IPitomy IS710 Door Box Quick Setup Manual

Hide thumbs
1
2

Advertisement

Table of Contents

IPitomy Door Box Quick Setup Guide
Document:IS710v2 Smart Sercurity IP Intercom User Manual.doc
•
The Ipitomy IS710 Door box comes by Default configured to a Static IP of
192.168.1.153
•
On First login make sure Language is set to English using the drop down on the left.
It is reccomended to connect to this IP address and then step one would be to configure for DHCP the network
Settings.
•
Step Two Configure Extension
Simply Create an Extension for the Doorbox in the PBX, set the Phone Type to IPitomy 2XX. Then using Auto-
Discovery find the device by scanning the network and configure in the normal Auto Discovery Method.
•
Once the Extension is registered with the PBX, the you can setup the Hotdial. This can be a Group or
Extension in the system, make sure the delay is set to 0. When the button on the doorbox is pressed, then
this will be the group or the extension which is called. The code to dial to send the open command to the
output contacts by default is 00. This is defined under DTMF.
The operation is defined as, User presses Center call button on Door box, Unit Hot dials the Extension or group
defined under Hotdial, and the answering party dials 00 which activates the door open current.
IS710_Door_Box
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS710 Door Box and is the answer not in the manual?

Questions and answers

Summary of Contents for IPitomy IS710 Door Box

  • Page 1 Step Two Configure Extension Simply Create an Extension for the Doorbox in the PBX, set the Phone Type to IPitomy 2XX. Then using Auto- Discovery find the device by scanning the network and configure in the normal Auto Discovery Method.
  • Page 2 IS710_Door_Box NEW IP710-01 Door Box Setup Guide • The New IP710-01 Door Boxes will have a static IP address of 192.168.1.100 It is reccomended to connect to this IP address and then configure for DHCP in the Network settings. • Use the WAN port if you are using POE Use the LAN port if you are connecting direct power to the door box •...
