Series
COUNTERS
for IMPULSES
COUNTERS for IMPULSE signals
USER'S MANUAL
(HT0695-r050705)
MAG983-X
MAG983-1
MAG983-2
MAG983-3
MAG983-4
IDEAL SOLUTION for impulse counting applications where the operator
has no access to the configuration of the unit. Instruments with scaling
capability, in order to visualize in different units such as units, meters,
accumulated flow, ...
FEMA ELECTRÓNICA - Page 1
Advertisement
Summary of Contents for Fema MAG983 Series
- Page 1 IDEAL SOLUTION for impulse counting applications where the operator has no access to the configuration of the unit. Instruments with scaling capability, in order to visualize in different units such as units, meters, accumulated flow, ... USER’S MANUAL (HT0695-r050705) FEMA ELECTRÓNICA - Page 1...
- Page 2 Frontal push button DIMENSIONS 96 x 48 x 117 mm (3,78 x1,89 x 4,61’’) PANEL CUTOUT 92,5 x 44,5 mm (3,64 x 1,75‘’) Vexc OUTPUT +10Vdc (maximum 70 mA) MATERIAL HOUSING ABS, black color WEIGHT 310 gr. FEMA ELECTRÓNICA - Page 2...
- Page 3 The «RESET» connection at the RESET POWER SUPPLY rearside terminal is operated with a 7 6 5 4 3 mechanical contact connected at terminals 7 and 3. Power is connected at terminals 1 and 2. RESET FEMA ELECTRÓNICA - Page 3...
- Page 4 5 (Signal) y 3 (Common) «INPUT2» terminals 6 (Signal) y 3 (Common) Note .- Input2 will be Mechanical Contact. It can not be configured Señal 0 Vdc for PICK-UP type 7 6 5 4 3 SENSOR PICK-UP at «INPUT2» FEMA ELECTRÓNICA - Page 4...
- Page 5 «61 4E» Default Parameters «66 1E» Default Parameters «62 1E» Default Parameters «1» 500 Value for memory «AL1» «63 1E» Default Parameters «2» 1000 Value for memory «AL2» «64 4E» Default Parameters «3» 1.0000 «Scale Factor» FEMA ELECTRÓNICA - Page 5...
- Page 6 (maximum 8.388.608 impulsos can programmed to activate a «RESET» when its value is be counted). If this value is exceeded, the negative reached (see code «56 5E»). led sign is activated and the display will work in FEMA ELECTRÓNICA - Page 6...
-
Page 7: Declaration Of Conformity
Harmonised Standards stated below. STANDARDS Signed .- D. Juncà IMMUNITY UNE EN 50082-1 (1998) Position.- Quality Manager EMISSIONS UNE EN 50081-1 (1994) Place .- Barberà, 2005 ELECTRICAL SAFETY UNE EN 61010-1 (1996) UNE EN 60204-1 (1997) FEMA ELECTRÓNICA - Page 7... - Page 8 TIME www.fema.es ELECTRONIC INSTRUMENTATION FOR INDUSTRY FEMA ELECTRÓNICA, S.A. Pol. Ind. Santiga - Altimira 14 (T14 - N2) E-08210 Barberà - BARCELONA ESPAÑA - SPAIN Tel. (+34) 93.729.6004 - www.fema.es FEMA ELECTRÓNICA - Page 8 Fax (+34) 93.729.6003 - info@fema.es...
