- Page 1 Surface Mount Dual 10” Subwoofer Accessories Original parts for: en | Installation note...
-
Page 3: Table Of Contents
Table of contents | en Table of contents Safety Suspensions Notices Short information Introduction Installation Installing the U-bracket Installing the transfomer input panel Installing the crossover input panel Technical data Dimensions Bosch Security Systems B.V. | Electro-Voice Installation note 2018.07 | 02 | F.01U.347.595... -
Page 4: Safety
For information on getting permission for reprints and excerpts, contact Bosch Security Systems, Inc. The content and illustrations are subject to change without prior notice. -
Page 5: Short Information
U-bracket for 10" subwoofer white IP-10D-TB Transformer input 10" subwoofer bk IP-10D-TW Transformer input 10" subwoofer wh IP-10D-CB Crossover input 10" subwoofer bk IP-10D-CW Crossover input 10" subwoofer wh Bosch Security Systems B.V. | Electro-Voice Installation note 2018.07 | 02 | F.01U.347.595... -
Page 6: Introduction
Cabinet subwoofer 2x10" black LB20-SW400-L Cabinet subwoofer 2x10" white Read through this manual to familiarize yourself with the safety information and applications before you use these products. 2018.07 | 02 | F.01U.347.595 Installation note Bosch Security Systems B.V. | Electro-Voice... -
Page 7: Installation
Install a 10-mm rated forged eyebolt (not included) into the safety point. Suspend the subwoofer from the eyebolts using rated fittings and steel cable. Secure the subwoofer from the safety eyebolt using a rated fittings and steel cable. Bosch Security Systems B.V. | Electro-Voice Installation note 2018.07 | 02 | F.01U.347.595... -
Page 8: Installing The Transfomer Input Panel
To install the transformer input panel, do the following: Remove the standard input panel. Disconnect the standard input panel. Connect the transformer input panel. Install the transformer input panel. Install the weather cover, if applicable. 2018.07 | 02 | F.01U.347.595 Installation note Bosch Security Systems B.V. | Electro-Voice... -
Page 9: Installing The Crossover Input Panel
To install the crossover input panel, do the following: Remove the standard input panel. Disconnect the standard input panel. Connect the crossover input panel. Install the crossover input panel. Install the weather cover, if applicable. Bosch Security Systems B.V. | Electro-Voice Installation note 2018.07 | 02 | F.01U.347.595... -
Page 10: Technical Data
Net weight: 1.71 kg (3.76 lb) Shipping weight: 2.34 kg (5.16 lb) Tab. 5.3: Crossover input Dimensions The U-bracket dimensions are not to scale and are for reference only. 2018.07 | 02 | F.01U.347.595 Installation note Bosch Security Systems B.V. | Electro-Voice... - Page 11 2x 21.0 mm [2x 0.82 in] 316.0 mm [12.44 in] 2x 21.0 mm [2x 0.82 in] 3x 50.0 mm [3x 1.97 in] Figure 5.1: Dimensions - 10" U-bracket Bosch Security Systems B.V. | Electro-Voice Installation note 2018.07 | 02 | F.01U.347.595...
- Page 12 Bosch Sicherheitssysteme GmbH Bosch Security Systems, Inc Robert-Bosch-Ring 5 12000 Portland Avenue South 85630 Grasbrunn Burnsville MN 55337 Germany www.boschsecurity.com www.electrovoice.com © Bosch Sicherheitssysteme GmbH, 2018...
