Step 4 Adjust Swivel Joints
Insert the 3/32" allen wrench (provided) into the appropriate set screw and
tighten or loosen to the desired degree of joint friction.
Base Mount
Platform Shaft
Step 5 Adjust Platform Tilt
A tilt device is mounted underneath the keyboard platform. You can easily
adjust the angle of typing on your keyboard by turning the tilt knob to
either raise or lower the front of the platform.
Your assembly and modifications are complete. If you need additional assistance
regarding this product or if you need to return this arm for any reason, please
contact our customer service department at 800.524.2744 to obtain a Return
Authorization Number (R/A).
© Innovative Office Products, Inc. 2004
Tilt Knob
IOP-502563
I n n o v a t i v e O f f i c e P r o d u c t s , I n c .
Model 9040
Keyboard Mechanism
Installation Instructions
