Proxicast EtherLINQ Quick Start Manual

4g lte router + wifi + vpn
Hide thumbs Also See for EtherLINQ:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
4G LTE Router + WiFi + VPN
Quick Start Guide
The REALLY QUICK Start Guide
1. Attach the external antennas
2. Insert an activated SIM
3. Connect power to the EtherLINQ
4. Wait 90 sec. for the OS and LTE LEDs to stop flashing
5. Connect a DHCP-enabled PC to the LAN port or scan for a WiFi network named
EtherLINQ-xxxx and enter the 8 digit password printed on the EtherLINQ's label
The EtherLINQ automatically attempts to connect to the default APN for your 4G carrier.
If you are using a different APN or the modem fails to connect to the Internet:
• Browse to http://192.168.1.1:8080 Username/Password: admin/1234
• Select the LTE tab
• Enter the correct APN for your SIM
• Click the Save & Apply button
• The EtherLINQ will reboot and connect to the Internet
Click the "Check For Updates" button to install the latest firmware

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EtherLINQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proxicast EtherLINQ

Summary of Contents for Proxicast EtherLINQ

  • Page 1 EtherLINQ-xxxx and enter the 8 digit password printed on the EtherLINQ’s label The EtherLINQ automatically attempts to connect to the default APN for your 4G carrier. If you are using a different APN or the modem fails to connect to the Internet: •...

  • Page 2: Package Contents

    • Metal Chassis & Wide Voltage Range Figure 1: Typical EtherLINQ Network Configuration See the EtherLINQ User’s Guide for a complete list of features and configuration settings. Also refer to Proxicast’s Support Web Site (http://support.proxicast.com) for technical notes, application configuration examples and knowledgebase articles.
  • Page 3 CONFIGURATION MODE and forces the LAN IP = 192.168.1.1:8080 RESET Press & hold for 10 seconds until the top row of LEDs flash in sequence. This returns the EtherLINQ to its factory default settings: LAN IP = 192.168.1.1:8080 Username/Password = admin/1234...

  • Page 4: Etherlinq Default Settings

    WPA2 Password = 8 digit number from the EtherLINQ label Security All TCP/UDP ports closed. Remote Management disabled Press the RESET button for 10 seconds to return the EtherLINQ to these settings. External Antenna Connections The EtherLINQ has 2 SMA Female antenna jacks for 4G LTE external antennas and 2 RP-SMA (reverse polarity) Female jacks for WiFi.
  • Page 5 Enter http://192.168.1.1:8080 in a web browser Step 2: At the Login screen (Figure 4), enter the default Username: admin and the default Password: 1234 Step 3: The EtherLINQ Status screen will be displayed (Figure 5) Figure 4: Login Screen Figure 5: EtherLINQ Status Screen...

  • Page 6: Common Tasks

    Update Firmware Status Tab> Check Requires an active WAN connection to For Updates button check the Proxicast server for updates. Consult the EtherLINQ User’s Guide for more detailed information on how to configure all of the EtherLINQ’s features.

  • Page 7: Troubleshooting

    Cannot ping the If the LAN LEDs are off, check the cable connections. EtherLINQ from Verify that the IP address and subnet of the EtherLINQ is in the the LAN same range as the computers on the LAN and that the EtherLINQ is the default gateway for all LAN devices.

  • Page 8: Common Carrier-Specific Issues

    1-412-213-2477 (outside USA) support@proxicast.com © Copyright 2000 - 2018. Proxicast, LLC. All rights reserved. Proxicast is a registered trademark and EtherLINQ, LAN-Cell and PocketPORT are trademarks of Proxicast LLC. All other trademarks/servicemarks mentioned are the property of their respective owners.
