Installation, Operating and Maintenance
EasyBus
Signalling and Switching Bus System
Contents
Safety instructions ............................................................................... 2
General information ............................................................................ 2
Warranty ............................................................................................. 2
Recycling .............................................................................................. 2
General information about EasyBus .................................................... 2
Module overview ................................................................................. 2
EasyF-ADC connections ....................................................................... 3
EasyF-AAC connections ....................................................................... 3
EasyF-VDC connections ....................................................................... 4
EasyF-VAC connections........................................................................ 4
EasyF-VMP connections ...................................................................... 5
EasyF-RMM connections ..................................................................... 5
EasyF-IOM connections ....................................................................... 6
EasyF-I8M connections ........................................................................ 6
Programming of the EasyF modules .................................................... 7
Cable length ......................................................................................... 8
Module mounting ................................................................................ 8
Flat cable system ................................................................................. 8
Switch cabinet mounting ..................................................................... 8
Wiring of the EasyS-MV1/-Mv2 ........................................................... 9
Modbus communication ..................................................................... 9
Terminating resistor ............................................................................ 9
Programming of EasyS-MV2 .............................................................. 10
Circuit diagram for an Easy network ................................................. 14
Modbus register ................................................................................ 18
Read and write register of EasyF-ADC and -AAC ............................... 19
Read and write register EasyF-VDC and EasyF-VAC ........................... 25
Read and write register for EasyF-RMM ............................................ 31
Read and write register EasyF-IOM ................................................... 34
Read and write register EasyF-I8M .................................................... 37
Read and write register EasyF-VMP .................................................. 40
Construction subject to change
No return possible
Version: 2016-06-29 | Page 1
