Olympia POWER LIGHT Series Quick Start Manual

``POWER LIGHT`` SERIES FOR NON-MAINTAINED EMERGENCY LUMINAIRES
TECHNICAL CHARACTERISTICS
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Pb)
BATTERY PROTECTION
INDICATIONS - CONTROLS
CHARGING TIME
MINIMUM AUTONOMOUS DURATION
LIGHT SOURCE
EMERGENCY ILLUMINATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
Thank you for purchasing this product of
Olympia Electronics. A European manufacturer.

GENERAL

These luminaires are used indoors (ta 40 C)
where emergency light is needed. Each
luminaire must be permanently connected to
mains power supply. In normal operation the
power and the charge indicators light to show
that the batteries are in charging condition. In
case of a mains power supply failure the
power and the charge indicators turns off and
the luminaire will
automatically in emergency mode. When the
mains power supply is restored the device
turns to normal operation.

INSTALLATION

To install the luminaire follow the installation
instructions οn page 2.

OPERATION

When the device is powered from the mains,
the charge and power indicators should light.
The charge indicator confirms the charging of
the batteries. If it does not light, probably, the
batteries are disconnected. If it does not light
and the batteries are connected, then contact
the technician. As long as the charge indicator
blinks, the batteries of the luminaire are
charging and in this period, any autonomy test
must be avoided. When the charging circle is
complete, the indicator lights continuously (it
can be used as an indication of a power
Page 1 from 2
GR-21
12V/7Ah
2x20W (halogen)
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
302 x 94 x 330 mm
3330gr.
o
light the spot lamps
High Quality European based Manufacturers
GR-21/Η
220-240V AC/50-60Hz
14VA
From overcharge and deep discharge
Power indicator, battery charge indicator, TEST button
90 min
2x55W (halogen)
580lm
0 to 40 C
Up to 95%
Bayblend FR3010, transparent polycarbonate
325 x 120 x 380 mm
3 years (1 year for the lamps and the battery)
interruption). The batteries charging is done by
an 3 stages technological advanced procedure,
to ensure the appropriate and full charging of
the batteries.
The power indicator confirms the proper
connection to the mains. The TEST button, has
a dual use. If pressed instantlly while the device
is connected to the mains, the device simulates
the power interruption, by lighting the lamps for
3''. In this way, we can control the driver circuit
of the lamps and the lamps as indicated in
paragraph 3 in the text below .
When the voltage is interrupted, with
corresponding pressings of the button, we can
choose the operation of 2,1 or no lamps, either to
increase the autonomy time or not to consume the
battery power unnecessarily. This option is
canceled when the network is restored.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance or
testing must be done by authorized personel
only.
2. The device must be connected to the mains
power supply thru a fuse dependent by the total
amount of the line's power load.
3. It is sugested to check every month the
indication LED for battery charging, and by
pushing instantly the TEST button to check the
emergency cirquit and the lamps. If the
luminaire does not light
4. It is sugested to check every 6 months the
GR-29
24VA
2x12V/7Ah
24h
60 min
2x20W (halogen)
1620lm
IP 42
o
302 x 94 x 330 mm
7290gr.
contact the installer.
923029000_23_023
3h
580lm
