QUICK START GUIDE
OZONOS TRIPOD
STARTUP
IMPORTANT INFORMATION
This manual describes the correct installation of the device.
Please follow all steps properly and observe warnings and
notes!
SETUP OZONOS TRIPOD
STEP 1
Mount the holder for
the OZONOS Aiclea-
ner firmly on the thread
of the tripod.
STEP 3
Pull your legs apart to a
maximum angle where
they are stable.
Tighten the locking
screw again.
STEP 5
Now attach the roll.
The brake must point
outwards and the lo-
cking screw inwards!
Ziehen sie nun die
Feststellschraube
wieder fest.
STEP 2
Loosen the locking
screw of the tripod
legs until they can be
moved.
STEP 4
Loosen the locking
screw on the wheel and
insert the metal piece.
STEP 6
Tighten the brake of
the mounted wheel.
Repeat steps 4-6 for
all three wheels.
2019/02
