A
B
C
D
E
F
G
H
I
J
Items Included:
A. (12) Machine Bolts & Washers
B. (3) Lag Bolts & Washers
C. (1) Spanner Wrench
D. (3) 20" Housings w/Covers
E. (1) Sediment Cartridge
F. (1) Chloramine Cartridge
G. (1) NaturSoft Cartridge
H. (1) Mounting Bracket
I. (3) Decals
J. (1) Silicone Grease
Specifications:
Rated Service Flow
5 gpm
Minimum Working
25 psi
Pressure
Maximum Working
80 psi
Pressure
Operating
36°F - 120°F
Temperatures
PH Range
6 - 11
© Pelican Water Systems
Housing Cover
Assembly
1. Unpackage and account for all items before starting installation.
2. Determine location and water flow direction for system.
3. Install covers onto bracket orientating the INLET and OUTLET
correctly. Use 4 bolts and washers in each cover to attach.
3060 Performance Circle • Deland, FL • 32724
NaturSoft Cartridge
(Install as Shown)
Housings
877-842-1635
MODEL: PSE-500
Fig. A
O-Ring
Stand Pipe
www.pelicanwater.com
EZC_2019-3_Rev_C
Advertisement
Summary of Contents for Pelican Water Technologies EZ Connect PSE-500
- Page 1 MODEL: PSE-500 Fig. A NaturSoft Cartridge (Install as Shown) Housing Cover O-Ring Stand Pipe Housings Items Included: A. (12) Machine Bolts & Washers Assembly B. (3) Lag Bolts & Washers C. (1) Spanner Wrench 1. Unpackage and account for all items before starting installation. D.
- Page 2 8. After 10 minutes turn off faucet. 9. Your system is now ready for use. Top of Pelican EZ Connect PSE-500 WARNING: If this or any other system is installed in a metal (conductive) plumbing system, i.e. copper or galvanized metal, the plastic Front of Pelican EZ Connect PSE-500 components of the system will interrupt the continuity of the plumbing system.
- Page 3 EZ CONNECT COMPACT WATER FILTRATION SYSTEM MODEL: PSE-500 Warranty Pelicans Limited Lifetime Warranty Pelican Water ("Pelican") warrants to the end user ("customer") that its tanks (13" and smaller), valves, in/out non-electric heads, bypass's, fittings and housings for POE systems ("Covered Items") will be free from defects in material and workmanship under normal use and service for a limited lifetime of twelve (12) years from the date of original purchase**.
