Summary of Contents for Comfort Zone 8259
- Page 1 TOUCHSCREEN THERMOSTAT (8259) GUIDE BRINGING YOU A LUXURY PRODUCT AT AN AFFORDABLE PRICE...
- Page 2 Function and Display Explanation Technical Information Voltage: See products Power key Power Consumption: 2W Setting range: 5...90°C (upper limitation from 35°C - 90°C adjustable) Manual control mode Limitation Range: 5...60°C (factory setting 35°C) Switching Differential: 0.5 - 10°C adjustable, factory setting ± 1°C Periods programming control mode Ambient Temperature: -5°C ~ 50°C Protective Housing: IP20...
- Page 3 Function and Display Explanation Dimensions (mm) menu key period from 1 to 6 plus key programming mode manual mode measured temp. day number time/temp. display minus key System Wiring Diagram heating on temp. sensor BYC-E91 on/off switch clock sensor Mounting Guides disassemble external frame with screw driver disassemble iron plate with screw driver fix iron plate with screw driver...
