- Page 1 e l e c t r o n i c Assembly and Commissioning Instructions Softstarters VS ... - 17...45 Quality is our Drive.
-
Page 2: Table Of Contents
VS II ...-17 ... 45 as per 07/10 15700.10005 Table of Contents Page Safety notes Conformity General description Usage to the intended purpose EC Declaration of Conformity Block diagram Commissioning Mounting instructions Connection Parameter settings LED indicators Option „M“ Fault Fault description Fault remedy Resetting of faults... - Page 3 VS II ...-17 ... 45 14. Dimensions 15. Special units These commissioning instructions were prepared with great care. Nevertheless, Advanced Control does not assume liability for damage resulting from mistakes possibly contained in this manual. Technical changes that serve to improve the product are subject to change without notice.
-
Page 4: Safety Notes
VS II ...-17 ... 45 Safety notes The described devices are electrical equipment for use in industrial electrical power installations. An impermissible removal of the covers during operation can cause serious damage to your health, since these devices contain live parts with high voltages. -
Page 5: General Description
VS II ...-17 ... 45 General description In the case of the soft starters of the VersiStart II type the motor voltage is changed in two phases (1L1/5L3) by a generalized phase control and power semiconductors. Starting from an adjustable starting trigger angle the trigger angle is continually reduced. -
Page 6: Ec Declaration Of Conformity
VS II ...-17 ... 45 EC Declaration of Conformity EC Declaration of Conformity The manufacturer / company placing the product on the market (authorized representatives of the manufacturer / companies placing the product on the market that are established within the Community) Name / Address: Peter Electronic GmbH &... -
Page 7: Block Diagram
VS II ...-17 ... 45 Block diagram control supply U 24VDC at option "B" supply voltage Start t acc t dec Electronics Boost Trigger Ramp pulse control generator Control U start bypass Commissioning The device is to be put into operation in 3 steps: 1. - Page 8 VS II ...-17 ... 45 3. The device has to be installed into a housing (min. degree of protection: IP54). Please take care of a sufficient heat dissipation. 4. The device must be operated without being exposed to contamination by water, oil, carbon deposits, dust, etc..
-
Page 9: Connection
X1 and X2 have to be bridged. Adjusting the control type Devices of the VersiStart II series may be controlled by two types of control. 1. Control with a switching contact or switching transistor between terminal X1 and X2. -
Page 10: Parameter Settings
VS II ...-17 ... 45 Parameter settings On the front panel there are 3 potentiometers by means of which the following settings can be made. Parameter Poti Setting range Acceleration time Acceleration time adjustable from 0.5...10sec Starting voltage 40…80% of rated voltage Start Deceleration time adjustable from 0.5...10sec... - Page 11 VS II ...-17 ... 45 Adjusting soft stop Note: Soft stop is only useful for pump drives or applications in the case of which the drive comes to a stop immediately after switch off. In the case of drives driving high-inertia loads, soft stop is not sensible. Note: To enable soft stop, the VersiStart II, during the deceleration phase, has to be supplied with power from the supply mains.
-
Page 12: Led Indicators
VS II ...-17 ... 45 LED indicators On the device front panel there are 2 light-emitting diodes indicating the following operational states. Operational status Green Device is connected to mains voltage Yellow Start completed, device bypassed Yellow - flashing Soft start / Soft stop with increasing or decreasing frequency Yellow - flashing Fault... -
Page 13: Fault
VS II ...-17 ... 45 Fault The device series VersiStart II monitors various fault conditions. If a fault is detected, the device signals the fault with the yellow LED (flashing at constant frequency). In the case of a fault, the signaling relay RA 1 is opened. -
Page 14: Fault Remedy
VS II ...-17 ... 45 Fault remedy In case of a fault, please proceed as follows: Fault 1: Check the frequency of starts and the starting current and also observe the max. ambient temperature. Give the device and/or the motor enough time between starts to cool down. -
Page 15: Technical Data (Standard)
VS II ...-17 ... 45 10. Technical data (standard)* Type designation, VersiStart VS II 400-17 VS II 400.25 VS II 400-32 VS II 400-45 Mains / motor voltage 400V ±10% 50/60Hz acc. to DIN EN 50160 (IEC 38) Control supply voltage U only in 24VDC ±10%/150mA the case of option „B“... -
Page 16: Environmental Conditions
VS II ...-17 ... 45 10.1 Environmental conditions Storage temperature -25 ... 70°C Ambient temperature 0 ... 45°C up to an installation altitude of 1000m, not exposed to moisture condensation Power reduction above 45°C - 2% per 1°C up to max. 60°C and altitudes above 1000m -2% per 100m Degree of protection IP 20... - Page 17 Advanced control does not prescribe the use of semiconductor protection Note: fuses. However, for some UL- or CSA-listed devices there are exceptions which are indicated in the relevant commissioning instructions.
-
Page 18: Determining The Permissible Starting Frequency
VS II ...-17 ... 45 11.2 Determining the permissible starting frequency The starting frequency depends on the: 1. starting current or the heat loss across the power semiconductors. 2. current carrying capacity and the temperature increase of the power semiconductors. 3. - Page 19 VS II ...-17 ... 45 VersiStart II 400-25 1000 2xIe 3xIe 4xIe 5xIe 6xIe 2xIe 3xIe 4xIe 5xIe 6xIe Anlaufzeit/Ramp-up time (s) VersiStart II 400-32 1000 2xIe 3xIe 4xIe 5xIe 6xIe 2xIe 3xIe 4xIe 5xIe 6xIe Anlaufzeit/Ramp-up time (s)
- Page 20 VS II ...-17 ... 45 VersiStart II 400-45 1000 2xIe 3xIe 4xIe 5xIe 6xIe 2xIe 3xIe 4xIe 5xIe 6xIe Anlaufzeit/Ramp-up time (s) These devices must be reseted by disconnect the auxiliary voltage.
-
Page 21: Special Units
VS II ...-17 ... 45 12. Special units The rated voltage of a device featuring special voltage is indicated on the rating plate. In the case of devices with voltages < 400V it must be ensured that the device rating and the motor rating are not identical. - Page 22 VS II ...-17 ... 45 Attention! To avoid EMI couplings into the electronics and they disturbances they involve, it is not allowed to use free, unshielded strands in the motor cable for connecting the temperature sensor to the soft starter. The temperature sensor should be connected with the soft starter by a separate, and preferably, shielded cable.
-
Page 23: Installation Guideline
(see techn. data). 13.1 Connection The device is to be installed according to the attached connection diagram. For other connections please consult Advanced Control . 13.1.1 Earthing The electricalearthing provided ensures a low impedance connection between all metallic surfaces. - Page 24 VS II ...-17 ... 45 Caution: The protective conductor connection to the motor must no be laid in shielded motor cables, but is to be separately laid with an appropriate cross-sectional area. The individual earthing systems, power earth, protective earth, digital earth, and analog earth conductors should be laid separately by using a suitable star-point wiring.
-
Page 25: General Connection Diagram
VS II ...-17 ... 45 13.2 General connection diagram If you want to further reduce the interference voltage on the mains supply line during acceleration or deceleration (devices with low immunity to interference in close proximity), three X-capacitors 0,15µF/400V and two single-phase line reactors 3mH have to be connected. -
Page 26: Typical Connections
VS II ...-17 ... 45 13.3 Typical connections Standard circuit Reversing switch Wende- schalter VS II 400-17...45 VS II 400-17...45 S - closed = acceleration; S - open = deceleration S - closed = acceleration; S - open = deceleration Standard circuit for pole-changing motors Reversing circuit for pole-changing motors Reversing... -
Page 27: Motor/Soft Start In Delta Connection (Only Units With Option „M")
VS II ...-17 ... 45 13.4 Motor/Soft start in delta connection (only units with option „M“) Start VS II 400-17...45 M X7 X8 Further connection diagrams are available via the internet at www.advcontrol.eu... -
Page 28: Wide-Voltage-Range Connection
VS II ...-17 ... 45 13.5 Wide-voltage-range connection Control supply U = 24VDC ext. control input U 10 ... 24VDC VersiStart II 400-17...45 B Device Fault bypassed Further connection diagrams are available via the internet at www.advcontrol.eu... - Page 29 VS II ...-17 ... 45 14. Dimensions L1 L2 L3 versi start II Bypass 100% Start 100% 100% T1 T2 T3 Mounting dimensions VS II 400-17…32 VS II 400-45 52.5 All dimensions indicated in mm. 15. Special units Please see supplement.
- Page 30 Т е л : + 3 7 2 6 2 2 8 2 2 0 E - ma i l : i n f o @a d v c o n t r o l . e u a d v c o n t r o l . e u A d v a n c e d S y s t e ms B a l t i c O U P u n a n e 7 3 , 1 3 6 1 9 T a l l i n n , E s t o n i a a d v c o n t r o l .
