DNT DigiMicro Profi HDMI User Manual page 37

Drawing
Click icon to choose any kinds of drawing under the
pull-down manual as below.
properties of the line
Click icon and set the font for the text in the popup
dialogue
Double-click on the picture to enter into measurement interface.
Under the 'Measurement' icon, you can choose any options to
measure.
Any Angle Line Measurement. Simply click from one point and
drag to the next point, then release the click.
Continuous Line Measurement. The Continuous Line
measurement allows you to measure any continuous desired
length. Simply click and drag from one point to other desired
points, and then release the click.
Radius Circle Measurement. Simply click and extend out to the
desired radius, the radius, circumference and area of the circle
will show up accordingly.
Diameter Circle Measurement. Simply click and extend out to
the desired diameter, the diameter, circumference and area of
the circle will show up accordingly.
Three Points Angle Measurement. Simply defi ne any three
points angle and click, the angle value will then display.
- 37 -
