 identified as node 0, one storage element as node 1, and so on. •...

  • Page 33: Setting The Dssi Ise Parameters

    1.6 Setting the DSSI ISE Parameters Once installed and powered up, the DSSI ISE parameters must be set. This is done through the use of the local program PARAMS. The following procedures should be used when performing an ISE installation. If further information on the use of PARAMS is desired, refer to the appropriate integrated storage element user’s guide (see Appendix A) for a complete description of the PARAMS utility.

  • Page 34: Using Console Commands

    1.6.1.2 Using Console Commands From console mode you can access the Diagnostic and Utility Program (DUP) to examine and set parameters. The command syntax depends upon whether your system uses an embedded adapter such as the KA670 module, or a Q–bus adapter (the KFQSA module).

  • Page 35: Using Mdm

    1.6.1.3 Using MDM If neither OpenVMS nor console commands are available on your system, you can access PARAMS through MDM using the following procedure: 1. Boot MDM. 2. Enter the date and time. 3. Select the menus in the following order: •...

  • Page 36: Setting The Ise Allocation Class

    1.6.2 Setting the ISE Allocation Class All DSSI ISEs are shipped with the allocation class set to 0. To determine what the allocation class should be set to, access a different ISE on the system and set the one you are installing to the same allocation class. In multihost systems, you must assign the same allocation class to all host systems and all connected ISEs.
  • Page 37 5. Enter SHOW ALLCLASS. The system responds with: Parameter Current Default Type Radix --------- ----------- ----------- ------ ------- ALLCLASS Byte PARAMS> 6. Enter SET ALLCLASS 1 (for our example). You want to set the ISE to the same allocation class as all the other ISEs on the DSSI bus. 7.

  • Page 38: Setting The Mscp Unit Number

    1.6.3 Setting the MSCP Unit Number The ISE is set at the factory to read the DSSI node ID as the MSCP unit number. Unit numbers for all DSSI devices connected to a system’s associated DSSI buses must be unique. When more than one bus is being used, and your system is using a nonzero allocation class, you need to assign new unit numbers for devices on all but one of the DSSI buses.

  • Page 39: Setting The Ise Node Name

    1.6.4 Setting the ISE Node Name Setting the ISE node name is an optional step. All DSSI ISEs come with a computer-generated node name. The user may wish to set this node name to a more recognizable character string. The following example changes the node name from the default (R1EJAA) to the new string "SUSAN."...

  • Page 40: Drvtst Example

    Once the ISE has passed DRVTST, the installation is complete. If further information on the use of DRVTST is desired, refer to the appropriate integrated storage element user’s guide (see Appendix A) for a complete description of the DRVTST local program. 1.7.1 DRVTST Example The following example shows how to run DRVTST.

  • Page 41: Error Messages

    1.7.2 Error Messages If an error condition is found during the execution of DRVTST, an error message is displayed. Two types of errors are reported: soft errors, which are corrected during the operation of the ISE, and fatal errors, which prevent the ISE from functioning.

  • Page 43: Tlz-Series Tape Drives

    TLZ-Series Tape Drives 2.1 General This chapter describes how to install the TLZ-series tape drive. For more detailed information about installing add-on storage devices into a BA400- series enclosure, refer to the appropriate enclosure maintenance guide (see Appendix A). 2.2 TLZ07 Tape Drive The TLZ07 is a 5.25-inch half-height cassette tape drive that provides high capacity, off-line data storage.

  • Page 44: Tlz07 Installation Preparation

    2.3 TLZ07 Installation Preparation TLZ07 tape drives require that bus node ID jumpers or DIP switches be set on the drive before the ISE is installed in a BA400-series enclosure. The TLZ07 tape drive has both jumpers and DIP switches that can be used to set the bus node ID, but only one or the other must be used.

  • Page 45: Tlz07 Installation Procedure

    2.4 TLZ07 Installation Procedure Use the following procedure to install the TLZ07 tape drive into a BA400-series enclosure. Have the system manager shut down the operating system before installing the tape drive. CAUTION Static electricity can damage integrated circuits. Use the antistatic wrist strap and antistatic pad found in the static-protective field service kit (29-26246-00) when you work with the internal parts of a computer system.

  • Page 46: Opening The Enclosure Doors

    Figure 2–1 Opening the Enclosure Doors Key Lock Top Key Position MLO-004034 Slot 0 Power Switch MLO-004035 Bottom Key Position MLO-012856 2–4 TLZ-Series Tape Drives...
  • Page 47 4. With the tape drive left side down (LEDs at the bottom), slide the drive into mass storage slot 0. Using the tabs in front of the upper and lower finger cutouts, firmly push the drive bracket into the enclosure until the interface card at the rear of the drive plugs into its backplane connector.

  • Page 48: Installing The Tlz07 Drive

    Figure 2–2 Installing the TLZ07 Drive Tighten screw. Tighten screw. Insert bezel. MLO-011787 2–6 TLZ-Series Tape Drives...

  • Page 49: Completing The Tlz07 Installation

    2.5 Completing the TLZ07 Installation This section explains how to verify successful installation of the TLZ07 drive by performing the power-on self-test (POST), and then assigning a device name to the drive. 2.5.1 TLZ07 Power-On Self-Test Use the following procedure to execute the POST: 1.

  • Page 51: Rrd-Series Cd-Rom Drive

    RRD-Series CD–ROM Drive 3.1 General RRD-Series CD–ROM drives are compact disc, read-only memory (ROM), Small Computer System Interface (SCSI) devices. These drives read data from industry standard 600-MB discs. To meet the requirements of a wide variety of applications, the RRD-series of CD–ROM drives support all CD– ROM standards including CD–ROM-XA (CD–ROM-eXtended Architecture), Multisession Photo CD, and MPC (Multimedia Products Council) 1 and 2, and is CD-I ready.

  • Page 52: Installation Procedure

    3.3 Installation Procedure Use the following procedure to install the RRD-series CD–ROM drives into the BA400-series enclosure. Have the system manager shut down the operating system before installing the CD–ROM drive. CAUTION Static electricity can damage integrated circuits. Use the antistatic wrist strap and antistatic pad found in the static-protective field service kit (29-26246-00) when you work with the internal parts of a computer system.

  • Page 53: Opening The Enclosure Doors

    Figure 3–1 Opening the Enclosure Doors Key Lock Slot 3 Slot 2 Slot 1 Top Key Position MLO-004034 Power Switch MLO-004035 Bottom Key Position MLO-012857 RRD-Series CD–ROM Drive 3–3...
  • Page 54 4. Refer to Figure 3–2 to install the CD–ROM drive into the mass storage slot: Using the tabs in front of the upper and lower finger cutouts, firmly push the drive brackets until the interface card at the rear of the drive plugs into its backplane connector (A).

  • Page 55: Inserting The Rrd Cd-Rom Drive

    Figure 3–2 Inserting the RRD CD–ROM drive Captive Screw Finger Cutouts Phillips Screw Guide Tabs MLO-011784 RRD-Series CD–ROM Drive 3–5...

  • Page 56: Kzqsa In Connector

    8. Locate the KZQSA IN connector on the I/O bulkhead. Figure 3–3 KZQSA IN Connector KZQSA In MLO-007150 3–6 RRD-Series CD–ROM Drive...

  • Page 57: Removing The Connector Cover

    9. Remove the protective cover from the KZQSA IN connector. Figure 3–4 Removing the Connector Cover Protective Cover MLO-007168 10. Locate the KZQSA internal cable labeled BC06P–2F that ships with the RRD drive. Figure 3–5 KZQSA Cable MLO-007151 RRD-Series CD–ROM Drive 3–7...

  • Page 58: Connecting To Kzqsa In

    11. Connect one end of the cable to the KZQSA IN connector. Press the bail latches onto the cable connector to lock it in place. Figure 3–6 Connecting to KZQSA IN MLO-007152 12. Locate the KZQSA module identified by the KZQSA-SA indentification label on the module cover.

  • Page 59: Kzqsa Label

    Figure 3–7 KZQSA Label KZQSA M5976 MLO-007153 13. Remove the terminator from the upper connector on the module. Figure 3–8 KZQSA Module Connector MLO-007179 RRD-Series CD–ROM Drive 3–9...

  • Page 60: Connecting To Kzqsa In

    14. Connect the other end of the cable to the KZQSA module connector. Press the bail latches onto the cable connector to lock it in place. Figure 3–9 Connecting to KZQSA IN Bail Latch Feed Cable Under System and Up Through Opening. MLO-007154 3–10 RRD-Series CD–ROM Drive...

  • Page 61: Completing The Installation

    3.4 Completing the Installation This section explains how to verify successful installation of the RRD CD–ROM drive by performing the power-on self-test (POST). 3.4.1 RRD CD–ROM Power-On Self-Test Use the following procedure to execute the POST: 1. Power on the system. •...

  • Page 63: Rrd/Tlz07 Dual Ise Drives

    RRD/TLZ07 Dual ISE Drives 4.1 General This chapter describes how to install the RRD/TLZ07 Dual ISE in the BA400- series enclosure. The RRD/TLZ07 Dual ISE contains a multi-purpose CD–ROM drive and a 5.25-inch cassette tape drive. Note VAX 4000 systems do not support the RRD/TLZ07 Dual ISE unless an HSD05 or HSD10 option is installed.

  • Page 64: Installation Procedure

    Note If the DIP switches on the TLZ07 drive are used to set the bus node ID, ensure that all of the bus node ID jumpers are removed. If the jumpers are used to set the bus node ID on the TLZ07 drive, ensure that all of the bus node ID DIP switches are set to 0.

  • Page 65: Opening The Enclosure Doors

    Figure 4–1 Opening the Enclosure Doors Key Lock Top Key Position MLO-004034 Slot 0 Power Switch MLO-004035 Bottom Key Position MLO-012856 RRD/TLZ07 Dual ISE Drives 4–3...
  • Page 66 4. Remove the center (plastic) card guides from the top and bottom storage divider in slot 0 (the guides are a pressure fit and lift right out). 5. With the tape drive left side down (LEDs at the bottom), slide the drive into mass storage slot 0.

  • Page 67: Installing The Rrd/Tlz07 Dual Ise

    Figure 4–2 Installing the RRD/TLZ07 Dual ISE Tighten screw. Tighten screw. Insert bezel. MLO-011786 RRD/TLZ07 Dual ISE Drives 4–5...

  • Page 68: Completing The Installation

    4.4 Completing the Installation This section explains how to verify correct installation of the RRD/TLZ07 dual ISE drives by performing the power-on self-test (POST). Section 4.4.1 describes the POST for a CD–ROM drive. Section 4.4.2 describes the POST for a TLZ07 tape drive. 4.4.1 RRD CD-ROM Power-On Self-Test Use the following procedure to execute the POST: 1.

  • Page 69: Tlz07 Power-On Self-Test

    4.4.2 TLZ07 Power-On Self-Test Use the following procedure to execute the POST: 1. Power on the system. • If there is no cassette in the drive: The Cassette and Write-Protect indicators flash for approximately 1 to 5 seconds and then shut off. •...

  • Page 71: Tz-Series Tape Drive

    TZ-Series Tape Drive 5.1 General This chapter describes how to install the TZ-series of tape drive. Figure 5–1 shows the front panel of the TZ86 tape drive and is representative of this series of drives. Figure 5–1 TZ86 Tape Drive Front Panel Unload Button Write-Protected...

  • Page 72: Tz-Series Tape Drive Installation Preparation

    The following table lists the tape drives and cartridge type along with storage capacity. Drive Type Cartridge Type Storage Capacity TZ85 CompacTape III 2.6 GB formatted TZ86 CompacTape III 6.0 GB formatted TZ87 CompacTape III 10.0 GB formatted, uncompressed 20.0 GB formatted, compressed TZ87X CompacTape IIIXT 15.0 GB formatted, uncompressed...

  • Page 73: Tz-Series Tape Drive Installation

    In VAX 4000 systems, the SCSI termination and TERM PWR are provided by the controller module on one end of the bus and termination for the other end of the bus is provided by an external terminator. Note Refer to Section 1.4.4 for bus node ID configuration guidelines. 5.3 TZ-Series Tape Drive Installation Use this procedure to install TZ-Series tape drives.

  • Page 74: Power Switch Location

    Figure 5–2 Power Switch Location Power Switch MLO-006628 2. Loosen the captive Phillips screws (at the top) and remove the blank front panel (70-27049-01) and filler panel (70-27414-01) located in mass storage slot 0. Note The TZ-series tape drive is installed only in mass storage slot 0. 3.
  • Page 75 5. Refer to Figure 5–3 to complete the installation of the drive. a. Tighten the two captive screws at the top and bottom of the bracket (A). CAUTION It is normal for there to be a small gap between the mounting bracket tabs and the enclosure frame.

  • Page 76: Installing The Tz-Series Drive

    Figure 5–3 Installing the TZ-Series Drive Captive Screws (2) Finger Cutouts Phillips Screw Guide Tabs MLO-011788 5–6 TZ-Series Tape Drive...

  • Page 77: Tz-Series Drive Installed In Mass Storage Slot

    Figure 5–4 shows the TZ-series tape drive installed in the enclosure. Figure 5–4 TZ-Series Drive Installed in Mass Storage Slot 0 Slot 3 Slot 2 Slot 1 Slot 0 MLO-006528 TZ-Series Tape Drive 5–7...

  • Page 78: Completing The Installation

    5.4 Completing the Installation This section explains how to verify successful installation of the TZ-series tape drives by performing the power-on self-test (POST). 5.4.1 TZ-Series Power-On Self-Test When the TZ-series subsystem is powered on, the drive performs the power-on self-test (POST). The sequence of events are listed in Table 5–1. Table 5–1 Power-on Self-test Events Stage What Happens...

  • Page 79: Setting The Ise Parameters

    5.5 Setting the ISE Parameters For TZ-series tape drives the SCSI ISE parameters are set in the same manner as the RZ-series ISEs. Refer to the HSD05 DSSI-to-SCSI Bus Adapter Operation Information for BA400-Based VAX 4000 Systems manual (EK– HSDC5–IN) or the HSD10 DSSI-to-SCSI Bus Adapter Operation Information for VAX 4000 Systems manual (EK–HSD10–OP) for this procedure.
  • Page 81 TX86 Series Cartridge Tape Subsystems EK–OTX86-OM TZ87 Cartridge Tape Subsystems EK–OTZ87-OM TZ88 DLT Series Tape Drive Owner’s Manual EK–TZ88N-OM BA400 Series Mass Storage Devices EK–441AC–IP HSD05 DSSI-to-SCSI Bus Adapter Operation Information EK–HSDC5–IN for BA400-Based VAX 4000 Systems HSD10 DSSI-to-SCSI Bus Adapter Operation Information EK–HSD10–OP...
  • Page 83 Index 3.5-inch ISE, 1–1 Front panel assembly, 1–4 accessing PARAMS, 1–25 using console commands, 1–26 using MDM, 1–27 using OpenVMS, 1–25 Hierarchical storage controllers (HSCs), 1–28 bus node ID configuration guidelines, 1–23 Installing new ISEs in the mass storage numbering, 1–23 cavity, 1–22 Installing Second Storage Device in a 3.5-inch ISE, 1–18...
  • Page 84 ISE PARAMS installation preparation, 4–1 setting, 1–25 RZ-series integrated storage element, 1–1, 1–4 installation preparation, 1–6 installation procedure, 1–7 MSCP problem resolution, 1–33 setting unit number, 1–30 TLZ07 panel indicators tape capacity, 2–1 TZ-series tape drive front panel, 5–1 TLZ07 tape drive PARAMS, 1–25 general description, 2–1 setting allocation class, 1–28...
  • Page 85 How to Order Additional Documentation Technical Support If you need help deciding which documentation best meets your needs, call 800-DIGITAL (800-344-4825) and press 2 for technical assistance. Electronic Orders If you wish to place an order through your account at the Electronic Store, dial 800-234-1998, using a modem set to 2400- or 9600-baud.
  • Page 87 Reader’s Comments BA400-Series Enclosures Storage Devices Installation Procedures EK–BA44A–IN. K01 Your comments and suggestions help us improve the quality of our publications. Thank you for your assistance. I rate this manual’s: Excellent Good Fair Poor Accuracy (product works as manual says) Completeness (enough information) Clarity (easy to understand) Organization (structure of subject matter)
  • Page 88 Do Not Tear – Fold Here and Tape No Postage Necessary If Mailed in the United States BUSINESS REPLY MAIL FIRST CLASS PERMIT NO. 33 MAYNARD MASS. POSTAGE WILL BE PAID BY ADDRESSEE DIGITAL EQUIPMENT CORPORATION Shared Engineering Services DIGITAL DRIVE MKO1-2/E12 PO BOX 9501 MERRIMACK, NH 03054–9982 Do Not Tear –...
