Charging Station
Models EVSE-RS and EVSE-RS Plug-in
POWER PRESENT
The charging station is receiving
AC power.
READY TO CHARGE
The charging station is ready to
charge or charging is paused.
VEHICLE CONNECTED
The connector is properly
connected to the vehicle port or
the charge is complete.
VEHICLE CHARGING
The vehicle is being charged.
TROUBLE
There is an error. Try removing
the connector and inserting
back into the vehicle. If
TROUBLE indicator is still
illuminated call Customer
Service at 888-833-2148.
Copyright © 2012 AeroVironment, Inc. - All rights reserved. AeroVironment and AV are trademarks of AeroVironment, Inc.
START
START
POWER PRESENT
READY TO CHARGE
VEHICLE CONNECTED
STOP
STOP
VEHICLE CHARGING
TROUBLE
START
Press to resume charging after
manual STOP. You do not need
to press START in order to
begin a regular charge. The
POWER PRESENT and READY
TO CHARGE lights must be on.
STOP
Press to manually pause
charging. You do not need to
press STOP to complete a full
charge. The device will stop
automatically when it reaches
full charge.
RELEASE BUTTON
Press to release the Connector
from the charging station or the
vehicle port.
21633-05 Rev.2
